Plantronics RIG 400 Series User manual

RIG 400 Series

RIG 400, RIG 400HS, RIG 400HX, RIG

400LX

User Guide

Contents

Setup and basics 3

Assemble headset 3

Be safe 3

Setup PS4 3

Setup Xbox One 4

Adjust the volume 4

Mute 4

LX1 adapter guide for LX series 5

Overview 5

Set up 5

Support 7

Your headset components easily snap into the headset frame to configure the best fit and sound.

1Follow the diagram to put your headset together.

IMPORTANT When inserting the boom, align the notches on the boom jack and port. The

microphone will not work if the boom is inserted incorrectly.

3.5 mm

Align/ Aligner

HS, HX models

NOTE Laptop, tablet and mobile device compatibility and use with these devices is not tested nor

endorsed by Sony Interactive Entertainment Europe.

2The headband adjusts to three sizes (small, medium, large) by moving the earcups. To remove an

earcup, press the earcup to detach it from the headband.

Please read the safety guide for important safety, charging, battery and regulatory information

before using your new headset.

1To setup your headset for PS4, first go to Settings > Devices > Audio Devices > Output to

Headphones > All Audio

2For system volume control, go to Settings > Devices > Audio Devices > Output to headphones >

Volume Control

Setup and basics

Assemble headset

Be safe

Setup PS4

To setup your headset for Xbox One, go to Display and sound > Kinect and devices > Select device

and adjust settings

(HS, HX models) To adjust the volume, slide the volume control.

(HS, HX models) To mute your headset, slide the mute switch to reveal the red color.

Setup Xbox One

Adjust the volume

Mute

3.5 mm

LED

Red = Mute

Blue = Balanced mode

Green = Independent mode

EQ settings (short press)

Single tone = Pure EQ maintains high frequencies

Double tone = Intensify EQ emphasizes mid-range sounds

Triple tone = Seismic EQ boosts bass

Mode settings (press and hold for 4 seconds)

Balance mode = The top dial controls master volume and the bottom dial controls game and chat

volume

Independend mode = The top dial controls game volume and the bottom dial controls chat

volume

Tap to mute your mic (LED turns red)

Top dial

Balance mode = Controls master volume

Independent mode = Controls game volume

Bottom dial

Balance mode = Balances game and chat volume

Independent mode = Controls chat volume

Headset port

3.5mm stereo AUX input

NOTE Balance mode is the default setting.

The adapter is compatible with the Xbox One first and second generation wireless controllers.

1Plug the adapter into a compatible Xbox One controller.

2Power on the Xbox One controller. It may take the adapter up to 10 seconds to boot up. The LED

turns on for 2 seconds to indicate power.

LX1 adapter guide for LX series

Overview

Set up

00:0 0:10

3Connect a headset to the adapter in the 3.5 mm jack.

4Choose how you want the dials to be configured. By default, the adapter is set to Balance mode.

Press the EQ button for 2 seconds to switch between Balance and Independent mode.

•Balance mode In Balance mode (blue LED) the top dial controls master volume and the bottom dial

balances game and chat.

•Independent mode In Independent (green LED) mode the game and chat channels are split; the top

dial controls game volume and the bottom dial controls chat volume.

5Choose an EQ setting. Cycle through the EQ modes by tapping the EQ button.

Tap the EQ button and hear EQ mode

one tone Pure EQ maintains high frequencies.

two tones Intensify EQ emphasizes mid-range sounds.

three tones Seismic EQ boosts bass.

6Optional Plug a device into the 3.5 mm jack, if you want to listen music while gaming.

0800 410014

0800 117095

80011336

+44 (0)1793 842443*

0800 945770

+44 (0)1793 842443*

1800 551 896

800 84 45 17

80 88 46 10

+44 (0)1793 842443*

Deutschland 0800 9323 400

Österreich 0800 242 500

Schweiz 0800 932 340

+44 (0)1793 842443*

8-800-100-64-14

+44 (0)1793 842443*

800 950934

0200 21 46 81

900 803 666

NL 0800 7526876

BE 0800 39202

LUX 800 24870

+44 (0)1793 842443*

*Support in English

For warranty details, go to plantronics.com/warranty.

Support

NEED MORE HELP?

plantronics.com/support

Plantronics, Inc. Plantronics B.V.

345 Encinal Street

Santa Cruz, CA 95060

United States

Scorpius 171

2132 LR Hoofddorp

Netherlands

Patents: EM 002814079; patents pending.

207795-06 (11.17)
