Plantronics K100 User manual
LEARN
MORE
K100™Bluetooth®In-car Speakerphone
TAKE A GOOD LOOK
MULTI-FUNCTION BUTTON
• Poweronoroff(3- to 4-second
press)
• Takeacallorendit (1 tap)
• Redial (2 taps)
• Transferaudiotoorfromphone
duringcall (3-second press)
• Rejectacall (press and hold until
you hear a single tone)
• Initiatephone’svoice-dialing
(2-second press until second
tone is heard)
• Activatemanualpairing(with
power off, press and hold until
LED flashes red/blue)
• Reconnect(1 tap)
• Enable/DisableMissedCall
Indicator (1 tap)
FM BUTTON
• FMtransmitonoroff (1 tap)
• FindFMchannel (press and hold
until station option is announced)
LED
• Charging (solid red)
• Poweringonoroff(2 blue or red flashes)
• FMtransmission (2 purple flashes)
• Missedcall (1 purple flash)
• Pairingmode (red/blue flashes)
VOLUME WHEEL
• Increasevolume(rotate clockwise)
• Decreasevolume (rotate counterclockwise)
MUTE BUTTON
• Muteonoroff(1 tap)
• Nightmode:LEDonoroff
(2-second press until tone is heard)
MICRO USB CHARGING PORT
• WithmicroUSBorcarcharger:
2.5 hours (100% charge)
• Bestperformancewhenfullycharged
MICROPHONES
-+
Besafe!Pleasereadthesafetyguide
beforeusingyournewspeakerphone.
CONNECT TO YOUR PHONE
“Pairing” is the process that
connects the speakerphone
to your phone. You can pair
more phones but can have
only one active connection
at a time.
1. READY
Activate the Bluetooth feature on
your phone, then use the phone’s
settings to add/search/discover
new Bluetooth devices.
iPhone: Settings > General >
Bluetooth > On
(starts the search for devices)
BlackBerry®smartphone:
Settings/options > Bluetooth: On >
Search for devices
VIDEO TUTORIAL FOR USA:
www.plantronics.com/pairing
2. SET
FirstTime:
With speakerphone turned off,
activate Bluetooth pairing mode
by pressing and holding the Multi-
function button to turn on speak-
erphone. The LED flashes red/blue
to indicate pairing mode.
3. CONNECT
Select “PLT_K100” from the list
of Bluetooth devices shown on
your phone.
If the phone asks for a passcode,
enter four zeros (0000). You may
see **** on screen.
Some phones also ask to confirm
the connection after pairing.
The speakerphone LED will stop
flashing red/blue once your phone
is successfully paired/connected.
HEAR CALLS THROUGH YOUR CAR STEREO
Suggested placement
You can listen to calls through
your car stereo speakers by
transferring the audio from
the speakerphone to one of
five FM channel options:
88.3MHz
88.7MHz
89.1MHz
89.5MHz
89.9MHz
If your phone is A2DP-enabled
you can also hear streaming
audio like GPS instructions and
music through your car speakers.
We recommend that you trans-
fer audio to an FM channel
before you start driving, and
that you make a routinely clear
channel a preset on your stereo.
1. READY
Ensure that your phone and speakerphone are
powered on and connected.
2. SET
Press the FM button to enter FM transmit
mode. The FM transmit channel will be an-
nounced.
3. CONNECT
Manually set your radio to the announced FM channel. You are now ready to transmit calls
and streaming audio like GPS directions from your phone to your car stereo.
If a radio station suddenly takes over the FM channel, tap the FM button to quickly redirect
the audio back through the speakerphone.
To find another FM channel, while FM is turned on, press and hold the FM button until another
channel option is announced, then tune your radio to the new channel.
LISTEN TO THE VOICE
WHAT YOU’LL HEAR WHEN YOU’LL HEAR IT
PowerOn After pressing the Multi-Function button for 3 to 4 seconds
PowerOff After pressing the Multi-Function button for 3 to 4 seconds
BatteryLow When you have less than an hour left before the battery
must be recharged
Pairing While the speakerphone and phone are trying to pair/connect
PairingIncomplete After the speakerphone and phone tried to pair but failed
LostConnection When the phone and speakerphone lose the Bluetooth connection
CallTerminated After ending a call or when using the call back feature through
visual voice mail
VolumeMaximum After reaching the highest volume setting
Connected After turning the speakerphone on or reconnecting a dropped
Bluetooth signal
MuteOn After tapping the Mute button
MuteOff From muted, after tapping the Mute button
FMONChannelXX.X After tapping the FM button, FM transmission turns on and the
voice announces the current station it is using
FMChannelXX.X After pressing and holding the FM button, the voice announces
the channel it now uses
FMOff From on, after tapping the FM button to turn transmission off
This speakerphone announces various
status alerts when you power on/off,
run low on talk time, or lose/reconnect
the Bluetooth connection to your
phone.
TIPS
Keep Your Eyes on the Road:
The controls are easy to find with your
fingertips without looking for them.
Before driving, reach up and familiarize
yourself with the controls so you can
keep your eyes on the road when a call
comes in.
The notched Volume wheel is easy•
to feel.
The Multi-function button is inside•
the wheel.
The Mute button has a raised notch.•
Avoid a Dead Battery:
Remember to power off the speaker-
phone when you exit your car. If you
forget, the speakerphone will automat-
ically turn off after 90 minutes of not
having an active connection.
Protect Your Hearing:
You can adjust the volume faster by
turning the volume wheel faster. To
adjust the volume a small amount,
turn the wheel slowly.
Learn to Share:
When powering on, the speakerphone
searches for the last connected phone.
If the last connected phone is not
within range, or the Bluetooth fea-
ture is turned off on the phone, then
another phone within range that has
been previously paired with the speak-
erphone can be connected by tapping
the Multi-function button.
Turn the LED On or Off:
For comfortable night driving, you
can turn the lights on or off by press-
ing and holding the Mute button for
2 seconds until you hear a tone.
Listen to the Voice:
This speakerphone says various status
alerts when you power on/off, lose/
reconnect the Bluetooth connection
to your phone, or change FM channels.
Sound Your Best:
Clip the speakerphone to your visor
where the two microphones, located
on the top of the unit, can be closest
to your face so you can speak in a
normal tone of voice and be heard.
SPECIFICATIONS
TalkTime Up to 17 hours
StandbyTime Up to 15 days
OperatingDistance(Range) Up to 33 feet from phone
SpeakerphoneWeight 92 grams
SpeakerphoneDimensions 120 x 60 x 16.5mm (without clip)
ChargeConnector Micro USB connector
BatteryType Rechargeable, non-replaceable Lithium-ion polymer
ChargeTime(Maximum) 2.5 hours to full charge
PowerRequirements 5V DC - 500mA
BluetoothVersion 2.1 with EDR and eSCO
BluetoothProles Hands-Free (HFP) 1.5, Headset (HSP) 1.1 and Advanced
Audio Distribution (A2DP)
Operating,Storageand
ChargingTemperature
14°F - 122°F (-10°C - 50°C)
NEED MORE HELP?
24-hour support in USA:
1-866-363-BLUE (2583)
1-year limited warranty details:
www.plantronics.com/warranty
© 2010 Plantronics, Inc. All Rights Reserved. Plantronics and K100 are trademarks
or registered trademarks of Plantronics, Inc. The Bluetooth word mark and logos are
owned by the Bluetooth SIG, Inc. and any use of such marks by Plantronics, Inc. is under
license. iPhone is a trademark of Apple Inc. registered in the U.S. and other countries.
Blackberry is owned by Research In Motion Limited and is registered in the United
States and may be pending or registered in other countries. Plantronics, Inc is not
endorsed, sponsored, affiliated with or otherwise authorized by Research In Motion
Limited. AM84444-01 (08/10)
