Rollei dk3000 User manual
3.3 MegaPixels DSC
User Manual - English
Contents
Safety Precautions 1
Specifications 2
Name of Parts 4
Before Using the Camera 8
1.Preparation 9
Powering the Camera 9
Storage Media 10
2. Recording 12
Basic Recording 12
Other Advanced Menu Functions 15
3. Playback / Delete 16
Basic Playback 16
Various Playback Functions 18
Deleting Files 23
4. Others 24
Changing the Camera Settings 24
Transferring your Image to the computer 27
Video Capture 28
Warning Message 29
○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○
1
Safety Precautions
Danger
Do not attempt to disassemble, repair or alter the equipment
yourself. The high-voltage circuitry in the equipment poses
significant electrical hazard.
Do not attempt to disassemble, alter or directly solder the
battery.
Do not put the battery in a fire, attempt to heat it, uses it in
high temperature environment such as next to a fire or inside
a car.
Do not put it into water or allow it to get wet.
Do not use this camera in the bathroom.
Do not use batteries that are significantly damaged or
deformed.
Turn off the power immediately in the event of irregularity,
such as the equipment emitting smoke or a strange smell.
Remove the battery as soon as possible, being careful to
avoid electric shocks or burns. If you are drawing power from
a household electric outlet, be sure to unplug the power cord.
Keep the battery and SD memory card used in this camera
out of the reach of children to prevent accidental ingestion.
2
Specification
General
zVideo Signal Protocol NTSC / PAL
zPower Source Rechargeable Lithium-Ion Battery 3.7V
/ AC Adapter 5V
zDimensions (WxHxD) 116.7 x 53.8 x 29.5 mm (4.5” x 2.1” x 11.6)
zWeight Approx. 172g (6.0 oz) (without battery)
zOperating Conditions Temperature: 0°C to 40°C (32°F to 104°F)
Humidity: 85% or less
zStorage Temperature -20°C ~ 60°C (-4°F to 140°F)
Memory Media
zInternal Memory 16 MB
zMemory Card Secure Digital Memory Card Slot
3
zShutter Speed 4, 2, 1 ~ 1/ 1000
zISO Sensitivity Auto, ISO 200, ISO 400
zBuilt-in Flash Modes: Flash Off, Forced, Auto, Slow Synchro,
Red-eye Reduction
zImage zStill Picture: 2848 x 2136 / 2048 x 1536 /
Resolution 1600 x 1200/ 1280 x 960
zMotion Picture:320 x 240
zFile Format JPEG (Exif2.1), TIFF, AVI
Camera
zCCD 1/2.7 inch 3.34 mega pixels
zLens Zoom Lens F2.8 ~ 3.8
zFocal Length f = 5.9 ~ 11.8 mm (equivalent to 38 ~ 76 mm in
35 mm format )
zShooting Range zGeneral: Approx. 14 cm (5.5”) (at Wide)
Approx. 40 cm (15.7”) (at Tele)
zMacro: Approx.7 ~ 14 cm (2.75” to 5.5”) (at Wide)
zDigital Zoom 2X
zMonitor 1.5 inch LTPS TFT color LCD
zWhite Balance Auto / Preset (Daylight, Overcast, Fluorescent
Light, Tungsten Light)
zExposure zExposure Metering System: Center-weighted
Compensation zMode: Auto /Manual compensation (± 2.0EV in
0.5 EV steps)
zMetering: TTL CCD method
4
Names of Parts
Camera
a. Front
b. Back
Shutter
Release Power
Switch
Flash
Sensor
Flash
Lens
Wrist Strap Eyelet
Battery Recharging
and Self-Timer LED
Card Cover
Card Cover Switch Battery Cover
Power Supply
Terminal DC Input
USB Terminal
Operating Parts
Main Switch
The camera offers a number of modes for
recording and playback. The mode dial is
used to select the desired mode.
Mode Dial Mode Name Description
Set up mode This mode is used for changing
and confirming the camera
setting.
Playback mode This mode is used for playing
recording files.
Still Picture mode This mode is used for normal
shooting.
PIC Button
Button
/ Zoom Button
Mode Dial
MENU / ENTER Button
CANCLE Button
DISPLAY Button
LCD Monitor
Vedio Out
SET UP
Flash LED
Autofocus LED
5
Continuous Picture are recorded
Shooting mode continuously while the
shutter release button
is pressed.
Motion Picture This mode is used for recording
motion picture.
4-way Button
For Up / Down / Left / Right and Zoom Function.
MENU / ENTER Button
Display Menu and various modes.
Button
Icon Display Mode Description
Lit Flash The flash will not fire under
Off any conditions.
No No Auto The flash fire automatically in
Icon Display low light and back light
conditions.
Lit Forced The flash will fire under
any conditions.
Blinking Slow The flash can be fired to
Synchro illuminate the subject while a slow
shutter speed correctly exposes the
background.
Tele / Up
Right
Wide / Down
Left
6
PIC Button
The camera offers six image quality modes: 2848 x 2136N,
2048 x 1536NC, 2048 x 1536F, 2048 x 1536N, 1600 x 1200N,
and 1280 x 960.
The default is 2048 x 1536N.
2848 x 2136N used for taking pictures with higher image
quality.
NC (non-compressed) mode is for recording data without
compressing it. N and F stand for Normal and Fine.
CANCEL Button
For Canceling.
DISPLAY Button
For LCD Display Function and Adjusting the Brightness of
the LCD Monitor.
The data display changes to show the recording mode,PIC
mode, recordable picture count, etc. each time the
DISPLAY button is pressed.
Press this button (approx. 2 seconds)
to adjust the brigstness of the LCD
monitor when it is hard to see, such
as in strong sunlight.
2002/07/15 11:25
N 1600
26
2002/07/15 11:25
7
This mode can not be played back by using
Zoom Playback Function.
8
Before using the camera
Attaching the Wrist Strap
Attach the wrist strap to the camera.
Pass the end of the strap through
the wrist strap eyelet on
the camera.
Setting the Date and Time
1. Set the mode dial to [ SET UP ].
2. Press the or button to select
[ DATE SETTING ] and press Button.
3. Press , , and buttons to set
the date and time. Press or button
to highlight the item you wish to adjust,
and press the or button to adjust
the item.
SET UP 2/3
BEEP SOUND
POWER SAVE
SEQ.FILE NO.
LANGUAGE
ON
OFF
ON
ENGLISH
SELECT:
DATE SETTING
SET DATE/TIME
SEL.:ENTER
CANCEL:CANCEL
2002 / /01 01
00 00:
The time is displayed in 24 - hour
clock format.
