Panasonic KV-S1045C User manual
Model No.
KV-S1045C
Installation Manual
These instructions contain information on installing the scanner. Please read this manual before installing the
unit.
For information on operating the scanner, please read the Operating Manual on the CD-ROM enclosed with this
unit.
Please carefully read this manual, and keep this documentation in a safe place for future reference.
High Speed Color Scanner
Introduction
Thank you for purchasing a Panasonic High Speed Color Scanner.
About the documentation
The scanner documentation consists of 2 manuals: the Installation Manual and the Operating Manual. In
addition, 3 software reference manuals are included.
Installation Manual
(this manual)
The Installation Manual explains the installation method and
procedures.
Operating Manual
(electronic documentation)
The Operating Manual explains the part names, operations, features
and maintenance of the unit.
Software Reference Manuals
(electronic documentation)
•PIE Reference Manual
Explains the settings of the PIE (Panasonic Image Enhancement
Technology) features using the ISIS and TWAIN drivers.
•RTIV Reference Manual
Explains the features and settings for RTIV (Reliable Throughput
Imaging Viewer). (You can view this manual by clicking the help
button on RTIV.)
•User Utility Reference Manual
Explains how to use the User Utility, which is used for scanner
maintenance. (You can view this manual by clicking the help
button on User Utility.)
•The electronic documentation is located on the included CD-ROM. For details on viewing the
documentation, see "Viewing Manuals From the CD-ROM" (page 18).
Abbreviations
•Windows® refers to the Microsoft® Windows® operating system (hereafter Windows).
•Windows® 2000 refers to the Microsoft® Windows® 2000 operating system (hereafter Windows 2000).
•Windows® XP refers to the Microsoft® Windows® XP operating system (hereafter Windows XP).
•Windows Vista® refers to the Microsoft® Windows Vista® operating system (hereafter Windows Vista).
2 Installation Manual
Introduction
Trademarks
•Microsoft, Windows, and Windows Vista are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
•ISIS and QuickScan are registered trademarks or trademarks of EMC Corporation in the United States
and other countries.
•IBM and AT are trademarks of International Business Machines Corporation in the United States, other
countries, or both.
•Pentium is a trademark of Intel Corporation in the U.S. and other countries.
•Adobe and Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the
United States and/or other countries.
•All other trademarks identified herein are the property of their respective owners.
International ENERGY STAR Program
As an ENERGY STAR®Partner, Panasonic has determined that this product meets
the ENERGY STAR guidelines for energy efficiency.
Installation Manual 3
Introduction
Federal Communications Commission Requirements (For United States
only)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
•The user may find the booklet "Something About Interference" available from FCC local regional offices
helpful.
FCC Warning: To assure continued FCC emission limit compliance, the user must use the recommended
shielded interfacing cable when connecting to a host computer. Also, any unauthorized changes or
modifications to this equipment would void the user's authority to operate this device.
FCC Declaration of Conformity
Trade Name: Panasonic
Model Number: KV-S1045C
Responsible Party: Panasonic Corporation of North America
One Panasonic Way
Secaucus, NJ 07094 U.S.A.
Telephone No.: 1-800-726-2797
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
For FRG Users (For Germany Only)
•Machine noise information regulation - 3.GPSGV, the maximum sound pressure level is 70 dB(A) or less,
in conformity with EN ISO 7779.
•This device is not intended for use in the direct field of view at visual display workplaces. To avoid
incommoding reflexions at visual display workplaces this device must not be placed in the direct field of
view.
4 Installation Manual
Introduction
Table of Contents
Before You Start .......................................................................................6
For Your Safety .................................................................................................................6
Safety Information (For United Kingdom only) ..............................................................8
Precautions ........................................................................................................................9
Installation ..............................................................................................11
Installing the Unit ............................................................................................................11
Installing Software ..........................................................................................................15
System Requirements ....................................................................................................15
CD-ROM Contents .........................................................................................................15
Software Installation .......................................................................................................16
Uninstalling Software ......................................................................................................17
Viewing Electronic Documentation ...............................................................................18
Viewing Manuals From the CD-ROM .............................................................................18
Viewing Manuals Installed On Your Computer ...............................................................18
Uninstalling Manuals ......................................................................................................18
Appendix .................................................................................................19
Troubleshooting ..............................................................................................................19
Installation Manual 5
Table of Contents
For Your Safety
To prevent severe injury and loss of life, read this
section carefully before using the unit to ensure proper
and safe operation of your unit.
•This section explains the graphic symbols used
in this manual.
WARNING
Denotes a potential
hazard that could
result in serious
injury or death.
CAUTION
Denotes hazards
that could result in
minor injury or
damage to the unit.
This symbol is used to alert
operators to a specific operating
procedure that must be
performed carefully.
These symbols are used to alert
operators to a specific operating
procedure that must not be
performed.
These symbols are used to alert
operators to a specific operating
procedure that must be
emphasized in order to operate
the unit safely.
For Users
WARNING
Power
The power source voltage of this unit is
listed on the nameplate.
Only plug the unit into an AC outlet with
the proper voltage.
If you use a cord with an unspecified
current rating, the unit or plug may emit
smoke or become hot to the touch.
When you operate this product, the power
outlet should be near the product and
easily accessible.
Connect the AC adaptor firmly to the
power cord, and plug the power cord
firmly into an AC outlet. Otherwise, it can
cause fire or electric shock.
Do not pull, bend, rest objects on, or chafe
the power cord, plug, and AC adaptor.
Damage to the power cord or plug can
cause fire or electric shock.
Do not attempt to repair the power cord,
plug, or AC adaptor. If the power cord or
plug is damaged or frayed, contact an
authorized service representative for a
replacement.
Ensure that the plug connection is free of
dust. In a damp environment, a
contaminated connector can draw a
significant amount of current that can
generate heat, and eventually cause fire
if left unattended over an extended period
of time.
Never touch the plug or AC adaptor with
wet hands.
Danger of electric shock exists.
6 Installation Manual
Before You Start
Before You Start
Stop operation immediately if the unit
emits smoke, excessive heat, abnormal
smell, or unusual noise. These conditions
can cause fire or electric shock.
Immediately turn the unit off, and unplug
the power cord, and contact your dealer
for service.
When disconnecting the unit, grasp the
plug instead of the cord. Pulling on a cord
forcibly can damage it, and cause fire or
electric shock.
Operating Safeguards
If metal fragments or water gets into the
unit, turn the unit off, and unplug the unit
immediately. Contact your dealer for
service. Operating the contaminated unit
can cause fire or electric shock.
Do not open covers, and do not attempt to
repair the unit yourself. Contact your
dealer for service.
Do not alter the unit or modify any parts.
Alteration or modification can cause fire or
electric shock.
During thunderstorms, do not touch the
unit, plug and AC adaptor. It may cause
an electric shock.
Roller Cleaning Paper
Do not drink or inhale the roller cleaning
paper fluid including isopropyl alcohol.
The roller cleaning paper may be harmful
to sensitive skin. Please use protective
gloves.
Do not use the roller cleaning paper near
a heater or open flame.
CAUTION
Power
The unit should be used only with the
power cord and AC adaptor enclosed with
the unit.
When the unit is not used over an
extended period of time, switch it off, and
unplug it. If an unused unit is left
connected to a power source for a long
period, degraded insulation may cause
electric shock, current leakage, or fire.
Installation and Relocation
Do not position the unit in a location where
it is unstable.
To prevent fire or shock hazard, do not
expose this unit to rain or any type of
moisture.
Do not place the unit in a hot humid or
dusty environment.
Prolonged exposure to these adverse
conditions may cause fire or electric
shock.
When moving the unit, be sure to unplug
the power cord from the AC outlet. If the
unit is moved with the power cord
attached, it can cause damage to the cord
which could result in fire or electric shock.
Do not use the exit tray hanging out of a
table.
When carrying the unit, do not use the
trays as handles.
Installation Manual 7
Before You Start
Operating Safeguards
If the unit falls down or gets damaged, turn
the unit off, and unplug the power cord.
Otherwise, it may cause fire or electric
shock.
Do not place any liquids or heavy items on
the unit.
Accidental spillage of liquid into the unit
may cause severe damage. If this occurs,
turn the unit off, unplug the power cord,
and contact your dealer for service.
Do not touch the scanning glass or their
surroundings immediately after
continuous scanning.
This area is very hot and can cause burns.
Safety Information (For
United Kingdom only)
This appliance is supplied with a moulded three pin
mains plug for your safety and convenience.
A 5 amp fuse is fitted in this plug. Should the fuse need
to be replaced, please ensure that the replacement fuse
has a rating of 5 amps and that it is approved by ASTA
or BSI to BS1362. Check for the ASTA mark
ASA
or the
BSI mark on the body of the fuse. And you must refit
the fuse cover when the fuse is replaced. If you lose the
fuse cover, the plug must not be used.
How to replace the fuse:
Open the fuse compartment with a screwdriver and
replace the fuse and fuse cover.
8 Installation Manual
Before You Start
Precautions
Installation
•Do not place the unit in direct sunlight, in a cold
draft, or near heating apparatus.
•Do not place the unit near apparatus which
generate electronic or magnetic noise.
•Protect the unit from static electricity.
•Do not move the unit immediately from a cold place
to a warm place. It may cause dew.
CD-ROM
•Do not write or stick paper on the front and/or back
of CD-ROM.
•Do not touch the data side of the CD-ROM. When
handling the CD-ROM, be careful not to leave
fingerprints or otherwise damage the CD-ROM.
•Do not leave the CD-ROM where it is directly
exposed to sunlight or near a heater for extended
periods.
•Do not throw or bend the CD-ROM.
Roller Cleaning Paper
•Keep the roller cleaning paper out of reach of small
children.
•Do not store the roller cleaning paper in direct
sunlight or in a place with a temperature over
40
°C
(104 °F).
•Only use the roller cleaning paper to clean the
rollers and scanning glass.
•For details about the roller cleaning paper, please
refer to the Material Safety Data Sheet (MSDS).
Please ask your Panasonic sales company about
obtaining the Material Safety Data Sheet.
KEEP AWAY FROM FIRE.
Others
•Make sure to remove paper clips and staples from
documents before scanning. Failing to do so can
damage the unit, document, or both.
•Do not use thinner, benzine, or cleaners containing
abrasives or surfactants, for cleaning the outside of
scanner.
•Plug the power cord into an outlet from which you
can easily unplug it.
Installation Manual 9
Before You Start
Illegal Duplication
It is unlawful to make duplication of certain
documents.
Duplicating certain documents may be illegal in
your country/area.
Penalties of fines and/or imprisonment may be
imposed on those found guilty. The following are
examples of items that may be illegal to duplicate
in your country/area.
•Currency
•Bank notes and checks
•Bank and government bonds, and securities
•Passports, licenses, official or private
documents, identification cards, and the like
•Copyright materials, or trademarks without
the consent of the owner
•Postage stamps, and other negotiable
instruments
This list is not inclusive, and no liability is
assumed for either its completeness or accuracy.
In case of doubt, contact your legal counsel.
Notice
Install your machine near a supervised area
to prevent illegal duplication from being
made.
Security Notice
The management of documents and scanned data is
the responsibility of the user. In particular, pay attention
to the following points.
•Make sure you have the same number of pages for
important documents both before and after
scanning, and take care not to leave any pages in
the scanner.
•Periodically back up important data.
•When having your computer or hard disk serviced,
or when disposing of your computer or hard disk,
completely erase any stored image data.
Caution Labels
HOT SURFACE
DO NOT TOUCH.
The glass in the scanning area becomes very hot.
Exercise care not to touch heated areas, or you may get
burned.
CAUTION
10 Installation Manual
Before You Start
Other manuals for KV-S1045C
2
Table of contents
Other Panasonic Scanner manuals
Panasonic
Panasonic KV-S2045C User manual
Panasonic
Panasonic KV-S1046C User manual
Panasonic
Panasonic KV-S1037 User manual
Panasonic
Panasonic KV-S2025C User manual
Panasonic
Panasonic KV-S7097 Installation and operating manual
Panasonic
Panasonic KV-S1057C User manual
Panasonic
Panasonic KV-S1027C Operating instructions
Panasonic
Panasonic Camescope KV-S1025C Operating and maintenance instructions
Panasonic
Panasonic KV-S4065CL - Sf Clr Duplex 65PPM USB 2.0 Lgl 300PG... User manual
Panasonic
Panasonic KV-S1015C User manual
Panasonic
Panasonic KV-S2065L User manual
Panasonic
Panasonic KV-S1065C User manual
Panasonic
Panasonic KV-S2048C User manual
Panasonic
Panasonic KV-S6040W - Document Scanner User manual
Panasonic
Panasonic KV-S5055C User manual
Panasonic
Panasonic KV-S7075C User manual
Panasonic
Panasonic KV-S6040W - Document Scanner User manual
Panasonic
Panasonic KV-S2028C User manual
Panasonic
Panasonic KV-S3065CL - Document Scanner User manual
Panasonic
Panasonic KV-S1046C User manual
