QuickWorldWide Little Sweetie 10 Pro Quick guide
Page 1 of 69
Page 2 of 69
TABLE OF CONTENTS
INTRODUCTION 3
CUSTOMER SERVICE 4
FEATURES 5
FRE-ASSEMBLY INFORMATION 6
REQUIRED TOOLS 7
HARDWARE & OPTIONAL ACCESSORIES 8
OTHER HARDWARE & OPTIONAL ACCESSORIES 9
OTHER REQUIREMENTS 11
PART LIST 12
SECTION 1: REAR FRAMES 13
SECTION 2: MAIN FRAMES 17
SECTION 3: TAIL ASSMEBLY 32
SECTION 4: CONTROL SYSTEM 39
SECTION 5-A: ROTOR HEAD FOR LITTLE SWEETIE 10 42
SECTION 5-B: ROTOR HEAD FOR SWEET 16V2 47
SECTION 6: LINKAGES 50
SECTION 7: SETTINGS 56
FRE-LIGHT CHECKS 63
WARNINGS 63
ADJUSTMENTS 64
HOW TO HOVER 65
HOW TO FLY FORWARD 67
AFTER FLIGHT CHECKS 69
WHAT IF THE HELICOPTER CRASHED 69
SPECIFICTION 69
Page 3 of 69
INTRODUCTION
Congratulation and thank you for purchasing this great product! It is our sole desire for you
to enjoy the quality workmanship and performance of any of our electric Li-Po powered
helicopters. We believe we have the latest designs and technology incorporated into our
model helicopters. Our CNC parts are produced using the best high density materials &
anodized using material hardening finishes with the tightest of tolerances. Our new
helicopters feature the latest advances in R/C helicopter design. The simple and
mechanically superior EMS design (also known as CCPM) ensures a helicopter that will be
more responsive and more stable than any other R/C helicopter you have ever flown. Three
servos are attached directly to the Swashplate to ensure precise control. This kit features all
metal construction, and a carbon or composite frames are standard. Along with great
products, our staffs are RC people that fly and have hands on experience with total
manufacturing & testing of our helicopters. In addition, we stand behind all our products
100% with satisfaction guaranteed.
For the past several years, we have been devoting ourselves to developing electric powered
helicopters. We feel that our electrics now are more powerful, smoother, and more
responsive than most of the nitro machines in the market. In addition, there is less time for
maintenance and no longer getting dirty from oil and gas. With new technology of batteries
and electric motors, the flying time and the efficiency increase significantly day by day. We
believe so much in our electric helicopters that we have given out for reviews to our fellow
hobbyists EP kits of four different motors and Li-Po battery classes. Electric powered
helicopters are here now to stay and will in time be bigger than the current nitro market. The
market has some very mixed ideas about electric and their safety. Our staff is here to
answer all of your technical questions. Our kits will be shipped 100% complete and we can
assure you that once you fly your EP helicopter you will love it.
The Little Sweetie 10 / Sweet 16V2
We believe you hold in your hands one of the best helicopters manufactured in the world
today. The brand new Little Sweetie 10 & Sweet 16V2 are the newest
designs of our Quick line. These babies carry the power and punch of the Q30 delivered
smoothly throughout the entire range of their electric motor. The Little Sweetie 10
& Sweet 16V2 Pro version feature a fully machined head, metal grips,
carbon fiber frames, and carbon fiber boom supports. The Little Sweetie 10 &
Sweet 16V2 Sport version features a G10 fiberglass frame, and molded
main blade grips and tail blade grips. Our helicopters are carefully designed and tested, and
manufactured of the highest quality materials available.
In a short time, you can be flying.
We ask that you please read the entire manual before starting the construction of the
Little Sweetie 10 & Sweet 16V2, and if you have any questions our
technical support staff can be reached at
(610) 282-4811 M-F 9-6, S 9-4 Eastern time,
For the latest information and updates, please visit our website at
www.quickworldwide.com
CUSTOMER SERVICE
Quickworldwide
201 South 3rd. St. & 309 N.
Coopersburg, PA 18036
Phone: (610)-282-4811
Fax: (610)-282-4816
Websites:
http://www.hhiheli.com
http://www.quickheli.com
http://www.giantscaleplanes.com
E-mail: [email protected]
Office Hours: Mon – Fri: 8:30 – 6:00
Sat: 8:30 – 1:30
(Eastern Daylight Time)
Technical Support Personnel:
Page 4 of 69
Page 5 of 69
FEATURES
Little Sweetie 10 & Sweet 16V2
1. Frame Construction: Little Sweetie 10 / Sweet 16v2 frames are made of the
highest quality Carbon Fiber or Black G-10. These frames are not only rigid but will
provide excellent vibration absorption.
2. Belt driven Tail: Smooth, reliable, and low maintenance.
3. High Quality Ball Bearings: Little Sweetie 10 / Sweet 16v2 offer ball
bearings on all moving parts.
4. EMS Collective System:The EMS Collective design allows ease of setup
with fewer moving parts. EMS demonstrates overall design simplicity and represents the
future of helicopter technology.
5. Control Linkages: The control linkages provided with the Quick Learner Kit
are high quality 2.3mm stainless steel rods with Delrin® acetal resin rod ends.
6. Single Blade Axle Design: simple, very responsive, with exceptionally
consistent flight characteristics.
7. Advanced Airfoil Fly-bar Paddles: These paddles will provide the best
flight characteristics for both 3D & Sport flying: Smooth forward flight, with quick
response upon demand.
8. Low Cost: Little Sweetie 10 / Sweet 16v2 have low cost replacement parts.
Page 6 of 69
PRE-ASSEMBLY INFORMATION
Warning
The radio-controlled model helicopter contained in this kit is not a toy.
Rather, it is a sophisticated piece of equipment. This product is not recommended for
use by children without adult supervision. Radio controlled models such as this are
capable of causing both property damage and/or bodily harm to both the
operator/assembler and spectators if not properly assembled and operated. Hobbies &
Helis International assumes no liability for damage that could occur from the mis-
assembly and/or use/misuse of this product.
Academy of Model Aeronautics
We strongly encourage all prospective and current R/C aircraft pilots to join the
Academy of Model Aeronautics. The AMA is a non-profit organization that provides
services to model aircraft pilots. As an AMA member, you will receive a monthly
magazine entitled Model Aviation, as well as a liability insurance plan to cover against
possible accident or injury. All AMA charter aircraft clubs require individuals to hold a
current AMA sporting license prior to the operation of their model. For further information,
please contact AMA at:
Academy of Model Aeronautics
5161 East Memorial Drive
Muncie, IN 47302-9252
USA
Phone: (317) 287-1256
www.modelaircraft.org
Before you begin
Quick Helicopter kits are packaged with care and attention to detail. We recommend
when you are ready to begin building this model that you examine the kit carefully,
inspect the contents of each package, and read and understand these instructions
thoroughly before starting assembly. It is suggested that you purchase a parts box for
the small fasteners and hardware, or use small bowls or other containers.
Page 7 of 69
REQUIRED TOOLS
Dremel Tools and Sandpapers would be helpful for building.
HARDWARE & OPTIONAL ACCESSORIES
GLUES AND THREAD LOCK COMPOUNDS
RADIO MOUNTING ACCESSORIES
Page 8 of 69
OTHER HARDWARE & OPTIONAL ACCESSORIES
3MM FLYBAR STIFFENERS
HHI 402
30 SIZE SKID STOPS
HHI 200 AVAILABLE IN COLORS
SERVO ARM SET
LANDING GEAR DAMPENERS
HHI 2004
BASE LOAD ANTENNA
HHI 53**
AVAILABLE IN BLUE, GOLD,
PURPLE
AND IN 40, 50, AND 72 MHz
Page 9 of 69
FINISHING CAPS
•Adds color and style
•Distributes force across larger surface area
3mm 4mm
(20 pcs in a package) (8 pcs in a package)
BLACK HHIM11100B ---
W
ITHOUT BLUE HHIM11103 HHIM11108
GOLD HHIM11101 HHIM11106
GREEN HHIM11100G ---
PURPLE HHIM11100 HHIM11105
W
ITH RED HHIM11100R ---
SILVER HHIM11100 HHIM11107
Page 10 of 69
