Printronix T5000 Series User manual

IPDS™Emulation for SL5000/T5000 series Printers

Programmer’s Reference Manual

IPDS™Emulation for SL5000/T5000 series Printers

Programmer’s Reference Manual

Trademark Acknowledgements

Advanced Function Printing is a trademark of International Business

Machines Corporation.

AIX, AS400, and OS/2 are registered trademarks of International Business

Machines Corporation.

ANSI is a registered trademark of American National Standards Institute, Inc.

Bar Code Object Content Architecture and BCOCA are trademarks of

International Business Machines Corporation.

IBM is a registered trademark of International Business Machines

Corporation.

Intelligent Printer Data Stream and IPDS are trademarks of International

Business Machines Corporation.

LinePrinter Plus is a registered trademark of Printronix, Inc.

Printronix is a registered trademark of Printronix, Inc.

PSA is a registered trademark of Printronix, Inc.

Printronix, Inc. makes no representations or warranties of any kind regarding

this material, including, but not limited to, implied warranties of

merchantability and fitness for a particular purpose. Printronix, Inc. shall not

be held responsible for errors contained herein or any omissions from this

material or for any damages, whether direct, indirect, incidental or

consequential, in connection with the furnishing, distribution, performance or

use of this material. The information in this manual is subject to change

without notice.

This document contains proprietary information protected by copyright. No

part of this document may be reproduced, copied, translated or incorporated

in any other material in any form or by any means, whether manual, graphic,

electronic, mechanical or otherwise, without the prior written consent of

Printronix, Inc.

Table of Contents

1 Introduction ............................................................. 7

About This Guide ...................................................................................... 7

Sources of Useful IBM Information..................................................... 7

Compatible System Attachments..............................................................8

Defining IPDS ...........................................................................................8

The Protocol....................................................................................... 8

The Printer Environment .................................................................... 8

Emulations and Data Streams............................................................8

2 Configuring with IPDS Commands ......................... 9

Overview................................................................................................... 9

The IPDS Emulation ................................................................................. 9

The Command Sets ........................................................................... 9

The Data Towers..............................................................................10

The States ........................................................................................10

Processing a Page ...........................................................................11

The Command Syntax .....................................................................12

The Text Commands........................................................................13

Load Equivalence (LE) ..............................................................13

Write Text (WT) .........................................................................13

Scalable Fonts .................................................................................15

XOA – Request Resource List (RRL) Reply .............................. 15

Font Selection............................................................................15

Images .............................................................................................16

The IM Image Command Set ...........................................................16

Write Image Control (WIC) ........................................................16

Write Image (WI)........................................................................17

Graphics ...........................................................................................17

The Graphics Command Set............................................................18

Write Graphics Control (WGC) ..................................................18

Write Graphics (WG) .................................................................18

Bar Codes ........................................................................................18

The Bar Code Command Set ...........................................................19

Write Bar Code Control (WBCC) ...............................................19

Write Bar Code (WBC) ..............................................................19

Table of Contents

The Page Segment Command Set ..................................................20

Begin Page Segment (BPS) ...................................................... 20

Delete Page Segment (DPS).....................................................20

Include Page Segment (IPS) ..................................................... 20

The Overlay Command Set..............................................................21

Begin Overlay (BO)....................................................................21

Delete Overlay (DO) ..................................................................21

Include Overlay (IO)...................................................................21

The Device Control Commands .......................................................21

Begin Page (BP) ........................................................................ 21

End ............................................................................................ 21

End Page (EP)........................................................................... 22

Load Copy Control (LCC) .......................................................... 22

Load Font Equivalence (LFE) ....................................................22

Load Page Descriptor (LPD)......................................................22

Load Page Position (LPP) .........................................................22

No Operation (NOP) ..................................................................22

Sense Type and Model (STM)...................................................22

Sense Type and Model Acknowledge Reply ............................. 23

Set Home State (SHS)...............................................................27

Execute Order Anystate (XOA)..................................................27

Execute Order Home State (XOH) ............................................ 28

XOH Obtain Printer Characteristics ........................................... 29

Exception Processing and IDs ......................................................... 34

A Fonts and Code Pages ......................................... 43

B IPDS Exception Reporting .................................... 47

Command Reject — X'80' ................................................................ 48

Intervention Required — X'40' .........................................................48

Equipment Check — X'10' ...............................................................49

Data Check — X'08' ......................................................................... 49

Specification Check-Bar Code — X'04' ............................................ 50

Specification Check-Graphics — X'03'............................................. 55

Specification Check-General — X'02' .............................................. 60

Conditions Requiring Host Notification — X'01' ...............................76

C Glossary ................................................................ 77

1Introduction

About This Guide

This manual contains the IPDS* configuration menu, lists the command sets

and provides error messages.

This manual assumes you are familiar with IPDS and programming in IPDS.

This book is not a tutorial, it does not explain how to program nor does it

describe which applications support which commands. For detailed

information, refer to the list below.

Sources of Useful IBM Information

•

IBM* Intelligent Printer Data Stream* Reference

•

IBM System/36 Concepts and Programmer's Guide

•

IBM System/38 Guide to Program Product Installation and Device

Configuration

•

Forms Design Reference Guide for Printers

•

IBM 9370 Information System: Customizing the Work Station Subsystem

•

IBM 9370 Information System: Work Station Subsystem and Reference

•

IBM AS/400* Programming: Data Management Guide

•

4234 Printer Models 007, 008, 011, and 012 Product and Programming

Description

•

Guide to Programming for Printing, Version 2

Chapter 1 Compatible System Attachments

Compatible System Attachments

With a twinax interface, you can attach your IPDS-compatible printer to the

following systems:

•System/36 (SSP 5.1 plus IPDS PRPQ P84094)

•System/38 (with Rel. 8 System/38 Control Program Facility)

•AS/400 processor

•5294/5394/5494 control units

(The coax IPDS emulation is currently not used.)

IPDS characteristics available on each of the above attachments are not

completely uniform, but the emulation printers are as fully functional on these

attachment as provided by the host vendor.

Defining IPDS

IPDS is both a protocol and a printer mode. The two terms do

not

mean the

same thing.

The Protocol

A protocol is a set of rules governing the exchange of information between the

printer and the host computer. The rules are codes that manipulate and print

data and allow for machine-to-machine communication. A printer and the host

computer must use the same protocol.

IPDS is the protocol for your printer. Refer to your IBM documentation for

details about commands, etc.

The printer uses EBCDIC character codes to print text, numbers, and

punctuation. Some EBCDIC characters, singly and in groups, are used as

control codes. Control codes instruct the printer to perform specific functions.

The Printer Environment

The printer operates under “IPDS” (text and graphics) mode. In the IPDS

mode, the data stream has special sequences to denote IPDS commands.

Emulations and Data Streams

Your IPDS printer emulates only IBM 3816 or 4028 and scalable AGFA fonts.

Twinax printers always use IPDS data streams for sending commands. Even

a simple job, such as a screen print, is IPDS data in a twinax attachment.

Because the printer definition on a twinax host is either set automatically (by

auto configuration) or manually, the printer type is already known.

NOTE: Sending a non-IPDS data stream to an IPDS printer and vise versa

will result in a hung spool file or writer.

2Configuring with IPDS

Commands

Overview

This chapter summarizes IPDS, lists control codes, and lists error messages.

For detailed information, refer to “Sources of Useful IBM Information” on

page 7.

The IPDS Emulation

IPDS consists of the following command sets, which are defined in more

detail beginning on page 13.

The Command Sets

Text This set contains the commands used to present text

information on a page, on a page segment, or on an

overlay.

IM Image The commands for this functional area output raster

image data on a page, a page segment, or on an overlay.

IO Image Not available for impact IPDS printers.

Graphics To present vector graphics on a page, a page segment or

on an overlay, use the commands in this set.

Bar Code This set contains the commands and data controls

needed to produce bar codes.

Page Segment The commands used to store and present page

segments that contain text, graphics, image, and bar

code information.

Overlay The commands used to store and present overlays that

contain text, graphics, image, and bar code information.

Device Control This set contains commands that let you set up a page

and manage printer-host communication.

Chapter 2 The IPDS Emulation

The Data Towers

Most of the IPDS commands contain data fields. The type of data is

categorized into the following data towers:

Text The Presentation Text Object Content Architecture

(PTOCA) commands are a part of the text data tower.

This information is necessary to print text in a page, a

page segment, or an overlay.

IM Image The image data enables the printer to print images in a

page, a page segment, or an overlay.

IO Image This is not supported.

Graphics The Graphic Object Content Architecture (GOCA)

commands are a part of the graphics data tower. This

information is necessary to print images in a page, a

page segment, or an overlay.

Bar Code The Bar Code Object Content Architecture* (BCOCA*)

commands are a part of the bar code data tower. This

information is necessary to print bar codes in a page, a

page segment, or an overlay.

Some of the data towers contain only one level of commands; some contain

two.

PTOCA, GOCA, and BCOCA are described in more detail in the IBM

documentation.

The States

IPDS-capable printers are known as “state machines.” As the printer

recognizes a specific command, it operates in the state identified with that

command. Figure 1 shows the transition of the different states.

Home State The initial operating state. The printer returns to this state

after a page, an overlay, or a page segment has been

sent.

Block States The printer establishes the processing conditions for a

data block to be accepted. There are three block states:

IM image, graphics, and bar code.

Page State While printing a logical page, the printer is in the Page

State.

Overlay State This state permits overlay data blocks to be stored. An

overlay is a block of data that is frequently accessed. It

can be a block of text, images, graphics, or bar codes. An

overlay can be a predefined page or part of a page and is

often used for forms.

Other manuals for T5000 Series

This manual suits for next models

Table of contents

Other Printronix Printer manuals

Printronix

Printronix MVP Series User manual

Printronix

Printronix MVP 150 User manual

Printronix

Printronix T8000 Use and care manual

Printronix

Printronix P7000 H-Series Operating manual

Printronix

Printronix P5000 Series Service manual

Printronix

Printronix P5000 Series Service manual

Printronix

Printronix L1024 User manual

Printronix

Printronix L5520 Quick reference guide

Printronix

Printronix P5005B User manual

Printronix

Printronix ProLine 5 Series User manual

Printronix

Printronix P6000 series User manual

Printronix

Printronix T6000 Use and care manual

Printronix

Printronix P5000 Series User manual

Printronix

Printronix SMARTLINE SL4M User manual

Printronix

Printronix P4280-CT User manual

Printronix

Printronix SL5000E series User manual

Printronix

Printronix N7000 H-Series User manual

Printronix

Printronix T2N series User manual

Printronix

Printronix L5520 Manual

Printronix

Printronix P5000LJ Series User manual

Printronix

Printronix P9212 User manual

Printronix

Printronix T5000R Series User manual

Printronix

Printronix T5000e series User manual

Printronix

Printronix SMARTLINE SL4M User manual

Popular Printer manuals by other brands

Lexmark

Lexmark 1400 Series Manual

Canon

Canon i70 Series quick start guide

Evolis

Evolis Elypso user guide

Kyocera

Kyocera FS-9530DN specification

Canon

Canon LASER SHOT LBP-1210 Specifications

Samsung

Samsung BIXOLON SRP-350plusF user manual

Canon

Canon PIXMA PRO-1 Series Getting started

Canon

Canon PIXMA G3560 Online manual

Dell

Dell Color Laser Printer 2130cn user guide

Tektronix

Tektronix Phaser 840 user guide

Epson

Epson ET-7750 Programming guide

Canon

Canon CLBR 460ps Service manual

Eltron

Eltron P210 Guide manual

Ricoh

Ricoh MD-P1 Service manual

Epson

Epson SC-F7100 series user guide

Epson

Epson Stylus C40UX Service manual

Canon

Canon imagePASS-A2 Service guide

Canon

Canon S820D user guide
