Planex GW-US54GZL User manual
2.4 GHz IEEE 802.11g 54Mbps Wireless LAN
USB Adapter
GW-US54GZL
MAC Installation Guide
Planex Communications Inc.
MAC Installation Guide
1. Install driver and ZDWlan Utility........................................................................... 2
2. Use ZDWlan Utility................................................................................................... 7
3. UnInstall driver and ZDWlan Utility.................................................................... 12
1. Install driver and ZDWlan Utility
Double Click
ZD1211MacUSB_install_3_0_0_0.pkg
Select install folder by Mac OS version.
Double Click
PCI ZD1211MacUSB_install_3_0_0_0.dmg
Click Continue
Click Continue
Select a Destination
Volume
Click Continue
Click Upgrade
Click OK
Enter Name and Password of
the user with Administrative
rights.
Click Continue Installation
Click Restart
Now the Driver and Utility Installation is Complete! Restart the computer.
If this the first time you run this Wireless card after installaion, please enable the new network
interface in the Network Control Panel in System Preferences.
It is essential to follow the steps in below, before first launch of ZyDASWLan utility.
Click Network
Click OK
Click Apply Now
Now It’s ready to use Wireless.
2. Use ZDWlan Utility
Launch ZyDasWLan
After installation and enable network configuration, you can open the wireless lan Utility in System
Preferences
Click one SSID in Available
Network: it would show the
AP information in right
window.
Double Click one SSID in
Available Network or Click
Connect this site : it would
connect to the selected
siteSSID.
Click Refresh: Site survey.
Click More Setting…: Open
more setting panel
Request dialog would pup if
need Encryption in WEP.
“No” for configure new key
setting, “Yes” for use previous
setting.
MainView
Change connection setting
Open WEP key setting
Open Information
Close the More Setting Panel
Apply the new setting.
More Setting
