Philips TCD168/VUAFAHYP User manual

Division of Philips France

Printed in France

4311 256 00312

User manual

LEAFLET c13db ÉXÉ 17/11/99 15:03 Page 1

Table of contents

Glossary 1

Before you start 2

The micro-SIM card 2

The battery 2

Insert the micro-SIM card 3

Insert the battery 3

Discover your phone 4

Display 5

Entering text 6

Basic functions 7

Switch ON/OFF 7

Voice dialling 7

Make a call 7

Answer or reject a call 8

Earpiece volume 8

Consult last calls 8

Adjust ringer volume 8

Emergency call 9

Change language 9

International call 9

Keypad lock/unlock 9

Special functions 10

Answer a second call 10

Automatic redial 10

Scratchpad 10

Touchtones (DTMF) 11

Hide your identity 11

Setting up Flash Dial 11

Menus 12

Discover the Compass key 12

Names 13

Add a name 13

Add voice dial 13

View names in the name list 14

Quick access to names 14

Search for a specific name 15

Road your own number 15

Delete a name 15

Messages 16

Read new messages 16

Read archived messages 17

Send short messages (SMS) 17

Service center number 17

Emotion icons 18

Send short messages from

phoneboock 19

Usual messages 19

Calls 20

View calls 20

Delete all calls 20

Meters 21

View meters 21

Reset meters 21

Settings 22

Set up meters 22

Key tones ON/OFF 22

Choose ringer 23

Cell broadcast 23

View topics, add a topic 23

Manual registration 24

Voice mailbox number 24

Consult your voice messages 25

Security 25

Pin request, 25

change PIN and PIN 2 codes 25

Fixed names 26

Extra 27

Alarm clock,(set off/set on) 27

Set clock 27

Calculator 28

Euro converter 28

Biorythm calendar 29

Stopwatch 29

Call forwarding 30

Forward always to voice mail 30

Forward always to number 30

Cancel all 30

PhilipsAuthenticAccessories 31

Troubleshooting 33

Safety Precautions 34

Index

TABLE OF CONTENTS

Philips Savvy p23 à 36 GB 15/11/99 15:30 Page 36

QUICK GUIDE

SWITCH ON

Press and

hold

Enter your

PIN code.

MAKEA CALL

Enter

phone

number.

Call the

number

(e.g.:112 for

emergency see p.9)

ANSWERA CALL

Accept.

ENDA CALL

End.

ADDA NAME

Enter

phone

number.

Enter name

If number is OK

ForVoice dial options

(see page 13)

ACCESSTO MENU

Enter or exit

the menus.

NAVIGATION

Move Up

Back.

Move Right.

Move Left.

Move Down

Forward

Validate.

SWITCH OFF

Press

and hold.

When your

phone is

switched off,you

cannot receive

calls.

Stored

1234_

Number:

Name:

1234_

Store no .

1234_

Network

12345678

Enter PIN:

✄

Philips Savvy p1à11 GB-21/7 15/11/99 15:21 Page I

MENU MAP

FORWARDING MESSAGES NAMES CALLS EXTRA SETTINGS SECURITY

Forwarding

Always Status If no reply If busy Unreachable Cancel all

Messages

Centre no. Archive Send Usual msg. Forwarding

Names

Search View Add Own number

Calls

Delete all View Meters

Extra

Stopwatch Clock Alarm clock Calculator BioCalendar Converter

Settings

Security

Change PIN2 Change PIN PIN code Fixed names Restriction

✄

Philips Savvy p1à11 GB-21/7 15/11/99 15:21 Page II

DTMF Dual Tone Multi Frequency

The tones are transmitted by the phone to the

network. They are used to interrogate answering

machines, transmit codes,...

GSM Network Global System for Mobile communications. The type

of phone network used by your phone.

PIN Code Personnal Identification Number, this is the secret

code of the SIM Card. If you, or someone else,

enters the wrong PIN code three times your SIM

card is blocked. If this happens, please contact

your service provider.

PIN2 Code Secret code that allows you to access certain SIM

card dependent features. If you, or someone else,

enters the wrong PIN2 code three times your SIM

card is blocked. If this happens, please contact

your service provider.

PUK Code Secret code used to unblock your SIM card if you,

or someone else, enters the wrong PIN code three

times. This code will be given to you by your

service provider.

Roaming Using your phone in a network other than your

home network in your country or abroad.

SIM card Subscriber Identification Module. This card which is

provided by your GSM service provider allows you

to make phone calls with your GSM phone. Your

phone number is contained inside the card.

SMS Short Messages Service. This service provided by

the operator allows you to send and receive short

written messages (Maximum : 160 characters).

GLOSSARY

Philips Savvy p1à11 GB-21/7 15/11/99 15:21 Page 1

From your card,remove

the micro-SIM card

The micro-SIM card

To use your phone,you must insert a valid

micro-SIM card supplied by your GSM network

operator.When you switch the phone on,it may

ask for the PIN code.The PIN code is the secret

code of the micro-SIM card.

The micro-SIM card contains your subscription number and phone number.It

also contains a memory in which you can store phone numbers and messages.If

you use your micro-SIM card on another phone,you still retain the same phone

number,stored numbers,and messages.

The battery

Your phone is powered by a rechargeable battery.

• After you plug in the battery,please wait a few seconds

before pressing the on/off key to switch the phone on.

• A battery only reaches its maximum capacity after being

totally discharged and recharged 2 or 3 times.

• A battery lasts longer if you allow it to fully discharge from

time to time.

• If you do not use your phone for several days,it is better

to remove the battery.

Remove the battery cover

Press on the latch on the back of the phone

and lift off the battery cover.

Remove the battery (if necessary)

Lift up on the bottom of the battery and

remove it from the phone.

BEFORE YOU START

Philips Savvy p1à11 GB-21/7 15/11/99 15:21 Page 2

Insert the micro-SIM card

First,place the micro-SIM card into the

appropriate slot in the battery compartment

(the clipped corner should be at the top left).

Then,slide the card with your finger until it

stops.

Insert the battery

1. Keep the battery + and - on the top

facing the + and - of the phone.

2. Slide the battery onto the contacts

points and press.

Replace the battery cover

Hook the battery cover onto the hinges on

bottom of phone and press forward until the

latch catches.

Charge the battery

With the battery inserted in the phone,plug

the connector into the right socket at the

base of the phone.Next,plug the transformer

unit into anAC power socket.

The only way to turn off the charger is to

unplug it,so use an easily accessibleAC

power socket.

The battery icon on your phone’s display

indicates the state of the charge process:

• Bars moving = battery is charging.

• Bars steady = battery is fully charged.

• Battery outline flashing (seeTroubleshooting p.32).

You can switch the phone on and use it during charging.

The first time you charge the battery and later, if it is completely discharged, the

battery icon will only appear 2 to 3 minutes after you connect the charger.

Please charge the phone for a minimum of 3 hours before first use.

BEFORE YOU START

Philips Savvy p1à11 GB-21/7 15/11/99 15:21 Page 3

DISCOVER YOUR PHONE

Antenna

Earpiece

listen here

Display

see next page

Red "ON/OFF" key

a long press on

this key switches

the phone on/off,

a short press ends

a call

Green "CALL" key

press this key to dial the

number or name on the

display, or use it to

answer a call

"CLEAR" key

to delete numbers and

letters on the display

Keypad

to enter

numbers and

text

MENU key

to enter and exit

the menus

Microphone

"Compass" key

use this key to navigate

in the menus,

the OK key is used to

validate information

MNO

PQRS TUV WXYZ

JKL

ABC

GHI

DEF

If you encounter the symbol in this manual,it means

that you have to press and hold the key to activate the

function.

Philips Savvy p1à11 GB-21/7 15/11/99 15:21 Page 4

DISPLAY

Silent mode

if on: phone will not

ring or beep (except

for the alarm clock)

New text message(s)

- if on: you received new messages

- if flashing: the memory is full,

you need to delete old messages

before you can receive new ones

Roaming

your phone

is registered

to a foreign

network

Network

if on: your phone is

registered to a network

if flashing: registration

is in progress

New voicemail

if on: there are

new messages

waiting in your

voicemailbox (*)

Reception quality

the more bars are

shown the better

the reception

Battery level

the bars indicate the

battery level (4 bars

is full, no bars

means recharging is

needed)

2 text lines

to enter numbers

and text or to read

text messages

Arrows

indicate in which directions

you can go using the

Compass key

left/right

and

back/forward

end of menu

Graphics area

displays the clock

and guides you

through the menu

Cursor

indicates that you can

enter numbers or text

(*) Depending on the network.

Philips Savvy p1à11 GB-21/7 15/11/99 15:21 Page 5

ENTERING TEXT

Each key allows you to obtain several characters.You have to quickly press

the same key several times to reach the desired character.

Example:

Key Characters

space 1 @ # = <> ( ) & £ $ ¥

a b c 2 à ä å æ ç

d e f 3 é è ∆ Φ

g h i 4 Γ ì

j k l 5 Λ

m n o 6 ñ ò ö ø

p q r s 7 β Π Θ Σ

t u v 8 ü ù

w x y z 9 Ω Ξ Ψ

.0 ” ’ ? ! ,:¡ ¿

*+ - / %

upper-case lower-case mode

While you enter text your phone changes between upper-case and lower-case

automatically.

If you wish to enter text in the upper-case mode press ,to enter text in the

lower-case mode press again.

The icons will show that you are in the upper-case mode.In the lower-case

mode the icons appear.

TO OBTAIN Space D ü

PRESS

Once Once

Five times

quickly

Philips Savvy p1à11 GB-21/7 15/11/99 15:21 Page 6

This manual suits for next models

Table of contents

Other Philips Cell Phone manuals

Philips

Philips CT0390BLK User manual

Philips

Philips Fisio 620 User manual

Philips

Philips X333 User manual

Philips

Philips 636 User manual

Philips

Philips laserfax 755 User manual

Philips

Philips 859 User manual

Philips

Philips Xenium 9@9q User manual

Philips

Philips lifeline User manual

Philips

Philips Pronto TSU9300 Safety guide

Philips

Philips Mirror FX 639 User manual

Philips

Philips SE735 User manual

Philips

Philips CD 290 User manual

Philips

Philips Xenium X712 User manual

Philips

Philips CT9A9QPNX User manual

Philips

Philips CT7608-000APMEA User manual

Philips

Philips CD4960B User manual

Philips

Philips S327 User manual

Philips

Philips CT 9A9R User manual

Philips

Philips CTV387 User manual

Philips

Philips CT5888/000APMEA User manual

Philips

Philips CT7568/000APMEA User manual

Philips

Philips CT0193BLK/00 User manual

Philips

Philips Xenium CT9A9GBLK User manual

Philips

Philips S890 User manual

Popular Cell Phone manuals by other brands

Zte

Zte BLADE A520 quick start guide

Nokia

Nokia Lumia 620 user guide

Blackbe;rry

Blackbe;rry KEYone Safety and product information

Bea-fon

Bea-fon X5 Premium quick guide

Blackbe;rry

Blackbe;rry 8707 Series user guide

Blackbe;rry

Blackbe;rry Storm Troubleshooting

LG LM-X420QN user guide

LifeWatch

LifeWatch V user guide

Bea-fon

Bea-fon SILVER LINE SL860 user guide

IKI Mobile

IKI Mobile KF4.5i user manual

Hitech

Hitech HT-850 user guide

Yezz

Yezz Fashion F10 user manual

Point Mobile

Point Mobile PM60 user manual

Blackbe;rry

Blackbe;rry Q10 user guide

Blackbe;rry

Blackbe;rry Bold 9900 user guide

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 user guide

LG LM-K420EMW user guide

ISAFE MOBILE

ISAFE MOBILE IS655.2 operating manual
