Paradyne COMSPHERE 3610 Operation and maintenance manual

You have accessed an older version of a

Paradyne product document.

Paradyne is no longer a subsidiary of

AT&T. Any reference to AT&T Paradyne is

amended to read Paradyne Corporation.

dyn

November 1995

** SPECIAL NOTICE **

As part of AT&T Paradyne’s ongoing enhancement and quality program, the

COMSPHERE

3600 Series Data Service Unit (DSU), Models 3610 and 3611,

incorporates the following new features and engineering changes (EC).

LPDA Feature Standard

The SNA Diagnostic Interface, LPDA-2, is now a standard feature. Refer to the LPDA-2

Configuration Options table in Chapter 4 of your User’s Guide for details on enabling the

LPDA option.

6700 Series NMS Remote Access

Firmware releases 6.5x and above provide remote access of the Model 3610 front panel

from the 6700 Series NMS with NMS version 4.0.4 or higher.

Firmware Version

If the control DSU software version is less than 6.21 but greater than 1.10, the following

configuration option changes will need to be made:

If Control DSU is: If Tributary DSU is: Set Tributary

Release FW Version Release FW Version

Set Tributary

DSU’s SW Vers to:

2 3.xx 3 4.xx 3.20

2 3.xx 3.1 5.xx 3.21

3 4.xx 3.1 5.xx 4.40

2 3.xx 3.2 or 3.3 6.xx 3.22

3 4.xx 3.2 or 3.3 6.xx 4.41

3.1 5.xx 3.2 or 3.3 6.xx Normal

3.2 6.2x 3.2 6.2x Normal

3.3 6.33 & above 3.3 6.33 & above Normal

Dial Backup (DBM)

An additional configuration option, WaitAnswer, is now available in the DBM configuration

option set for 4-wire switched 56 DBM and DBM-S. The following is now the last

configuration option of the DBM Configuration Option table.

Document No. 3610-A2-GK42-00 Page 1 of 2

** SPECIAL NOTICE (continued) **

November 1995

WaitAnswer: 90ms (default)

Next 90ms 300ms 500ms 1s 2s 3s 4s 5s Prev

WaitAnswer

.Sets the time delay between the first ring received by the incoming call indication

and answer. Some central office switches require a delay to correctly recognize the DSU

answer signal.

90ms — The amount of time allowed between the incoming call indication and

to 5s answer response.

Async Terminal

When enabled, the interface supports a VT-100 compatible terminal with

9.6 kbps, 8 bits, 1 stop bit, and no parity.

The Async Terminal feature has several additional changes effective with firmware

version 6.44:

For uniformity, every configuration option presents Previous first and Next

second for selection screens.

The Top-Level Menu screen now displays LED status for Alarm, Backup, and

Test for the active core if a condition exists on the interface. As shown in the first

screen, each status will display if the LED is lit or blinking.

All screens display the option V/Ctrl-V to view current Health and Status.

Three input screens now have an amount-of-time prompt for specific user input.

The input field must be fully populated (all digits entered) as shown in the

second screen. The three screens where an amount of time is entered are

Digital Test Run Time, Configuration Diagnostic Tributary Time Out (TribTimOut),

and Configuration Backup Network Time Out (NtwkTimOut).

AT&T Paradyne LED Status

Customer ID: SITER818 Model: COMSPHERE 3610

Port1 DSU 9.6 C

1 – Local T/Ctrl–T=Top Menu

2 – Remot U/Ctrl–U=Up Menu

V/Ctrl–V=View H/S

PRESS Desired Selection Key Ctrl–x = Disconnect

Alrm Bkup Test

Please keep a copy of this notice with your product documentation.

Page 2 of 2 Document No. 3610-A2-GK42-00
