OWNER’S MANUAL: DIESEL SHUNTER LOCOMOTIVE
“JOBUS CHARNOCK”
Gauge III Radio controlled Model with synchronized diesel engine sound &
horn for 63.5mm gauge tracks.
www.pline.in
V1.0
PLEASE READ THIS OWNERS MANUAL CAREFULLY BEFORE OPERATING THE MODEL
Caution!!
This model is an accurate replica of the original locomotive. It has sharp and moving parts. The
locomotive drive gears are brass & stainless steel with sharp edges.
AT ANY TIME, OPERATORS MUST NOT COME IN CONTACT WITH THE MODEL WHILE IT IS
POWERED. UNDER NO CIRCUMSTANCES SHALL Paul Industrial Company OR ANY OF ITS
ASSOCIATES BE HELD RESPONSIBLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
ARISING IN REGARD TO ANY PLINE PRODUCT.
Items included:
1. G3 Diesel Shunter Model Locomotive X 1 off (Serial No.)
2. 2.4 GHz 4 Ch RC transmitter X 1off
3. Owner’s Manual X 1 off
Required:
1. 12v 1.3Ah rechargeable Battery pack for Locomotive X 1 off
2. AA batteries for transmitter X 4 off
3. Suitable battery chargers for serials 1 & 2
Battery Pack Selection:
Your G3 Diesel Shunter locomotive & transmitter are not supplied with the Battery Packs due to
International Shipping & Security norms. We recommend any deep-cycle Battery pack with an output of
12v rated at 1.3Ah (or higher rating) for the locomotive and 4 off AA alkaline cells for the transmitter.
Connect your preferred battery pack to the terminal Connector leads inside the locomotive’s rear engine
cowl (one on the speaker end of the cab), by removing the cosmetic hatch cover. The hatch cover is
snap fitted and can be removed by lifting it up straight. BE CAREFUL TO CONNECT THE CORRECT
POLARITY OF THE BATTERY TERMINALS TO THE CONNECTOR STRIP. THE WIRES ARE COLOURED RED FOR
+VE & BLACK FOR –VE POLARITY. INCORRECT POLARITY CONNECTION CAN DAMAGE THE CONTROL
SYSTEM OF YOUR MODEL. The locomotive battery pack can be housed inside the engine cowls or in the
cab.
Lubricating:
With a bit of care, your PLine Diesel Shunter should give you many years of pleasure and reliable service.
Lubrication is of prime importance for a model of this type with moving parts. Always use quality
lubricants. This should not be a problem, for there are many modern lubricants available in hobby and
www.pline.in
V1.0
sport shops. Light oil such as Labelle #108 or Hoppe’s Gun Oil would be good enough for lubricating
most of the moving parts. For gears use a suitable gear grease such as Permatex Super Lube or another
hobby gear lubricant.
The brass bevel gears driving each axle can be lubricated by applying grease on the gear teeth using a
small screw driver.
To access the many moving parts of this model it is best to carefully place it on its side on a soft towel or
foam sheet. A drop of light oil on every moving part is necessary, and there aren’t many on this
locomotive. Use oil that is a bit heavier to lubricate the axle bushings, axle boxes and pivot points of the
Power Bogies. Use a drop of Lubricating Oil to lubricate each Axle box. Be sure to lubricate all the wheel
bearings, motor bearings etc. that you can see. Do not over lubricate, for excess oil only picks up
unwanted dirt. Be careful to keep lubrication off the painted surfaces as this causes shiny areas.
The main motor gear box is lubricated in the factory and will not need any attention during the first runs
of your model. However, in time, you should make sure that the gears are will lubricated with suitable
gear grease.
Thorough Lubrication of the locomotive should be done every 5 hours of operation.
www.pline.in
V1.0
Operating the model:
Insert 4 off AA alkaline or similar batteries into the transmitter, and connect a suitable 12v battery pack
to the battery terminals of the locomotive (refer section for details).
Cab controls (above)
Tx controls (above)
www.pline.in
V1.0
Next switch the transmitter ‘ON’. The model can now be powered ‘ON’ by flipping the main power 3-
way switch in the cab downwards. Always SWITCH ‘ON’ the Tx first before POWERING ON the model.
By moving the left hand joystick gradually upwards on the transmitter the locomotive will move forward
(marked as “F” on the Tx), while gaining speed, and moving the same joystick downwards would reverse
the model (marked as “R” on the Tx), and increase speed. The model ideally should come to a stop when
the same joystick is in the neutral or centre position. This position can be adjusted using the throttle
trim slider located alongside the left hand joystick on the transmitter.
CAUTION: DO NOT RUN THE MOTORS ON FULL THROTTLE IN THE FIRST 100 MINUTES OF RUNNING. Run
the model at half throttle in any one direction for a few minutes, then stop, and then run it again at half
throttle for a few minutes more. Repeat this procedure for about half an hour until the model runs
smoothly in both directions. Once you have run your Model on half throttle in both directions on a test
track for at least about an hour, your model should be ready to run at Full throttle on the Outdoor
layout.
Sound & Horn:
When the model is powered on and not moving, you should hear the engine idling sound. As you speed
up or down in either forward or reverse directions the engine sound will also rev up or down in a
synchronized fashion, and idle when the model comes to a standstill.
The right hand side joystick on the transmitter when moved downwards blows the model’s horn
(marked as “H” on the Tx).
Lights:
The lights on the model can be operated by flipping the smaller toggle switch in the ‘ON’ or in the
downward position. The lights are directional and on the traction motors. So when the model moves in
any direction, the head, and marker lamps in that direction lights up.
Maintenance:
Clean the body of the Model with a clean soft lint free cotton cloth. To remove stubborn grease stains
from the painted surface use a detergent solution with a lint free cloth.
Always make sure that the screws on your model’s main bevel gear sets are not loose, before and after
every run. If loose tighten them gently using a M3 allen wrench and a 5mm wide flat blade screw driver.
With a little care your PLine Gauge 3 Diesel Shunter Locomotive will give you years of trouble free
running.
www.pline.in
V1.0
IMPORTANT!
Some parts may have loosened during shipment. Inspect your model prior to any
operation. Please contact PLine at info@pline.in for more assistance.
THANK YOU!
Marketed by: Paul Industrial Company
30A, Kasundia Road,
Howrah-711101, India.
Tel:+91-33-26407137
Fax: +91-33-26406248
URL: www.pline.in
Manufactured by: Model Engineering Company
47, Sankharitola Street, Calcutta-700014, India.
