Proficient Audio Systems Kevlar CC550 System manual

To get sound that blows your mind — with power and impact

to match the moving image – you need midrange voicing that’s

precisely articulated.

Proficient Audio has designed a flagship center channel speaker

with Kevlar drivers that delivers lifelike sound. And, when you’re

sitting off-axis – out of the “sweet spot” listening area — the

CC550 provides ultra-wide horizontal dispersion for superior

tracking with your video screen.

The CC550 is truly a high-end system and features two 5¼"

Kevlar woofers that deliver tight, low-end bass. Our twin 2" bass

ports help to deliver deeper bass while reducing vent noise and

distortion. And with a 3" Kevlar midrange driver, dialog is clear

and precise. To top it off, the 1" aluminum dome tweeter gives you

smooth, flat response on the high-end of the frequency range. All

of this — optimized within a low-resonance cabinet.

If you are looking for really tight, realistic bass, the CC540 is

the ticket. It features dual graphite woofers, a graphite mid and

aluminum tweeter. If you are looking for a low profile center

channel speaker, the CC400 is the one, with dual 4" polypropylene

woofers and a 1" aluminum tweeter.

That’s quality you can trust. Just what you would expect from Proficient.

Get Centered

CC400

Dual 4" Poly

CC540

Dual 5¼" Graphite

CC550

Dual 5¼" Kevlar®

proficientaudio.com

Proficient Center Channel Specs

CC550 CC540

Description 5¼" Kevlar Bookshelf Center Channel 5¼" Graphite Bookshelf Center Channel

Woofers Two 5¼" Kevlar Cones Two 5¼" Graphite Cones

Midrange 3" Kevlar Cone 3" Graphite Cone

Tweeter 1" Aluminum Dome 1" Aluminum Dome

Power Handling 125 Watts 100 Watts

Frequency Response 40Hz-20kHz 70Hz-20kHz

Impedance 8Ω 8Ω

Sensitivity 88dB 1W/1m 89dB 1W/1m

Dimensions (H x W x D) 6¾" x 20½" x 8¾" 6¾" x 20½" x 8¾"

Warranty 10-Year Limited 10-Year Limited

PAS00019 (rev2)

940 columbia avenue • riverside, california 92507 • 877.888.9004 • Fax 951.787.8747 • proficientaudio.com

CC400

Description 4" Polypropylene Bookshelf Center Channel

Woofers Two 4" Polypropylene Cones

Tweeter 1" Aluminum Dome

Power Handling 85 Watts

Frequency Response 80Hz-20kHz

Impedance 8Ω

Sensitivity 89dB 1W/1m

Dimensions (H x W x D) 5½" x 20" x 7¼"

Warranty 10-Year Limited
