Renault Kadjar User manual

QUICK GUIDE

KADJAR

WELCOME ABOARD YOUR VEHICLE

Note

Thank you for choosing us. With an interior combining refinement and sportiness, a design that is both fluid and muscular, you have chosen a Crossover with char-

acter. As you will see, Renault has employed all its expertise to provide you with a quality product that you cannot resist taking out on the road at every opportunity.

In order to make your experience as pleasant as possible, we suggest you discover the main features of your new vehicle by reading this document.

Detailed information regarding your vehicle’s use, maintenance and warranty, as well as videos and simulators,

are all only a click away in the e-Guide, accessible from the website www.e-guide.renault.com.

Translated from French. Copying or translation, in part or in full, is forbidden unless prior written permission has been obtained from the vehicle manufacturer.

This document does not replace the driver’s handbook.

Please read the complete driver’s handbook for more detailed information on the equipment mentioned in the reference guide for your vehicle.

The reference guide covers all items of equipment (both standard and optional) available for these models, but whether or not these are fitted to the vehicle depends

on the version, the options selected and the country where the vehicle is sold.

Front and engine compartment

Front passenger side

Rear seats

Rear

Accessing the vehicle

Driving position: adjustment

Starting/stopping the engine

Dashboard

Instrument panel

Lighting/Wipers

Air conditioning

Driving

Stop and Start Function

Driving: advice for Eco-driving

FRONT AND ENGINE COMPARTMENT

Engine oil level

To check the oil level, use the dipstick 8.

The level indicated on the dipstick 8should be be-

tween MINI Aand MAXI B. If the oil level is at

minimum, the message “Adjust oil level” is dis-

played on the instrument panel. Unscrew the cap 7

to adjust the level.

You must observe the service intervals and the

standards governing the oils tested for your

engine. Refer to the maintenance document for the

vehicle, and to Section 4 of the vehicle handbook

for the precautions to take when filling with oil.

Coolant level

The level should be read with the engine switched

off and on level ground. The level indicated on the

reservoir 6should be between the MINI and MAXI

marks.

If it is necessary to top up this level, it is essential

to do so when the engine is cold.

Screen washer fluid level

Add some fluid to the reservoir 9if necessary. To

check the level, please refer to Section 4 of your

drivers handbook.

Opening the bonnet

To open, pull the release switch 1, raise the bonnet

slightly and lift the paddle 4. Lift the bonnet.

Position the stay 3in its housing 2.

Closing the bonnet

Check that nothing has been left in the engine

compartment. Position the stay 3in its housing 5.

Take hold of the bonnet, guide it down to about

30 cm from its position when closed, and then let

it drop. It will latch automatically under its own

weight. Check that it is locked.

FRONT PASSENGER SIDE

Deactivating the front

passenger air bag

If you wish to fit a rear-facing child seat on the

front passenger seat, you must deactivate the

airbag: with the engine switched off, push and turn

the lock 1to the OFF position.

With the ignition on, the warning light

the display 2comes on.

Reset the lock to ON as soon as you are no

longer using the child seat.

Activation of the front

passenger air bag

You should reactivate the air bag as soon as you

remove the child seat from the front passenger seat

to ensure the protection of the front passenger in

the event of an impact.

To reactivate the airbag: when the vehicle is sta-

tionary, push and turn lock 1to the ON position.

With the ignition on, it is essential to check that the

warning light

is off and that the warning

light



comes on on the display 2for about

one minute after each start-up.

Front passenger seat

table position

Depending on the vehicle, the passenger seatback

may be folded down onto the seat base to create

a table.

– Lower the headrest;

– move the seat back;

– pull the handle 3and fully lower the seatback.

When using the passenger seat in table position,

you must not use the two rear seats immediately

behind it.

Folding down the rear

bench seatback

Ensure that the front seats are far enough forward.

Pull the handle 1and lower the seatback A.

To return the seatback to its initial position, check

that the seat belts are in the correct position and

lift the seatback. Check that it is correctly locked.

REAR SEATS

Check that the seats are correctly locked when

put back in position.

Child safety

To make it impossible for the rear doors to be

opened from the inside, move the lever 2on each

door and check from the inside that the doors are

securely locked.

Refer to Section 1 of the driver’s handbook.

ISOFIX system

Each rear side seat is fitted with the ISOFIX child

seat mounting system.

The two rings 3are located between the seatback

and the seat base of the seat and are identified by

a marking on the seatback. To access the rings,

remove the blanking covers.

To ensure your child seat can be easily fitted and

locked on the rings 3, use the access guides 4on

the child seat.

Consult your RENAULT Dealer to find out about the

equipment available for your vehicle.

Refer to Section 1 of your driver’s handbook.

Fuel tank

Your vehicle is fitted with a flap and a cap.

– To open the cover, pull the control 1

open the cover 3and unscrew the cap 2;

– If, while driving, the low-fuel warning light

appears, fill up with fuel as soon as

possible.

– When the warning light comes on, you have ap-

proximately 30 miles (50 km) left if you drive at

moderate speed.

REAR (1/2)

2 3

Depending on the vehicle, the fuel tank’s capac-

ity varies between approximately 55 and 65 litres.

Rear seats

FOLDING THE REAR BENCH SEAT

The rear bench seat is automatically unlocked to be

folded down to get a flat floor.

Make sure the front seats are far enough forward.

Pull the control 4to fold down the rear bench seat-

back.

For more information, please refer to Section 3 of

your driver’s handbook.

REAR (2/2)

Mobile floor

If fitted on the vehicle, this is made up of two in-

dependent and interchangeable parts. The smooth

side is easy to clean.

The mobile floor 5enables:

– a flat floor;

– a larger boot volume;

– separate boot compartments.

Please refer to the information on “Boot storage”

in Section 3 of your driver’s handbook to arrange

the mobile floor.

Tyre inflation kit/

Emergency spare wheel

Depending on the vehicle, in the event of a punc-

ture, there is either a tyre inflation kit 6or emer-

gency spare wheel available.

To access it, lift the mobile floor, then the boot

carpet.

Tools

The tool kit is located in the tray under the boot

carpet.

Depending on the vehicle, the toolbox contains:

– wheelbrace;

– jack;

– hubcap tool;

– tow eye;

– tow eye locking lever;

– bag containing the wheel bolt;

– storage bag for punctured wheel.

Using the inflation kit is a complex operation.

Please refer to Section 5 of your driver’s hand-

book.

ACCESSING THE VEHICLE

With the RENAULT card on you (even left in your

pocket, bag, etc.) you can:

– automatic unlocking by pressing on the locking/

unlocking button on one of the front door han-

dles or the boot;

– automatic locking by pressing on the locking/un-

locking button on one of the front doors or the

boot.

Note: If required, you can use the manual mode

or built-in key. To gain access to the built-in key,

please see Section 1 of the driver’s handbook.

RENAULT Card version

The RENAULT Card system replaces the traditional

key. Locking/unlocking the vehicle is simple: as

long as it is nearby, a single press on the handle

button of either front door is enough.

For special notes relating to this system, refer to

Section 1 of your driver’s handbook.

SPECIAL FEATURES

The detection zone of the card, necessary for lock-

ing and unlocking the vehicle, depends on the sur-

rounding environment or location of the card.

RENAULT Card/remote

control key

Press:

‡

to unlock;

…

to lock;

to switch on/off the dipped beam headlights,

the side indicator lights and the interior lighting re-

motely (in order to make out your vehicle in a car

park, for example);

†

to lock/unlock the tailgate compartment only.

NOTE

– Two flashes of the direction indicator lights con-

firm locking;

– one flash of the direction indicator lights con-

firms unlocking.

SPECIAL NOTE

…

For vehicles equipped with deadlocking,

pressing this button twice in succession prevents

the doors from being unlocked, even from the

inside.

Never leave the RENAULT Card in the vehicle or

near to any electrical equipment (computers,

telephones, etc.) which could affect its opera-

tion.

DRIVING POSITION: SETTINGS (1/2)

Adjusting lumbar support

Raise or lower lever 6.

Front seat heating

Providing the ignition is on, pressing the switch 7

on the desired seat will activate the system. The

switch warning lights come on. The system regu-

lates the heating and deactivates it if necessary.

Pressing the button again lowers the temperature.

Pressing a third time switches the heating off.

Manually controlled seats

MOVING THE SEAT FORWARDS OR BACKWARDS

Lift handle 1. At the desired position, let go of the

handle again. Ensure it is correctly locked in place.

RAISING OR LOWERING THE SEAT

Move the lever 2as many times as required.

TILTING THE SEATBACK

Lift handle 3and tilt the seatback to the desired

position.

Electrically controlled

seats

PULLING FORWARD/BACKWARD AND RAISING/

LOWERING THE SEAT

Use the switch 4.

TILTING THE SEATBACK

Move the top of switch 5forwards or backwards.

Carry out these adjustments when the vehicle

is stationary.
