Panasonic CS-YE18NKV-7 User manual

Panasonic Appliances Air-Conditioning Malaysia

Sdn. Bhd. 2012. Unauthorized copying and distribution

is a violation of law.

parcial do conteúdo deste manual.

F568382

QUICK GUIDE

GUΙA RÁPIDO

Operating Instructions

Air Conditioner

Manual de Instruções

Condicionador de ar

Model No.

Modelo

Indoor Unit Outdoor Unit

Unidade Interna Unidade Externa

CS-YE18NKV-7 CU-YE18NKV-7

CS-YE23NKV-7 CU-YE23NKV-7

ENGLISH

Before operating the unit, read these operating

instructions thoroughly and keep them for future

reference.

PORTUGUÊS (BR)

Antes de ligar a unidade, leia cuidadosamente

este manual de instruções e guarde-o para futura

referência.

ENGLISH Thank you for purchasing Panasonic Air Conditioner

TABLE OF CONTENTS

OPERATION CONDITION

SAFETY PRECAUTIONS 4~5

REMOTE CONTROL 6

INDOOR UNIT 7

TROUBLESHOOTING 8

INFORMATION 9

QUICK GUIDE BACK COVER

NOTE : The illustrations in this manual are for explanation purposes only and may differ from the actual unit. They are

subjected to change without notice for future improvement.

PORTUGUÊS (BR) Obrigado por adquirir o Condicionador de ar da Panasonic

ÍNDICE

CONDIÇÃO DE FUNCIONAMENTO

PRECAUÇÕES DE SEGURANÇA 10~11

CONTROLE REMOTO 12

UNIDADE INTERNA 13

SOLUÇÃO DE PROBLEMAS 14

INFORMAÇÕES 15

GUIA RÁPIDO CONTRACAPA

NOTA : As ilustrações deste manual têm apenas caráter explicativo e podem diferir da unidade real. Estão sujeitas a

alterações sem aviso prévio para ﬁns de melhoramento.

TABLE OF CONTENTS OPERATION CONDITION

OPERATION CONDITION

Use this air conditioner under the following temperature range

Temperature (°C) Indoor Outdoor

* DBT: Dry bulb temperature

* WBT: Wet bulb temperature

*DBT *WBT *DBT *WBT

COOLING Max. 32 23 43 26

Min. 16 11 16 11

HEATING Max. 30 - 24 18

Min. 16 - -5 -6

ÍNDICE CONDIÇÃO DE FUNCIONAMENTO

CONDIÇÃO DE FUNCIONAMENTO

Utilize este condicionador de ar nas seguintes faixas de temperaturas

Temperatura (°C) Interna Externa

* DBT:Temperatura de bulbo

Seco

* WBT:Temperatura de bulbo

úmido

*DBT *WBT *DBT *WBT

REFRIGERAÇÃO Máx. 32 23 43 26

Mín. 16 11 16 11

AQUECIMENTO Máx. 30 - 24 18

Mín. 16 - -5 -6

SAFETY PRECAUTIONS

To prevent personal injury, injury to others, or property

damage, please comply with the following.

Incorrect operation due to failure to follow instructions below

may cause harm or damage, the seriousness of which is

classiﬁed as below:

WARNING

This sign warns of death or serious injury.

CAUTION

This sign warns of injury or damage to property.

The instructions to be followed are classiﬁed by the following

symbols:

This symbol denotes an action that is PROHIBITED.

These symbols denote an actions that is

COMPULSORY.

WARNING

INDOOR UNIT AND OUTDOOR UNIT

This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities, or lack

of experience and knowledge, unless they have

been given supervision or instruction concerning

use of the appliance by a person responsible for

their safety. Children should be supervised to

ensure that they do not play with the appliance.

Please consult authorized dealer or specialist to

clean the internal parts, repair, install, remove

and reinstall the unit. Improper installation and

handling will cause leakage, electric shock or

ﬁre.

Conﬁrm to authorized dealer or specialist on

usage of speciﬁed refrigerant type. Using of

refrigerant other than the speciﬁed type may

cause product damage, burst and injury etc.

Do not install the unit in a potentially explosive

or ﬂammable atmosphere. Failure to do so could

result in ﬁre.

Do not insert your ﬁngers or other

objects into the air conditioner indoor

or outdoor unit, rotating parts may

cause injury.

Do not touch the outdoor unit during lightning, it

may cause electric shock.

Do not expose yourself directly to cold air for a

long period to avoid excess cooling.

Do not sit or step on the unit, you may

fall down accidentally.

REMOTE CONTROL

Do not allow infants and small children to play

with the remote control to prevent them from

accidentally swallowing the batteries.

POWER SUPPLY

Do not use a modiﬁed cord,

joint cord, extension cord or

unspeciﬁed cord to prevent

overheating and ﬁre.

To prevent overheating, ﬁre or electric shock:

• Do not share the same power outlet with other

equipment.

• Do not operate with wet hands.

• Do not over bend the power supply cord.

• Do not operate or stop the unit by inserting or

pulling out the power plug.

Air Inlet

Air Outlet

Air Inlet

Outdoor

Unit

Indoor

Unit

Power

Supply

Remote

Control

ENGLISH

CAUTION

INDOOR UNIT AND OUTDOOR UNIT

Do not wash the indoor unit with water, benzene,

thinner or scouring powder to avoid damage or

corrosion at the unit.

Do not use for preservation of precise

equipment, food, animals, plants, artwork

or other objects. This may cause quality

deterioration, etc.

Do not use any combustible equipment in front of

the airﬂow outlet to avoid ﬁre propagation.

Do not expose plants or pet directly to airﬂow to

avoid injury, etc.

Do not touch the sharp aluminium ﬁn,

sharp parts may cause injury.

Do not switch ON the indoor unit when waxing

the ﬂoor. After waxing, aerate the room properly

before operating the unit.

Do not install the unit in oily and smoky areas to

prevent damage to the unit.

Do not dismantle the unit for cleaning purpose to

avoid injury.

Do not step onto an unstable bench when

cleaning the unit to avoid injury.

Do not place a vase or water container on the

unit. Water may enter the unit and degrade the

insulation. This may cause an electric shock.

Do not open window or door for long time during

COOL mode operation.

Ensure drainage pipe is connected properly and

keep drainage outlet clear of gutters, containers

or does not immersed in water to prevent water

leakage.

After a long period of use or use with any

combustible equipment, aerate the room

regularly.

After a long period of use, make sure the

installation rack does not deteriorate to prevent

the unit from falling down.

REMOTE CONTROL

Do not use rechargeable (Ni-Cd) batteries.

It may damage the remote control.

To prevent malfunction or damage of the remote

control:

• Remove the batteries if the unit is not going to

be used for a long period of time.

• New batteries of the same type must be

inserted following the polarity stated.

POWER SUPPLY

Do not pull the cord to disconnect the plug to

prevent electric shock.

WARNING

POWER SUPPLY

If the supply cord is damage, it must be replaced

by the manufacturer, its service agent or similarly

qualiﬁed persons in order to avoid a hazard.

It is strongly recommended to be installed

with Earth Leakage Circuit Breaker (ELCB)

or Residual Current Device (RCD) to prevent

electric shock or ﬁre.

To prevent overheating, ﬁre or electric shock:

• Insert the power plug properly.

• Dust on the power plug should be periodically

wiped with a dry cloth.

Stop using the product if any abnormality/failure

occurs and disconnect the power plug or turn off

the power switch and breaker.

(Risk of smoke/ﬁre/electric shock)

Examples of abnormality/failure

• The ELCB trips frequently.

• Burning smell is observed.

• Abnormal noise or vibration of the unit is

observed.

• Water leaks from the indoor unit.

• Power cord or plug becomes abnormally hot.

• Fan speed cannot be controlled.

• The unit stops running immediately even if it is

switched on for operation.

• The fan does not stop even if the operation is

stopped.

Contact your local dealer immediately for

maintenance/repair.

This equipment must be earthed to prevent

electrical shock or ﬁre.

Prevent electric shock by switching off the power

supply and unplug when:

- Before cleaning or servicing.

- Extended non-use.

- Abnormally strong lightning activity.

REMOTE CONTROL

Maximum distance: 8m

INDICATOR

POWER

(Green)

6TO SET THE TIMER

• To turn ON the unit at a preset time, set the timer while

the unit is OFF.

• To turn OFF the unit at a delayed time, set the timer while

the unit is ON.

Press twice →Press repeatedly to set your desired time

• Once the timer is set, the TIMER indication on the remote

control display will be shown.

• To check the remaining time before the timer takes effect,

press TIMER .

• To cancel the timer, press TIMER once, then press again

and hold for approximately 3 seconds.

• The timer will also be canceled when you press

OFF/ON

when power failure occurs.

• This setting is for one time operation, you will need to set

again each time you want to use the timer.

Press the remote control’s button

1TO TURN ON OR OFF THE UNIT

• Please be aware of the OFF indication on the remote

control display to prevent the unit from starting/stopping

improperly.

2TO SET TEMPERATURE

• The range of temperature for selection is 16°C ~ 30°C.

• Recommended temperature for energy saving:

HEAT mode: 20°C ~ 24°C.

COOL mode: 26°C ~ 28°C.

3TO SELECT OPERATION MODE

AUTO mode - For your convenience

• Unit selects the operation mode according to temperature

setting, outdoor and room temperature.

• Operation mode is reselected every 30 minutes. During

operation mode selection the power indicator blinks.

HEAT mode - To enjoy warm air

• Unit takes a while to warm up. The power indicator blinks

during this operation.

COOL mode - To enjoy cool air

• Use curtains to screen off sunlight and outdoor heat to

reduce power consumption during cool mode.

4TO SELECT FAN SPEED (3 OPTIONS)

FAN

PEED

• For AUTO, the indoor fan speed is automatically adjusted

according to the operation mode.

5TO ADJUST VERTICAL AIRFLOW DIRECTION

(5 OPTIONS)

AIR SWING

• Keeps the room ventilated.

• If AUTO is set, the louver swing up/down automatically.

• In HEAT mode, if AUTO is set, the horizontal louver ﬁx at

predetermined position.

OFF/ON

TEMP

AIR SWING

TIMER

MODE

FAN SPEED

AUTO

HEAT

COOL

TIMER

Remote Control display

444444444

ENGLISH

CAUTION

•Switch off the power supply and unplug before cleaning.

•Do not touch the aluminium ﬁn, sharp parts may cause injury.

INDOOR UNIT

CLEANING

INSTRUCTIONS

HINT

• Do not use benzene, thinner or scouring powder.

• Use only soap ( pH7) or neutral household detergent.

• Do not use water hotter than 40°C.

• To ensure optimal performance of the unit, cleaning

maintenance has to be carried out at regular intervals.

Dirty unit may cause malfunction and you may see error

code “H99”. Please consult authorized dealer.

1INDOOR UNIT

• Wipe the unit gently with a soft, dry cloth.

2FIXED PANEL

• Could not be removed.

3FIXED FILTER

• Could not be removed.

• Wipe the ﬁlter gently with a soft damp cloth.

4AIR FILTERS

• Air ﬁlter cleaning is required every two weeks.

• Wash/rinse the ﬁlters gently with water to avoid damage

to the ﬁlter surface.

• Dry the ﬁlters thoroughly under shade, away from ﬁre or

direct sunlight.

• Replace any damaged ﬁlters.

5HORIZONTAL AIRFLOW DIRECTION LOUVER

• Manually adjustable.

6VERTICAL AIRFLOW DIRECTION LOUVER

• Do not adjust by hand.

7REMOTE CONTROL RECEIVER

8AUTO OFF/ON BUTTON

• Used when remote control is misplaced or a malfunction

occurs.

Action Mode

Press once. Auto

Press and hold until 1 beep is

heard, then release. Cooling

Press and hold until 1 beep is

heard, then release.

Press again until 2 beeps, then

release.

Heating

Press the button to turn off.

AUTO

OFF/ON

POWER

The following symptoms do not indicate malfunction.

SYMPTOM

CAUSE

Mist emerges from indoor unit. ►• Condensation effect due to cooling process.

Water ﬂowing sound during operation. ►• Refrigerant ﬂow inside the unit.

The room has a peculiar odor. ►• This may be due to damp smell emitted by the wall,

carpet, furniture or clothing.

Indoor fan stops occasionally during automatic fan speed

setting.

►• This helps to remove the surrounding odours.

Operation is delayed a few minutes after restarting. ►• The delay is a protection to the unit’s compressor.

Outdoor unit emits water/steam. ►• Condensation or evaporation occurs on pipes.

Indoor fan stops occasionally during heating operation. ►• To avoid unintended cooling effect.

Cracking sound during operation. ►• Changes of temperature caused the expansion/

contraction of the unit.

Check the following before calling for servicing.

SYMPTOM

CHECK

Heating/Cooling operation is not working efﬁciently. ►• Set the temperature correctly.

• Close all doors and windows.

• Clean or replace the ﬁlters.

• Clear any obstruction at the air inlet and air outlet vents.

Noisy during operation. ►• Check if the unit has been installed at an incline.

• Insert the air ﬁlter properly.

Remote control does not work.

(Display is dim or transmission signal is weak.)

►• Insert the batteries correctly.

• Replace weak batteries.

The unit does not work. ►• Check if the circuit breaker is tripped.

• Check if timers have been set.

The unit does not receive the signal from the remote

control.

►• Make sure the receiver is not obstructed.

• Certain ﬂuorescent lights may interfere with signal

transmitter. Please consult authorized dealer.

TROUBLESHOOTING

ENGLISH

Primary Battery

Attention:

Check the instructions of use of the product conﬁrming if the polarities (+) and (-) are according

to the indicated direction. Batteries can leak or explode if polarities were inverted, exposed to ﬁre,

disassembled or recharged.

Avoid mixing with other types of batteries or used batteries, carry or store them unattached, because

it increases the risk of leaking.

Take out the batteries from the product if it were not being used, to avoid possible damage in case

leak happens.

Batteries should be stored in dry and ventilated places.

In case leak happens to the battery, avoid touching it. Wash the affected part of the body with plenty

water. If irritation occurs, look for medical aid.

Don’t remove the wrapping of the battery.

Information for Users on Collection and Disposal of Old Equipment and used Batteries

[Information on Disposal in other Countries

outside the European Union]

These symbols are only valid in the European

Union. If you wish to discard these items,

please contact your local authorities or dealer

and ask for the correct method of disposal.

Note for the battery symbol (bottom two

symbol examples):

This symbol might be used in combination with

a chemical symbol. In this case it complies with

the requirement set by the Directive for the

chemical involved.

INFORMATION

FOR SEASONAL INSPECTION AFTER EXTENDED NON-USE

• Checking of remote control batteries.

• No obstruction at air inlet and air outlet vents.

• Use Auto OFF/ON button to select Cooling/Heating operation.

After 15 minutes of operation, it is normal to have the following

temperature difference between air inlet and air outlet vents:

Cooling: ≥8°C Heating: ≥14°C

FOR EXTENDED NON-USE

• Activate Heat mode for 2~3 hours as an alternative to remove

moisture left in the internal parts thoroughly to prevent mould

growth.

• Turn off the power supply and unplug.

• Remove the remote control batteries.

NON SERVICEABLE CRITERIAS

TURN OFF POWER SUPPLY AND UNPLUG then

please consult authorized dealer under the following

conditions:

• Abnormal noise during operation.

• Water/foreign particles have entered the remote

control.

• Water leaks from Indoor unit.

• Circuit breaker switches off frequently.

• Power cord becomes unnaturally warm.

• Switches or buttons are not functioning properly.

PRECAUÇÕES DE SEGURANÇA

Para evitar lesões pessoais, lesões a outras pessoas, ou

danos materiais, siga as seguintes informações.

A utilização incorreta devido ao descumprimento das

instruções pode resultar em ferimentos ou danos cuja

gravidade é classiﬁcada da seguinte forma:

AVISO

Este símbolo indica perigo letal ou ferimento grave.

CUIDADO

Este símbolo indica perigo de ferimento ou danos materiais.

As instruções a seguir são classiﬁcadas com os seguintes

símbolos:

Este símbolo indica uma ação PROIBIDA.

Este símbolo indica uma ação que é OBRIGATÓRIA.

AVISO

UNIDADE INTERNA E UNIDADE EXTERNA

Este dispositivo não se destina ao uso por

pessoas (incluindo crianças) com reduzidas

capacidades físicas, sensoriais ou mentais, ou

falta de experiência e conhecimento, exceto se

tiverem supervisão ou instrução relacionadas

com o uso do dispositivo por uma pessoa

responsável pela sua segurança. As crianças

devem ser supervisionadas para assegurar que

não brinquem com o dispositivo.

Consulte um revendedor autorizado ou

especialista para limpar as peças internas,

reparar, instalar, remover e reinstalar a unidade.

A instalação e manuseio incorretos causarão

vazamento, choque elétrico ou fogo.

Conﬁrme para o revendedor autorizado ou para

o especialista a utilização do tipo de refrigerante

especiﬁcado. O uso de um refrigerante diferente

do tipo especiﬁcado pode causar danos ao

produto, explosão, ferimentos, etc.

Não instale a unidade num ambiente

potencialmente explosivo ou inﬂamável. A

inobservância deste aviso poderá resultar num

incêndio.

Não insira seus dedos ou outros objetos

na unidade interna ou na unidade

externa do condicionador de ar, as

peças rotativas podem causar lesões.

Não toque na unidade externa durante

trovoadas, pode causar choque elétrico.

Não se exponha diretamente ao ar frio por

um longo período para evitar resfriamento

excessivo.

Não se sente na unidade nem utilize-a

como um degrau, você poderá cair

acidentalmente.

CONTROLE REMOTO

Não deixe as crianças brincarem com o

controle remoto para impedir que engulam

acidentalmente as pilhas.

FONTE DE ALIMENTAÇÃO

Não use um cabo modiﬁcado,

cabo de união, cabo de

extensão ou cabo não

especiﬁcado para evitar

sobreaquecimento ou

incêndio.

Para impedir sobreaquecimento, fogo ou choque

elétrico:

• Não compartilhe a mesma tomada de

alimentação com outro equipamento.

• Não opere com as mãos úmidas.

• Não dobre o cabo da fonte de alimentação.

• Não opere ou pare a unidade ao inserir ou

retirar o plugue de alimentação.

Saída

de ar

Entrada de ar

Unidade

Externa

Unidade

Interna

Fonte de

alimentação

Controle

Remoto

Saída

de ar

Entrada de ar

This manual suits for next models

Table of contents

Languages:

Other Panasonic Air Conditioner manuals

Panasonic

Panasonic CS-RE9UKA User manual

Panasonic

Panasonic U-6LA1E5-1 User manual

Panasonic

Panasonic U-8ME1E81 User manual

Panasonic

Panasonic S-22YA1E5 User manual

Panasonic

Panasonic CS-NZ25YKE User manual

Panasonic

Panasonic S-60PT2R5 User manual

Panasonic

Panasonic U-8ME2R8 User manual

Panasonic

Panasonic CW-XC65HU; CW-XC85HU User manual

Panasonic

Panasonic CU-UV5RKP User manual

Panasonic

Panasonic CS-C45FFP8 User manual

Panasonic

Panasonic CS-XE7JKEW User manual

Panasonic

Panasonic CS-A12CKP User manual

Panasonic

Panasonic PZH2 User manual

Panasonic

Panasonic CW-C51LE User manual

Panasonic

Panasonic CU-FZ25WKE User manual

Panasonic

Panasonic CU-J50DBE8 User manual

Panasonic

Panasonic CW-A120FR User manual

Panasonic

Panasonic R410A User manual

Panasonic

Panasonic S-36PT2E5B User manual

Panasonic

Panasonic S-45MK2E5A User manual

Panasonic

Panasonic CW-XC105HU User manual

Panasonic

Panasonic CS-C28JKV User manual

Panasonic

Panasonic CS-C28GKF User manual

Panasonic

Panasonic CU-TE12HKE User manual

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

nedis

nedis ACMB1WT7 quick start guide

Samsung

Samsung AR KV Series User & installation manual

Daikin

Daikin FCFV50A Operation manual

Fujitsu

Fujitsu Inverter ASBA30JFC operating manual

Toshiba

Toshiba RAS-M10SMUV-E installation manual

Daikin

Daikin FXLQ20MAVE Operation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Frigidaire

Frigidaire FFRE0533S1E0 Use & care guide

Samsung

Samsung AS09HM3N user manual

Frigidaire

Frigidaire CRA073PU11 use & care

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual

Webasto

Webasto Frigo Top 25 DS Instructions for use
