Robot Coupe R301 User manual

Prepare 2000 restaurant servings

in 3 hours. Healthcare facilities

can prepare puree diets daily for 12

residents.

• 1.5 H.P. single phase motor with

magnetic safety switch. Push button

“On-Off” and “Pulse” switches.

• New motor base and vegetable prep

attachment designed to be more

user friendly, better sanitation and

made from new material that is more

resistant to chemical agents for a

longer life span.

• New cutter bowl and lid design with:

R301 Series D - Gray Bowl

R301U Series D - Stainless Steel

Bowl

- ergonomic handle for easier

handling.

- 10% increased liquid capacity due

to higher hub.

- new safety system improves the life

span of lid and safety rod.

• New integrated ventilation system

position for better sanitation.

• Great disc selection to accommodate

most veg prep applications.

• Attachments easily removed for

assured sanitation.

• Unit base uses 13 1/16” x 11 15/16”

of counter space.

• Packed with two processing discs

(R209, 5/64” grating disc & R211,

5/32” slicing disc) as standard.

• 1 year parts and labor warranty.

Robot Coupe U.S.A., Inc.

P.O. Box 16625

Jackson, MS 39236-6625

1-800-824-1646 • (601) 898-8411

FAX: (601) 898-9134

www.robotcoupeusa.com • e-mail: info@robotcoupeusa.

com

“The Inventor & World Leader in Food Processors”

Commercial Food Processor

“Series D”

R301& R301U

Combination Continuous Feed

Vegetable Prep and Vertical

Cutter Mixer

Prepare Sauces and

Pate’ in Bowl Unit

Vegetable prep attachment

designed for quality continuous

feed slicing, shredding, grating,

french fry, and julienne cuts.

Accommodates 21 different

processing discs. Bowl attachment

designed for vertical cutting and

mixing functions: Mix, chop, puree,

and blend.

R301U Series D

Model has Stainless

Steel Bowl

R301 Series D

Model has Gray

Bowl

Robot Coupe U.S.A., Inc.

P.O. Box 16625

Jackson, MS 39236-6625

1-800-824-1646

(601) 898-8411

FAX: (601) 898-9134

www.robotcoupeusa.com

e-mail: info@robotcoupeusa.com

Distributed by:

Robot Coupe reserves the right to change specifications. Call the factory for latest specifications and recommendations.

Specifications

R301 SERIES D STANDARD MODEL: includes motor base unit

with gray ABS plastic cutter bowl, stainless steel “S”blade,

continuous feed attachment, one 1/8”(3mm) slicing disc and

one 1/8”(3mm) medium grating disc and discharge plate.

R301U SERIES D STANDARD MODEL: includes motor base

unit with stainless steel cutter bowl, stainless steel “S” blade,

continuous feed attachment, one 1/8”(3mm) slicing disc and

one 1/8”(3mm) medium grating disc and discharge plate.

ELECTRICAL REQUIREMENTS: 120V, 60Hz, 9 Amps, single phase.

Contact your local electrician for local code

requirements.

SWITCHING: Control panel with push-type on / off and pulse

buttons.

MOTOR: 1.5 HP, 1725 RPM, direct-drive, fan-cooled.

WEIGHT: 40 lbs. net, 42 lbs. approximate shipping weight.

“The Inventor & World Leader in Food Processors”

OPTIONAL EQUIPMENT: 19 additional processing discs.

STANDARDS: ETL electrical & sanitation, cETL (Canada)

Slicing Discs

27051 - 1/32" (1mm)

27555 - 5/64" (2mm)

27086 - 1/8" (3mm)

27566 - 5/32" (4mm)

27087 - 3/16" (5mm)

27786 - 1/4" (6mm)

Ripple Cut Slicers

27621 - 5/64" (2mm)

Graters

27588 - 1/16" (1.5mm)

27577 -5/64" (2mm)

27511 - 1/8" (3mm)

27046 - 1/4" (6mm)

27632 - 11/32" (9mm)

27078 - Hard Cheese Grate

Pulping

27079 - Fine pulping disc

27764 - Pulping disc

Julienne

27599 - 5/64" (2x2mm)

27080 - 5/64" x 5/32" (2x4mm)

27081 - 5/64"x1/4" (2x6mm)

27047 - 5/32" (4x4mm)

27610 - 1/4" (6x6mm)

27048 - 5/16" (8x8mm)

Available Disc Selection

Cutter

Bowl Veg Prep

Commercial Food Processor

“Series D”

R301& R301U

Ref #10008 1/2007
