PEERLESS WSP816 Guide

ISSUED: 03-24-09 SHEET #: 125-9056-1

Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-729-0307 or 708-865-8870.

1 of 2

Models: WSP816,

WSP816-W

Use a stud finder to locate stud centers. Use wall

plate (A) as a template to mark stud centers

through slots. Drill 3/4" (19 mm) dia. holes through

drywall and studs. Insert togglers (E) as shown

below. Six 1/4-20 x 2.5" phillips screws (D) and six

washers (C) are provided. Place screws (D) through

wall plate (A). Partially fasten the toggler (E) to the

back of the screw. Pivot ends of toggler (E) 90°.

• Make sure that mounting screws are anchored into

the center of the studs. The use of an "edge to edge"

stud finder is highly recommended.

WARNING

A

BC

D

E

A

E

D

E

D

A

A

DC

E

Installation and Assembly:

Metal Stud Wall Plate for FPS-1000 or SP850

IMPORTANT! Read entire instruction sheet before you start installation and assembly.

Maximum Load Capacity: 150 lb (68 kg)

D

E

A

C

Push toggler (E) through hole.

Pull screw (D) back until toggler (E) hits the inside of

the metal stud. Fasten all six screws (D) tight, until

wall plate (A) is flush with wall.

WSP816 WSP816-W

Description Qt

y

. Part # Part #

A

16" wall plate 1 024-1047 024-2047

B1/4-20 x 1/2 phillips head screw 4 510-9108 510-9108

C1/4" flat washer 10 540-9440 540-9440

D1/4-20 x 2.5 phillips head screw 6 520-9522 520-9522

Etoggler 6 590-1093 590-1093

Parts List

ISSUED: 03-24-09 SHEET #: 125-9056-1

Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-729-0307 or 708-865-8870.

2 of 2

© 2009 Peerless Industries, Inc. All rights reserved.

Peerless is a registered trademark of Peerless Industries, Inc.

All other brand and product names are trademarks or registered trademarks of their respective owners.

Secure FPS-1000, or SP850 to wall plate using

four 1/4-20 x 1/2" phillips head screws (B) and

1/4" flat washers (C).

B

C

FPS-1000 OR SP850
