Pyle PLVWR84IR User manual
WARNING:
DO NOTWATCH MONITORWHILE
VEHICLE INMOTION ITCAN
BE HAZARDOUS
Instruction Manual
PLVWR84IR
YOU'RE NOWREADY FORMORE FUN ONTHE ROADTHAN EVERBEFORE
WWW.PYLEAUDIO.COM
Brightness
Contrast
Color
Volume AV
U/D
L/R
MD
TFT-LCD
MONITOR REMOTE
Power on/off
Mode
Left/right
Up/dowm
Video1/video2
Mute
¡À
¡À
¡À
¡À
Contents and specificationscan be subjectedto change withoutprior notice.
Remote control
Cautions
Never connectthe caradaptor tocigarette lightersfor suchas
trucks orbuses whichuse 24VDCpower.
Do notexpose themonitor tohigh humidity, dust, steam,
oily smoke,direct sunlightetc.
For yoursafety ,turnpower OFFwhen notin useand unplug
the adaptor.
Never attemptyour ownmaintenance .Consultyour TV
dealer orth ecompany.
Avoid droppingand strongimpact.
For yoursafely ,thedriver shouldnot watchthe TVor
operate thecontrols whiledriving .
Accessories
1x Remotecontrol
1x insturctionmanual 1x Metal Bracket
1
3
4
562
Pannel
1.VOL-
2.MENU
3.VOL+
4.POWER
5.LAMP
6.OPEN
FEATURES:
8.4 ROOFMOUNT TFTLCD MONITOR
BUILT-IN IRTRANSMITTER
OSD ONSCREEN DISPLAY
REMOTE CONTROL
RESOLUTION:1440X234
POWER SUPPLY:DC11V-14V
SYSTEM:PAL/NTSC
DIMENSION:8.5 X8.1 X1.2(INCH)
