Ronbow BRIT E026117 Assembly instructions

INSTALLATION AND CARE GUIDE

BRIT TALL SIDE CABINET

E026117

BRIT 71” Tall Side Cabinet

Model : E026117

170710ronbow.eu | ronbow.comINSTALLATION SHEET

Tools Required

PRE-INSTALLATION

2 set of anti-tipping hardware

4 short screws

4 long screws

8 shelf clips

4 anchors

Materials Included

BRIT 71” Tall Side Cabinet

Model : E026117

170710ronbow.eu | ronbow.comINSTALLATION SHEET

Step 1:

Figure 1.

INSTALLING ANTI-TIPPING HARDWARE

Determine the ideal location of your

new side cabinet.

Mark the location of x, y on the wall.

Then use the anti-tipping hardware

base plate (shown on the right) as a

guide to mark the anchor location.

Drill 1/4” anchor holes and screw into

the drywall.

Secure the anchors into the wall, and

then fasten the long screws provided

into the anchor to secure the base

plate.

Secure the matching plate to the

cabinet with the screws provided.

See Figure 1.

Step 2:

Step 3:

Step 4:

Y

BRIT 71” Tall Side Cabinet

Model : E026117

170710ronbow.eu | ronbow.comINSTALLATION SHEET

Figure 2.Slide the zip ties provided

through the loop and secure the

cabinet to the wall.

Note: Some minor adjustments

may be needed to level the side

cabinet to

the ﬂoor.

Turn the leg levelers at the

bottom of each leg to ensure the

side cabinet

is level.

Verify with a level.

See Figure 2.

Step 5:

Leveler

Finished Wall

BRIT 71” Tall Side Cabinet

Model : E026117

170710ronbow.eu | ronbow.comINSTALLATION SHEET

See Figure 4.

See Figure 3.

Step 1: Unhinge the door by popping o the

hinge from the base of the cabinet.

Figure 3.

Step 2: Unscrew the hinge plate from the base

of the cabinet.

Measure the distances of the existing

screw holes and copy that to the

opposite side.

Figure 4.

Step 3:

Step 4:

Install the hinge plate.

REVERSE DOOR OPENING FOR INVERTED INSTALLATION

Bracket

Hook

Install the door to the base of the

cabinet. Push the hinge until you hear

a click to lock the hinge into place.

Cup

BRIT 71” Tall Side Cabinet

Model : E026117

170710ronbow.eu | ronbow.comINSTALLATION SHEET

See Figure 5.

Step 1: Unhinge the door by popping o the

hinge from the base of the cabinet.

See page 3.

Figure 5.

Step 2: Unscrew the shelf clip from

the under-side.

Remove the glass shelf.

REMOVE GLASS SHELVES

BRIT 71” Tall Side Cabinet

Model : E026117

170710ronbow.eu | ronbow.comINSTALLATION SHEET

Figure 6.

Locate the screw nearest the hinge

cup and rotate clockwise or counter-

clockwise to move the door from side

to side.

Locate the screw furthest away from

the hinge cup and turn the screw

clockwise or counter-clockwise to

move the door from front to back.

Locate the screw pictured in Figure 6.

Turn the screw clockwise or counter-

clockwise to move the door from top

to bottom.

ADJUST DOOR HINGE

Figure 7.

Figure 8.

NOTE: When adjusting the door hinges keep in mind

to adjust the other hinges.

Side to Side

Front to Back

Top to Bottom

See Figure 6.

See Figure 7.

See Figure 8.

Side

Depth

Height

BRIT 71” Tall Side Cabinet

Model : E026117

170710ronbow.eu | ronbow.comINSTALLATION SHEET

Wood Surfaces

Recommended Products

The ﬁne furniture ﬁnish of your new vanity, mirror or other bathroom accessories are designed to

protect against normal home use. With proper care, your product will provide years of use and beauty

in your home.

General Care Tips

PRODUCT CARE AND MAINTENANCE

• If a spill occurs, clean and dry the surface immediately as liquid can soak through the surface and cause

greater damage.

• Do not place in direct sunlight. Exposure to sunlight may affect the appearance of your vanity, and the

finish will eventually crack.

• Keep away from direct sources of extreme temperatures as heat, cold or moisture from humidity.

Color changes, or blemishes in the wood can occur if recommended care of is not met. Try to avoid

these extremes.

• Most wood surfaces can be cleaned, or dusted, with any commercial wood cleaning product. For general

cleaning, use a non-abrasive, or lint-free cloth while dusting along the wood grain to preserve the

wood’s chacteristics.

• Pledge Orange Oil, or similar

• Orange-Glo Wood Cleaner

DISCLAIMERS: Wood naturally ages, darkens and changes color over time due to several environmental conditions that may cause materials to vary from their

original color and/or to warp, split or crack. These variations are considered to be the nature of the material in relation to their environmental exposure and may

be signiﬁcant over a long period of time. The eectiveness of cleaning Ronbow product is dependant on various factors that include sunlight, smoke, moisture,

household cleaners and/or amount of cleaning product used over time. Ronbow cannot guarantee that the above Product Care & Maintenance methods will

eectively clean your product.

• Test cleaning product on small, discrete area prior to applying to entire surface.

• Wipe surfaces frequently with dry, soft, non-abrasive and lint-free towel.

• Do not allow liquids and moisture to accumulate on the surface of products.

• For warranty information, please visit our website at www.ronbow.com or contact the Customer Service

Department at (510) 713-1188.

170710

40650 Encyclopedia Circle

Fremont, CA 94538

T 510.713.1188

F 510.657.9388 ronbow.eu | ronbow.com
