Plantronics Calisto P830 User manual

Getting started:

Follow the steps below to get call answer/end controls

with your Calisto speakerphone and Cisco® IP

Communicator.

1. Connect your speakerphone to the computer. If

this is the first time you are connecting, wait for

the installation process to complete.

2. To get call control features, please download the

latest version of Plantronics software at

plantronics.com/software.

Note: Check with your IT staff before installing software

on your computer.

Configuring Cisco IP Communicator to always route call

audio to the speakerphone:

3. Click the Menu icon in the upper right corner of

the Cisco IP Communicator main screen.

4. Select the Audio Tuning Wizard option.

5. Select your Plantronics speakerphone as the

default device for the Headset option.

6. We recommend you select your Plantronics

speakerphone as the default device for both

Speakerphone and Handset options as well.

7. To route the ringer through your PC speakers,

select your PC speakers for the Ringer option.

Click Next.

8. In these next few screens you can test and adjust

listening volume and microphone level.

9. When you are finished adjusting listening volume

and microphone level, click Finish.

Note: USB configuration settings are unique for each USB

port. If you connect the speakerphone to a different port you

will need to make these changes again to set behavior for

that USB port.

Calisto®P830™Quick Setup Guide

Welcome:

Using a Plantronics Calisto speakerphone

for PC calls will deliver a simpler, more

comfortable and better sounding audio

experience than you could get using just

your computer’s internal microphone and

speaker.

Plantronics Speakerphone

©2011 Plantronics, Inc. All rights reserved, Plantronics, the logo design, Calisto and P830 are trademarks or registered trademarks of Plantronics, Inc. Cisco is a registered trademark of Cisco Systems Inc. and/or its affiliates in the U.S. and other countries.

Published 10.11

Calisto P830 Key Features:

Seamlessly switches between calls

from PC, mobile and home landline

Color display and touch sensitive keys

for intuitive visual call management

Full duplex wideband audio support

and advanced noise cancellation

Plantronics Speakerphone

PC Speakers

Making and Receiving Calls with Cisco IP Communicator

To MAKE a call:

To call an existing contact, click on the

Directories (1) icon. Click on one of the

choices given depending on your contact (2).

Then click the contact’s name (3) and hit

Dial (4).

To initiate a call by typing a phone number,

click on the main window of the Cisco IP

Communicator screen and begin dialing the

number. Then press the Enter key.

When a call is placed, a call notification will

appear in the main Cisco IP Communicator

screen, and the audio will be routed to your

speakerphone.

To RECEIVE a call:

When you receive a call, a red light will blink

on your Cisco IP Communicator screen (5)

and a call notification window will appear in

the lower right corner of your computer

screen (6).

To answer the call, use the controls on your

speakerphone or click the left pane of the

call notification window (7). To dismiss the

call, click the right pane of the call

notification window (8).

Published 10.11
