PlayActive JE118 User manual
• Suitable for 37~96 Months
•Maximum user weight: 30kg
•Adult assembly required
Please keep this manual for future reference as it contains important
information.
Before first time use, charge the battery for at least 4-6 hours.
OWNER'S MANUAL with Assembly Instructions
Read and understand this entire manual before using!
CHILDREN'S
ELECTRIC TOY CAR
Products features may vary
from the picture above.
With remote control function
Use the vehicle on generally level ground ONLY!
caution
About Your New Vehicle
Thank you for your purchasing our products, we wants your child to enjoy this product for years to
come. Keep these points in mind as you read this guide:
FOR THE SAFETY OF YOUR CHILD, PLEASE READ ALL WARNINGS AND
ASSEMBLY/USE INSTRUCTIONS. KEEP THIS GUIDE FOR FUTURE REFERENCE.
• ADULT ASSEMBLY REQUIRED. The product contains small parts, which are for
adult assembly only. Keep children away when assembling.
• Always remove protective material and poly bags and dispose before assembly.
WARNING!
Suitable age: 37~96 months
6V4AH x1(Fuse: 7A) or 6V7AH x1(Fuse: 7A) or 6V10AH x1 (Fuse:7A)
Load Capacity:
Under 30KGS
Size of car:
118 x 81 x 67 CM
Speed: 3KM/H 3~5KM/H
Power way:
Charging type
Charger: Input: depend on local voltage
Output: DC 6V500mA or DC6V1A
or DC12V1A
Average
battery life:
Approximately
300 times
Charge time: 8-12 Hours
Battery &
Fuse:
1WD
2WD
1WD
1WD
2WD
2WD
IMPORTANT
WARNING
This label means the information or assembly for One Wheel Drive version ONLY!
This label means the information or assembly for Two Wheels Drive version ONLY!
CHOKING HAZARD - Small parts.
Not suitable for children under 37
months.
VER:SMS-XX-EN-111212
6V7AH x1 (Fuse: 10A)
VER:SMS-JE118-EN-120503VER:SMS-JE118-EN-RC-120503
1
1
4
8
1
1
2
1
1
1
1
x1
x2
x3
x2
x1
x2
x1
x2
x4
x8
x3
x2
2
1
1
1
4
12
2
2
3
A
B
C
D
4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
2
3
1
1
24
25
2
Parts List
PART
NO.
REMARKS
Assembly package
1WD
2WD
1WD
2WD
1WD
2WD
1WD
2WD
1WD
2WD
1WD
2WD
PART NAME
Q’ty (pcs)
Vehiclebody
Viewmirrors
Ø10Locknut
Ø10Washer
Seat
Ø5nut
Sidesupport
Steeringcolumn
Rearaxle
Steeringwheel
M5x35machinescrew
Drivingwheel
Wheel
Gearbox
Motorhood
Ø4x12flathead
screw
Ø10bushing
M5x16machinescrew
Windshield
Backrest
Charger
Capnut
Ø4x12roundheadscrew
Splitpin
Spanner
Ø10Washer
4pcsplacedonthefrontaxle,
4pcsplacedontherearaxle.
2pcsplacedonthefrontaxle,
2pcsplacedontherearaxle.
Placedonthesteeringwheel
Placedonthesteeringwheel
1pcslabeled“R”,1pcslabeled“L”
1PCSFORSPARE
Exhaust
Decorativestrip
M5x25machinescrew
Remotecontroller
1pcsplacedonthesteeringwheel,
1pcsplacedonthesteeringcolumn.
1
22
3
A
4
4
16
5
B
B
C
4
7
D
8
9
10
11
6
12
13
23
14
15
2
2
17
20
21
D
19
18
6
24
25
Tools Required
Screwdriver(not included)
Spanner
Pliers(not included)
Parts Diagram
NOTE: Some parts shown are assembled on both sides of vehicle
PART NOT SHOWN : Decorative strip x3
2
1x4
Assembly Steps
• Your new vehicle requires adult assembly. Please set aside at least 40 minutes for
assembly. Children can be harmed by small parts, sharp edges and sharp points in the
vehicle's unassembled state. Care should be taken in unpacking and assembly of the
vehicle. Children should not handle parts, or help in assembly of the vehicle.
• Please identify all parts before assembly and save all packaging material until assembly
is complete to ensure that no parts are discarded.
• Assembly tool for need: screwdriver(provide for oneself) and spanner.
●
Remove all the parts from the rear
axle.
●
Slide a Ø10 washer onto the rear axle
from the longer end.
●
Insert the rear axle through the hole in
vehicle body.
Ø10 Washer
Rear axle
Rear axle
●Turn the vehicle body downside
up.
●
Fit the side support to the vehicle
body.
●
Insert four Ø4x12 round head
screws and tighten with a screwdriver.
●Repeat for the other side.
Ø4x12 round
head screw
Side support
3
Assembly Steps
2WD
2WD
●Turn the vehicle body downside up.
●
Remove all the parts from the rear axle.
●
Insert the rear axle through the hole in the
vehicle body.
Rear axle
Hint: An extra spanner has been provided to hold the Ø10 locknut on the other side
of the front axle while tightening the locknut on the other side.
●Fit the gear box onto the rear axle
from the left side (Standing at the rear of the
vehicle body). And make the motor on the
gear box pass through the hole in the vehicle
body.
●Fit the driving wheel onto the rear axle,
keep it match with the gear box.
●Fit a Ø10 washer onto the rear axle.
●Fit a Ø10 locknut to the end of the rear
axle.
●Insert the tabs on the hubcap into slots in
the driving wheel.
●Slide the gear box (standing at back of vehicle body) onto the rear axle. “R” labeled gear box should be fit
to the “R” side of vehicle body; “L” labeled gear box should be fit to “L” side of vehicle body.
●Slide the driving wheel onto rear axle, make it match with the gear box.
●Slide a
Ø
10 washer.
●Tighten the
Ø
10 locknut with a spanner.(Do not over tighten)
●Repeat this procedure to assemble the other driving wheel to the rear axle.
●Fit the hubcap to the driving wheel.
Driving wheel
Ø10
Locknut
Gear box
Rear
axle
Ø10
Washer
Hubcap
4
5
5-1
5-2
5-
1
5-2
5
5-1
Assembly Steps
Ø10 Washer
Split pin
Ø10
Washer
Steering column
●Turn the vehicle body on its side.
●Remove the screw and nut from the steering column.
●Slide a
Ø
10 washer onto the steering column from the straight end (PIC 5-1).
●Insert the straight end of steering column up through the hole in vehicle body and out through
the hole in the dash.
●Insert the bent end of steering column through the hole in the front axle plate, fit a
Ø
10 washer
onto the steering column and insert a split pin into the hole in the steering column, bend the ends
of split pin back using a pair of pliers (PIC 5-2).
Hubcap
Ø10
Washer
Ø10
washer
Ø10
bushing
Front
axle
Wheel
Ø10
Locknut
●Remove the parts from the front axle.
●Fit a
Ø
10 washer onto the axle.
●Fit a
Ø
10 bushing onto the axle.
●Fit a wheel onto the axle, make the wheel
match with the bushing.
●Fit a
Ø
10 washer onto the axle.
●Tighten the
Ø
10 locknut with a spanner. (Do
not over tighten)
●Insert the hubcap.
●Repeat for the other wheel(s).
Direction
gear box
Steering
column
M5x25
Machine screw
●Turn the vehicle body on its side.
●Remove the screw and nut from the steering column.
●Insert the straight end of steering column up through the hole in vehicle body and out through
the hole in the dash.
●Insert the bent end of steering column through the hole in the front axle plate.
●Line up the holes in the direction gear box with the hole in the steering column. Tighten the
M5x25 machine screw and
Ø5 nut back in the same location (PIC 5-1).
●Fit a
Ø
10 washer onto the bent end of the steering column and insert a split pin into the hole in
the steering column, bend the ends of split pin back using a pair of pliers (PIC 5-2).
Ø5 nut
6
7
8
Assembly Steps
Ø4x12 round
head screw
Windshield
UP
Steering wheel
M5x35
Machine screw
Ø5 Nut
Fuse box
Power connector
Motor connector
Vehicle connector
●Turn the vehicle body upright.
●Fit the tabs on the windshield into the
slots in the vehicle.
●Insert two
Ø4x12 round head screws
and tighten with a screwdriver.
●Remove the M5x35 machine screw
and
Ø
5 nut from the steering wheel.
●Insert the steering wheel to the end of
the steering column.
●Insert the M5x35 machine screw
through the steering wheel and steering
column, and tighten the
Ø
5 nut back in
the same location.
●Plug the power connector into the
terminal on battery as shown.
●Plug the vehicle connector(s) into the
motor connector(s).
10
11
9
Assembly Steps
Backrest
Ø4x12
flat head
screw
Tabs
Seat
Slots
Motor hood
M5x16 machine
screws
2WD
●Fit the motor hood on the motor.
●Tighten four
Ø
4x12 flat head screws to
secure it.
●Repeat for the other side.
●Fit the motor hood on the motor.
●Tighten four
Ø
4x12 flat head screws to
secure it.
●Insert the tabs at the back of the seat
into the slots in the vehicle body.
●Insert two M5x16 machine screws, and
tighten with a screwdriver.
●Insert the backrest into the hole in the
vehicle body and push until you hear this
click into place.
12
13
Assembly Steps
Exhaust
(Grooved side up)
Decorative strip
Vehicle clamps
●Wash your hands before applying the decorative strips.
●Before applying the decorative strips, wipe the surface of the vehicle with a clean,
dry cloth to remove any dust or oils.
●Place the decorative strips exactly as shown in the illustrations.
●Remove the backing from the decorative strip. Insert the end of the decorative strip into the hole
in the vehicle body, and apply the decorative strip to the vehicle body. Keep the other end of the
decorative strip under the vehicle clamp.
●Repeat for the other side.
●When fitting the decorative strip to the bonnet, remember to keep the both sides of decorative
strip under the vehicle clamps.
●Insert the tabs on the exhaust
(grooved side up) into the hole in the
vehicle body and push until you hear this
click into place.
●Repeat for the other exhaust.
HINT:
Inset the end of the decorative
strip into the hole in the
vehicle body.
Keep the other end
under the vehicle clamp
