PedalPCB Triad Overdrive Quick start guide

Copyright © 2020 - PedalPCB.com Page 1 of 5Triad Overdrive

Triad Overdrive

Revised 12/31/20

All trademarks and registered trademarks are the property of their respective owners. The company, product, and service names used in this web site

are for identication purposes only. Use of these names, logos, and brands does not imply endorsement.

• Volume

• Body

• Drive

• Gain (Toggle switch)

CONTROLS AND FEATURES

Copyright © 2020 - PedalPCB.com Page 2 of 5Triad Overdrive

Triad Overdrive

Parts List (Page 1 of 1)

LOCATION VALUE TYPE NOTES

R1 1M Resistor, 1/4W

R2 1K Resistor, 1/4W

R3 470K Resistor, 1/4W

R4 10K Resistor, 1/4W

R5 10K Resistor, 1/4W

R6 22K Resistor, 1/4W

R7 220R Resistor, 1/4W

R8 4K7 Resistor, 1/4W

R9 1K Resistor, 1/4W

R10 10K Resistor, 1/4W

R11 1K Resistor, 1/4W

R12 470K Resistor, 1/4W

R13 10K Resistor, 1/4W

R14 100R Resistor, 1/4W

R15 10K Resistor, 1/4W

R19 10K Resistor, 1/4W

R100 47K Resistor, 1/4W

R101 47K Resistor, 1/4W

R102 4K7 Resistor, 1/4W

C1 100n Film capacitor, 7.2 x 2.5mm

C2 1u Electrolytic capacitor, 5mm

C3 51p Ceramic capacitor

C4 56n Film capacitor, 7.2 x 2.5mm

C5 100n Film capacitor, 7.2 x 2.5mm

C6 220n Film capacitor, 7.2 x 5.0mm

C7 1u Electrolytic capacitor, 5mm

C8 100n Film capacitor, 7.2 x 2.5mm

C9 10u Electrolytic capacitor, 5mm

C100 100n Film capacitor, 7.2 x 2.5mm

C101 100u Electrolytic capacitor, 5mm

C102 10u Electrolytic capacitor, 5mm

D1 1N4148 Signal diode, DO-35

D2 1N4148 Signal diode, DO-35

D3 LED 3mm Red LED, Diused

D4 LED 3mm Red LED, Diused

D100 1N5817 Schottky diode, DO-41

Q1 2N5088 BJT transistor, NPN TO-92

Q2 2N5088 BJT transistor, NPN TO-92

IC1 TL072 Dual op-amp, DIP8

VOLUME B100K 16mm right-angle PCB mount pot

BODY B25K 16mm right-angle PCB mount pot

DRIVE A500K 16mm right-angle PCB mount pot

GAIN SPDT Toggle switch, SPDT 2-position (ON/ON)

Copyright © 2020 - PedalPCB.com Page 3 of 5Triad Overdrive

Triad Overdrive

Schematic Diagram

Copyright © 2020 - PedalPCB.com Page 4 of 5Triad Overdrive

Triad Overdrive

Wiring Diagram

F

O

O

T

S

W

I

T

C

H

P

O

T

E

N

T

I

O

M

E

T

E

R

P

O

T

E

N

T

I

O

M

E

T

E

R

P

O

T

E

N

T

I

O

M

E

T

E

R

L

E

D

D

C

J

A

C

K

I

N

P

U

T

J

A

C

K

O

U

T

P

U

T

J

A

C

K

T

O

G

G

L

E

S

W

I

T

C

H

Copyright © 2020 - PedalPCB.com Page 5 of 5Triad Overdrive

Triad Overdrive

Drill Template

125B Enclosure

Body

Volume Drive

Gain
