Pro Breeze PB-AC05 User manual

Instruction manual

Model PB-AC05

12000 BTU Portable Air Conditioner

Portable Air Conditioner

Safety Warning

Contents Pg

Specific Information

Regarding R290

Refrigerant Gas

Caution

Specifications

Parts

Front View

Rear View

Accessories

Control Panel

1. Buttons moving from left to right

•

2. Indicator light symbols moving from

top to bottom and left to right

•

3. Digital display panel moving from top

to bottom

•

Remote Control

Note:

Installation

Prior to and after installation adhere to

the below:

•

Leave the appliance in an upright

position for at least two hours prior

to first use.

Heat Exhaust Hose Installation

Sliding Window Sealing Board Assembly

Installation

Notes:

•

Hinged Window Sealing Fabric

Assembly Installation

1. Open window and clean frame and

casement surfaces of dust and

particles.

2. Stick the velcro tape around the

entire window frame. Never stick

to the window seal as doing so will

prohibit the window from closing fully.

3. Stick the velcro tape around the

entire window casement (inside or

outside). Check to ensure the window

can close fully.

4. Attach side A of the sealing fabric

assembly to the velcro on the window

frame working from the centre

outwards.

5. Close and open window to ensure no

fabric gets trapped.

6. Attach side B of the sealing fabric

assembly to the velcro on the window

casement working from the centre

outwards.

7. Open the window slightly and

insert the heat exhaust hose short

connector into the sealing fabric

assembly securing with the zippers

around its lip.

8. The sealing fabric assembly is now

ready for use.

Notes:

• Do not bend the heat exhaust hose in

excess of 45 degrees. It should be as

short and as straight as possible to

• Do not overstretch the heat

exhaust hose as this may affect the

Frame

Side A

Side B

Casement

4 & 6

2 &3

Hinged window sealing fabric zip

Controls

Control Panel

Power Button

Mode Button

• Cooling Mode

• Fan-Only Mode

• Dehumidifying Mode

• Heating Mode

Note:

Fan Speed Button

Note:
