QOLSYS IQ Siren User manual

IQ SIREN QUICK INSTALL GUIDE

Built-in Lithium Battery: 430 mAh

Alarm Power: 1.7W

Max Standby Power: 0.7W

Max Volume: 105dB

Operating Temperature: 0°C to 40°C

Operating Distance: Up to 550 feet outdoors

Frequency Type : Z-Wave Plus

SPECIFICATIONS

The IQ Siren is a wireless Z-Wave device that allows you to have additional sirens

placed throughout the home.

It plugs into any standard outlet, acts as a repeater in the Z-Wave network, has a

rechargeable back up battery and three LED lights that strobe when the siren is

triggered.

Mounting Locations:

•Kitchen

•Living Room

•Basement

•Bedrooms

•Garage

Pair up to 3 IQ Sirens with the IQ Panel.

FEATURES & OVERVIEW

This is a quick guide for experienced installers only. Refer to http://dealers.qolsys.com (login required)

STEP

DETERMINE

INSTALLATION

LOCATION

PREPARE THE IQ PANEL TO

ENROLL THE IQ SIREN

STEP

PAIRING WITH

THE IQ PANEL

✓

Test device to ensure

proper function

Document#: IQSIREN-QG-03-17

Revision#: 03/27/17

Issue Date: MAR 2017

Qolsys Product #: QZ2300-840

Press the button on

the bottom of the IQ

Siren once to enroll

with the IQ Panel.

(LED will flash)

STEP

Plug in the IQ Siren

at desired location

Customize name

Complete pairing process

by touching Add

Place your panel in

“autolearn" mode

Tech[email protected]om

Qolsys Inc. proprietary.

Reproduction without permission is not permitted.

FCC ID: XBAZW080

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired

operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference

that may cause undesired operation of the device.

Cet appareil est conforme avec Industrie Canada exempts de licence standard RSS (s). Son fonctionnement est soumis aux deux conditions suivantes: (1) cet appareil ne doit pas provoquer d'interférences et (2) cet appareil doit accepter toute

interférence, y compris celles pouvant causer un mauvais fonctionnement de l'appareil.

CONTACT TECH SUPPORT

GOT QUESTIONS?
