PEERLESS VML11 Guide
ISSUED: 08-11-03 SHEET #: 090-9093-3 11-10-04
Visit the Peerless Web Site at www.peerlessindustries.com For customer service call 1-800-729-0307 or 708-865-8870.
1 of 4
IMPORTANT! Read entire instruction sheet before you start assembly and installation.
Models:RTLCD-100S
D-LCD-100S
PART LIST
K
E
J
I
QTY. DESCRIPTION
A090-0147 1 LCD assembly
B095-4101 1 adapter plate
C520-2027 4 M4 x .7 x 10 mm phillips screw
D520-2099 4 10-32 x 1.25” phillips screw
E540-9443 4 .219 x .5 x .25 nylon spacer
F520-2100 4 10-32 x 2” phillips screw
G540-9465 4 .219 x .5 x .88 nylon spacer
H560-1134 3 cord clip
I540-9442 8 #10 SAE washer
J590-1122 1 2’ helical wire wrap
K520-2005 4 M5 x .8 x 10 mm phillips
L540-9447 4 1/4 split washer
M504-2013 4 M4 x 12 mm phillips screw
N590-5003 4 .198 x .313 x .437 retaining spacer
O504-2014 4 M4 x 20 mm phillips screw
Some parts may not appear exactly as illustrated.
B
C
G
D
H
Part #
Installation & Assembly -UnderCabinetSwivelMount forLCDTVs
L
M
O
N
F
A
Max Load 10 lb (4.5 kg)
This product is intended for use with 10” to 15" LCD TVs weighing up to 10 lb and VESA® 75 and VESA® 100
mounting patterns
Important, read before installation: In order to locate the mount completely under
the cabinet, the cabinet depth should be at least 1.5" more than the height of the TV. This
depth may be more depending on the width and shape of your TV. As an alternative
means of mounting, the mount can still be fastened when it is extended 2" past the front
of the mounting surface which will add 2" of depth to your cabinet.
ISSUED: 08-11-03 SHEET #: 090-9093-3 11-10-04
Visit the Peerless Web Site at www.peerlessindustries.com For customer service call 1-800-729-0307 or 708-865-8870.
2 of 4
Removecordcover fromLCDassembly(A).
A
CordCover
FORVESA75MOUNTINGPATTERN:1.)
Chooseholepatternindicatedbelow.2.)
Attach adapter bracket (B) to back of monitor
using four M4 x 10 mm screws (C) as indi-
cated below. 3.) If hole pattern is in a pocket,
attach adapter bracket (B) to back of monitor
using four M4 x 20 mm screws (O) and four
retainingspacers(N)asindicatedbelow.
Monitor may appear
slightlydifferentthan
illustrated
For monitors with a hole
pattern in a pocket,
spacers (N) go between
adapter bracket (B) and
monitor.
BB
FORVESA100MOUNTINGPATTERN:1.)Choose
holepatternindicatedbelow.2.)Attachadapter
bracket (B) to back of monitor using four M4 x 10
mm screws (C) as indicated below.Note: If installing
LCDscreenmodelSharp®LC-13E1U,LC-15E1U,
LC-20E1U, or if you don't get three complete turns in
the screen inserts, use four M4 x 12 mm screws (M)
instead of four M4 x 10 mm screws (C).
This product is designed to accommodate screens with VESA®compliant hole
pattern. For safe mounting, please make sure that mounting screws turn at least
three complete turns in the screen inserts.
ISSUED: 08-11-03 SHEET #: 090-9093-3 11-10-04
Visit the Peerless Web Site at www.peerlessindustries.com For customer service call 1-800-729-0307 or 708-865-8870.
3 of 4
FastenLCD Assembly (A) to cabinetusing four
10-32x 1.25”screws (D)four #10SAE wash-
ers (I)and four1/4” spacers (E). Get all four
screws(D) started before tightening.
Note: Ifcabinet underside has lip, usefour 7/8”
spacers (G)and four 10-32 x 2” screws (F)
insteadof screws (D) and spacers(E). This
lowersLCD Assembly(A)by 7/8” to allow LCD
Assembly (A) to open and close without
obstruction.
Carefully hold the closed mount with the TV against the
bottom of your cabinet. Make sure that there is enough
clearance between the back of the TV and the wall to
clear the back tab. Drill four 1/4” holes to match the
drawingto the right.
F
EG
or
or
I
A
Back Tab
6.00”
1.25”
Back holes of
LCD assembly
Locate the bracket in the slot so that
the top of the TV does not touch the
roundcover or goabove it whenthe tilt
is in the open position as shown in
figure 1. Place 1/4 split washer (L) on
M5screw (K) before#10 SAE washer
(I)and fasten adapterplate (B) toLCD
assembly (A) as shown in figure 2.
Wall
figure 1
TOP VIEW
Sample location: your
screen may mount in a
different location in the slot.
K
A
B
L
I
RoundCover
figure 2
• We recommend taking the screen off the mount to
affix the bracket to the cabinet, to avoid any damages
to the screen.
CAUTION
D
ISSUED: 08-11-03 SHEET #: 090-9093-3 11-10-04
Visit the Peerless Web Site at www.peerlessindustries.com For customer service call 1-800-729-0307 or 708-865-8870.
4 of 4
CordCover
Reattach screen onto bracket using the same
position determined in step 4. Wind helical wrap (J)
around all cords from back of LCD TV, as shown.
Place cord clips (H) as needed, to better manage
cords, making sure that one clip is close enough to
thehingearea to preventcordfrom bunching up.
Note: Make sure that cords come out right side of
LCDassembly (A).
Place cord cover back onto LCD assembly (A), so that it
is even with the bends on the side of the mount.
Note: Make sure all slack is pulled out with mount fully
openbeforereplacingcordcover.
J
Right Side
A
H
©2004PeerlessIndustries,Inc.Allrightsreserved.
PeerlessisaregisteredtrademarkofPeerlessIndustries,Inc.
Allotherbrandandproductnamesaretrademarksorregisteredtrademarksoftheirrespectiveowners.
