Paradyne Compshere 3000 Series Operation and maintenance manual

Document No. 3610-A2-GK40-22 Page 1 of 2

March 1997

** SPECIAL NOTICE **

As part of Paradyne’s ongoing enhancement and quality program, the COMSPHERE

3600 Series Data Service Unit (DSU) incorporates several new features. Firmware and

DSUs with firmware releases 8.xx and above provide:

Automatic detection of the DDS data rate. The factory-default for Rate(Kbps) is now

Auto. For maximum reliability and minimum power-up time, set the actual data rate

after installation.

Two additional factory default configuration sets are available for multipoint control

and multipoint tributary.

Each set of existing factory default configuration options has changed. Refer to

Table A-1 in Appendix A in each of the following documents:

3610-A2-GB46

3610-A2-GB48

3610-A2-GB49

When any change is made to a configuration and not saved, a prompt displays

asking the user: Save Options? or Save Changes?

Dial Tone Test is available from the Test branch for Dial Backup Modules (DBMs).

Reset is available from the Control branch to initiate a power-up routine.

Power On Test General configuration option. When disabled, the DSU bypasses

device tests.

Facility Alarms for crossed pair detection, no synchronization during auto-rating,

control mode idle, and rate conflict.

New Revision to COMSPHERE 3600 Series Product-Related Documentation

Document Name Number Description

COMSPHERE 3600 Series Data Service

Units, Models 3610 and 3611, User’s Guide 3610-A2-GB46 Ships with all standalone

3610 DSUs.

COMSPHERE 3600 Series Data Service

Units, Models 3610 and 3611, Time Division

Multiplexer, Multichannel Multipoint, and

Digital Bridge Options Supplement

3610-A2-GB48 Supplement to the User’s Guide.

Ships with Model 3610 DSUs with

MCMP/TDM options or upgrades.

COMSPHERE 3600 Series Data Service

Units, Models 3610 and 3611, Dial Backup

Module Options Supplement

3610-A2-GB49 Supplement to the User’s Guide.

Ships with Model 3610 DSUs with

Dial Backup Module (DBM) options

or upgrades.

COMSPHERE 3000 Series Carrier,

Installation Manual 3000-A2-GA31 Ships with every carrier.

Page 2 of 2 Document No. 3610-A2-GK40-22

** SPECIAL NOTICE (continued) **

Software and Firmware Version Control

The DSU software version now has an additional setting of 6.66. Use the new setting of

6.66 when the control DSU firmware version is 5.00 to 6.99 and the tributary DSU firmware

version is 7.25 or higher.

It is recommended that the control and tributary DSUs have the same firmware version or

that the control has the highest firmware version. If the control DSU software version is less

than 7.24 but greater than 1.10, changes are required to the DSU tributary firmware

version in the General configuration options.

If Control DSU is: If Tributary DSU is: Set Tributary

DSU

’

sSW

Supported

by 6700

Supported

by 6800

Release FW Version Release FW Version

DSU’s SW

Version to:

by 6700

Release

by 6800

Release

2 3.xx 3 4.xx 3.20 3.0/1.0 3.0

2 3.xx 3.1 5.xx 3.21 3.0/1.0 3.1

2 3.xx 3.2 or 3.3 6.xx 3.22 4.0.0/1.2 4.1

2 3.xx 3.4 7.xx 3.23 4.0.5/1.2.1 4.2.7

2 3.xx 3.5 8.xx 3.24 4.0.7/1.3 4.2.9

3 4.xx 3.1 5.xx 4.40 3.0/1.0 3.1

3 4.xx 3.2 or 3.3 6.xx 4.41 4.0.0/1.2 4.2.6

3 4.xx 3.4 7.xx 4.42 4.0.5/1.2.1 4.2.7

3 4.xx 3.5 8.xx 4.43 4.0.7/1.3 4.2.9

3.1 5.xx 3.1 5.xx Normal 3.0/1.0 3.1

3.1 5.xx 3.2 or 3.3 6.xx Normal 4.0.0/1.2 4.2.6

3.1 5.xx 3.4 7.xx 6.65 4.0.5/1.2.1 4.2.7

3.1 5.xx 3.5 8.xx 6.66 4.0.7/1.3 4.2.9

3.2 6.2x 3.2 6.2x Normal 3.0.10/1.1 4.1.6

3.2 6.2x 3.3 6.33–6.99 Normal 4.0.0/1.2 4.2.6

3.2 6.2x 3.4 7.xx 6.65 4.0.5/1.2.1 4.2.7

3.2 6.2x 3.5 8.xx 6.66 4.0.7/1.3 4.2.9

3.3 6.33–6.99 3.3 6.33–6.99 Normal 4.0.0/1.2 4.2.6

3.3 6.33–6.99 3.4 7.xx 6.65 4.0.5/1.2.1 4.2.7

3.3 6.33–6.99 3.5 8.xx 6.66 4.0.7/1.3 4.2.9

3.4 7.xx 3.4 7.xx Normal 4.0.5/1.2.1 4.2.7

3.4 7.xx 3.5 8.xx Normal 4.0.7/1.3 4.2.9

3.5 8.xx 3.5 8.xx Normal 4.0.7/1.3 4.2.9

Please keep a copy of this notice with your product documentation.



*3610–A2–GK40–22*
