Royal Sovereign ARP-906EC User manual

Royal Centurian Inc.

ARP-906EC

OWNER’S MANUAL

MANUAL DEL PROPIETARIO

Portable Air Conditioner

Acondicionador de Aire Portátil

Read and retain these instructions for future reference

For any Customer Support needs, please choose

the Support tab on www.royalsovereign.com

Parts - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3

Safety Precautions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4

Installation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5

Operation/Functions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6

Maintenance - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9

Troubleshooting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10

Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11

Warranty - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12

PORTABLE AIR CONDITIONER

Model ARP-906EC

TABLE OF CONTENTS

ARP-906EC

PARTS

Handle Control panel

Evaporator Filter

Condenser

Air Outlet

Air Louvers

Rear Casters Exhaust Air Outlet

Power Cord

Drain Port

Front Casters w/ Lock

Exhaust Air Hose

BEFORE USE

SAFETY PRECAUTIONS

If unit has been transported on its side set the machine upright for 2 hrs. before use.

1. Only use in the upright position on a flat, level surface at least 20”/50cm from any object or water leak may occur.

2. Do not place objects on top or in front of the unit.

3. Closely supervise children and pets while unit is in use.

4. For indoor use only.

5. Turn off and unplug the unit when it is not in use.

6. Do not use in wet environments.

7. Do not pull the unit by the cord.

8. If the power cord is damaged, it must be replaced by an electrician to avoid hazard or injury.

Make sure there is a green light on the plug when unit is plugged into power source. If not press reset button on plug

until the green LED light on the plug illuminates.

FOR MAXIMUM EFFICENCY

1. Do not exceed the recommended room size of 300 sq. feet.

2. Keep doors and windows closed.

3. Keep curtains or blinds closed during the sunniest part of the day.

4. Keep filters clean.

5. Once room has reached the desired conditions, reduce the temperature

ARP-906EC

INSTALLATION

1. Connect the hose to the exhaust air outlet.

2. Insert the exhaust hose into the window spacer.

NOTE: The hose may be extended from 1-5 ft/300-1500mm but for maximum efficiency use the shortest length

possible. For best results do not let the exhaust hose exceed a 45° angle.

OPERATION/FUNCTIONS

CONTROL PANEL

1. Temperature/Hour LED Display

2. Power button

3. Power/Water Full indicator light

4. Temperature DOWN button

5. Temperature UP button

6. Mode button (Fan, Cool, Auto, Dry)

7. Fan indicator light

8. Cool indicator light

9. Auto indicator light

10. Dry indicator light (Dehumidifier)

11. Speed button (High, Medium, Low)

12. High indicator light

13. Medium indicator light

14. Low indicator light

15. Sleep button

16. Sleep indicator light

17. Oscillating button

18. Oscillating indicator light

19. Timer button (1-12 hours)

20. Timer indicator light

ARP-906EC

ON/OFF

Press this button to start and stop the unit.

MODE

Press this button to select the Fan, Cool, Auto or Dry (Dehumidifier) mode.

The Fan mode will allow you to select a Speed of High, medium or Low.

The Cool mode will allow you to select a Speed of High, Medium or Low or a specific temperature by using the

UP/DOWN buttons.

The Auto mode will automatically adjust the settings between Fan (High, Low and Medium) and Cool (High, Low and

Medium) depending on the current temperature in the room. Press the Auto button and then use the UP/DOWN button to

select your desired temperature. If the temperature in the room is at 73°F and above the COOL mode and SPEED will

automatically be selected to keep the room at the desired temperature. If the temperature in the room is between 68°F -

73°F the FAN mode and SPEED will automatically be selected to keep the room at the desired temperature.

The Dry mode will allow you to dehumidify the room and remove excess moisture.

SPEED

Press the SPEED button to select a High, Medium or Low setting.

TIMER (1-12 Hours)

The timer button will allow you to turn the unit ON or OFF without even being in the room.

If the unit is off- Press the TIMER button (Timer indicator light will be lit). Continue pressing the TIMER button until you

select the quantity of hours (1-12) you want the unit turned on in. Example- If you want the unit to turn on in 3 hours then

Press the button until it shows 3, the unit will automatically turn on in 3 hours.

If the unit is on- Press the TIMER button (Timer indicator light will be lit). Continue pressing the TIMER button until you

select the quantity of hours (1-12) you want the unit turned off in. Example- If you want the unit to turn off after 4 hours

then press the button until it shows 4, the unit will automatically turn off in 4 hours.

SLEEP

By pressing the SLEEP button, the set temperature will increase 2°F / 1°C

in the first hour, another 2°F / 1°C in the second hour and then remains at that temperature.

WATER FULL

When the water tank is full the POWER/WATER FULL light will light up and you will hear a beeping noise. At this point

you must empty it out by placing a container underneath the drain port, remove the rubber drain plug and then water will

flow out until it is empty.

OSC (OSCILLATING) FEATURE

This feature allows the air to flow in all directions. Press the Oscillating button (OSC indicator will be lit). The air louvers

will begin oscillating. Press the OSC button again to turn it off.

REMOTE CONTROL

A - Timer button

B - Fan button

C - Mode button

D - Sleep button

E - Oscillating button

F - ON/OFF button

G - Temperature UP button

H - Temperature DOWN button

ARP-906EC

MAINTENANCE

Always unplug the air conditioner from the outlet before cleaning. To maximize the efficiency of the air conditioner, clean

regularly.

Cleaning the Filter

Remove the filter from the side of housing. Use a vacuum cleaner or gently tap the filter to remove loose dust and dirt,

then rinse thoroughly under warm running water. Dry thoroughly before returning the filter to the correct position.

NOTE: Never operate the unit without a filter

Cleaning the Housing

Use a soft, damp cloth to wipe the body clean.

Never use chemicals, gasoline, detergents, chemically treated cloths or other cleansing solutions as this could possibly

damage the housing.

Storage

• Drain any water from the unit by emptying the water through the drain port into the water tray (see the PARTS section).

• Clean the filter

• Unplug and wrap the power cord around the cord holders on the back of the unit.

• If possible, place back in its original carton or cover for storage.

• Always keep the unit in the upright position

TROUBLESHOOTING

NOTE: Never try to repair or dismantle the unit yourself.

Problem Possible Cause/Solution

• Press reset button on the plug until the green LED light

on the plug illuminates.

• Check to see if it is plugged in.

• Check to see the power is on.

• Is there direct sunlight. Close all curtains and blinds.

• Check to make sure there are no doors/windows open.

• Check to make sure nothing that produces heat is on.

• The unit may be on an uneven surface. Make sure it is

on a flat surface.

• The compressor may have turned on. This is normal.

The air conditioner does not run

The machine is not cooling very well

The unit is vibrating

Sudden noise
