Ricoh RT3040 Quick start guide

LCIT RT3040

Machine Code: D3G1

Field Service Manual

Ver. 1.0

Latest Release: December, 2018

Initial Release: December, 2018

Symbols, Abbreviations and Trademarks

Symbols, Abbreviations

This manual uses several symbols and abbreviations. The meaning of those symbols and abbreviations

are as follows:

Symbol

What it means

Clip ring

Screw

Connector

Clamp

E-ring

Flat Flexible Cable

Timing Belt

SEF

Short Edge Feed

LEF

Long Edge Feed

Black

Cyan

Magenta

Yellow

B/W, BW

Black and White

Full color

[A] Short Edge Feed (SEF)

[B] Long Edge Feed (LEF)

Trademarks

Adobe, Acrobat, PageMaker, PostScript, and PostScript 3 are either registered trademarks or

trademarks of Adobe Systems Incorporated in the United States and/or other countries.

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any

use of such marks by Ricoh Company, Ltd. is under license.

Firefox and Thunderbird are registered trademarks of the Mozilla Foundation.

Dropbox is a registered trademark or trademark of Dropbox, Inc.

Google, Android, and Chrome are trademarks of Google Inc.

Java is a registered trademark of Oracle and/or its affiliates.

Macintosh, OS X, Bonjour, Safari, and TrueType are trademarks of Apple Inc., registered in the U.S.

and other countries.

Microsoft, Windows, Windows Server, Windows Vista, Internet Explorer, and Outlook are either

registered trademarks or trademarks of Microsoft Corp. in the United States and/or other countries.

PictBridge is a trademark.

QR Code is a registered trademark of DENSO WAVE INCORPORATED in Japan and in other

countries.

The SD and SD logo are trademarks of SD-3C, LLC.

UNIX is a registered trademark of The Open Group.

UPnP is a trademark of UPnP Implementers Corporation.

This product includes RSA BSAFE® Cryptographic software of EMC Corporation. RSA and BSAFE are

registered trademarks or trademarks of EMC Corporation in the United States and other countries.

The proper names of Internet Explorer 11 is as follows:

•Windows® Internet Explorer® 11

The proper names of the Windows operating systems are as follows:

•The product names of Windows Vista are as follows:

Microsoft® Windows Vista® Ultimate

Microsoft® Windows Vista® Business

Microsoft® Windows Vista® Home Premium

Microsoft® Windows Vista® Home Basic

Microsoft® Windows Vista® Enterprise

•The product names of Windows 7 are as follows:

Microsoft® Windows® 7 Home Premium

Microsoft® Windows® 7 Professional

Microsoft® Windows® 7 Ultimate

Microsoft® Windows® 7 Enterprise

•The product names of Windows 8 are as follows:

Microsoft® Windows® 8

Microsoft® Windows® 8 Pro

Microsoft® Windows® 8 Enterprise

•The product names of Windows 10 are as follows:

Microsoft® Windows® 10 Home Premium

Microsoft® Windows® 10 Pro

Microsoft® Windows® 10 Enterprise

Microsoft® Windows® 10 Education

•The product names of Windows Server 2003 are as follows:

Microsoft® Windows Server® 2003 Standard Edition

Microsoft® Windows Server® 2003 Enterprise Edition

•The product names of Windows Server 2003 R2 are as follows:

Microsoft® Windows Server® 2003 R2 Standard Edition

Microsoft® Windows Server® 2003 R2 Enterprise Edition

•The product names of Windows Server 2008 are as follows:

Microsoft® Windows Server® 2008 Standard

Microsoft® Windows Server® 2008 Enterprise

•The product names of Windows Server 2008 R2 are as follows:

Microsoft® Windows Server® 2008 R2 Standard

Microsoft® Windows Server® 2008 R2 Enterprise

•The product names of Windows Server 2012 are as follows:

Microsoft® Windows Server® 2012 Foundation

Microsoft® Windows Server® 2012 Essentials

Microsoft® Windows Server® 2012 Standard

•The product names of Windows Server 2012 R2 are as follows:

Microsoft® Windows Server® 2012 R2 Foundation

Microsoft® Windows Server® 2012 R2 Essentials

Microsoft® Windows Server® 2012 R2 Standard

•The product names of Windows Server 2016 R2 are as follows:

Microsoft® Windows Server® 2016 R2 Essentials

Microsoft® Windows Server® 2016 R2 Standard

Other product names used herein are for identification purposes only and might be trademarks of their

respective companies. We disclaim any and all rights to those marks.

Microsoft product screen shots reprinted with permission from Microsoft Corporation.


1
Table of Contents
1. Detailed Descriptions.......................................................................................................................... 2
Changes from the Previous Machine..................................................................................................... 2
Specifications.......................................................................................................................................... 3
Parts Layout............................................................................................................................................ 4
Mechanism ............................................................................................................................................. 6
Paper Feed Separating Mechanism................................................................................................... 6
Drive Mechanism................................................................................................................................ 7
Tray Lift/Descent Mechanism............................................................................................................. 7
Remaining Paper / Paper End Detection ........................................................................................... 9
2. Replacement and Adjustment .......................................................................................................... 10
Rear Cover ........................................................................................................................................... 10
Front Cover........................................................................................................................................... 12
Upper Cover ......................................................................................................................................... 13
Right Cover........................................................................................................................................... 14
Pick-up Roller, Feed Roller, Friction Roller.......................................................................................... 15
Paper Feed Motor (M2)........................................................................................................................ 17
Transport Motor (M1)............................................................................................................................ 18
Tray Lift Unit ......................................................................................................................................... 19
Controller Board (PCB1)....................................................................................................................... 20
Tray Set Switch (Front) (SW1)............................................................................................................. 21
Tray Set Switch (Rear) (SW2).............................................................................................................. 22
Paper Feed Sensor (S1), Paper End Sensor (S3), Upper Limit Sensor (S4), Transport Sensor (S2) 23



1.Detailed Descriptions

Changes from the Previous Machine

•Antistatic Control

Metal cover [A] for antistatic control has been added to the following sensors:

•Paper Feed Sensor

•Transport Sensor

•Paper End Sensor

When replacing the those sensors, this cover will also be used after replacement, so remove it from the

old sensors. When you do so, be careful not to deform or damage anything.

1: Paper Feed Sensor

2: Upper Limit Sensor

3: Paper End Sensor

4: Transport Sensor

•Dehumidification Heater

An optional dehumidification heater (attached to the side of the tray) is available.

1.Detailed Descriptions

Specifications

Item

Specifications

Paper size:

A4 LEF, B5 JIS LEF, 8 1/2 x 11 LEF

Paper weight:

52–300 g/m2 (14 lb. Bond–110 lb. Cover)

Paper capacity (80 g/m2, 20 lb. Bond):

1,500 sheets

Power consumption:

13 W (Power is supplied from the main unit.)

Dimensions (W x D x H):

340 × 544.5 × 290 mm (13.4 × 21.4 × 11.5 inches)

Weight:

Approx. 11 kg (24.3 lb.)

1.Detailed Descriptions

Parts Layout

No.

Description

No.

Description

Friction roller

Feed roller

Transport sensor (S2)

Paper end sensor (S3)

Transport roller

Pickup roller

Paper feed sensor (S1)

Remaining paper sensor (S6) (inside lift unit)

Upper limit sensor (S4)

Lower limit sensor (S5)

No.

Description

No.

Description

Tray set switch (front) (SW1)

Paper feed motor (M2)

Paper feed sensor (S1)

Remaining paper sensor (S6) (inside lift unit)

Upper limit sensor (S4)

Tray lift motor (M3) (inside tray lift unit)

Transport sensor (S2)

Interlock switch 1 (SW3)

Pick-up roller solenoid (SOL1)

Interlock switch 2 (SW4)
