Panasonic CS-TE12DKE User manual

1 Features 2

2 Functions 3

2.1. Remote Control 3

2.2. Indoor Unit 4

2.3. Outdoor unit 5

3 Product Specifications 6

4 Dimensions 10

4.1. Indoor Unit 10

4.2. Outdoor Unit 11

5 Refrigeration Cycle Diagram 12

6 Block Diagram 13

7 Wiring Diagram 14

7.1. CS-TE9DTE / CS-TE12DKE 14

rights reserved. Unauthorized copying and

distribution is a violation of law.

CS-TE9DKE CU-TE9DKE

CS-TE12DKE CU-TE12DKE

7.2. CU-TE9DKE / CU-TE12DKE 15

8 Electronic Circuit Diagram 16

8.1. Indoor Unit / Remote Controller 16

8.2. Outdoor Unit 18

9 Operation Details 20

9.1. BASIC FUNCTION 20

9.2. Indoor Power Relay Control 21

9.3. Room Air Temperature Control (Compressor Control) 21

9.4. Airflow Direction Control 23

9.5. Quiet operation (Cooling Mode / Cooling area of Dry

Mode) 24

9.6. Indoor Fan Control 26

9.7. Powerful Operation 29

Air Conditioner

CONTENTS

Page Page

Order No. RAC0502005C2

9.8. Automatic Operation 30

9.9. Timer Operation (24H Real Timer) 31

9.10. Auto Restart Control 31

9.11. Ionizer Operation 32

9.12. Protection Control 33

10 Operating Instructions 34

11 Installation Instructions 40

11.1. SAFETY PRECAUTIONS 40

11.2. INDOOR UNIT 43

11.3. OUTDOOR UNIT 46

12 Installation and Servicing Air Conditioner Using R410A 49

12.1. OUTLINE 49

12.2. TOOLS FOR INSTALLING/SERVICING REFRIGERANT

PIPING 50

12.3. REFRIGERANT PIPING WORK 54

•

• •

• Product

−

− −

− Microcomputer-controlled compressor operating

frequency.

−

− −

− Vertical airflow direction.

−

− −

− Four modes of operation selection.

−

− −

− Air filter with function to reduce dust and smoke.

−

− −

− SUPER Alleru-buster filter inactive various harmful

airborne elements including allergens, viruses and

bacteria.

−

− −

− Ionizer control for generate negative ion in discharge air.

−

− −

− Quiet mode to provide quiet operation.

−

− −

− 24-hour timer setting.

−

− −

− Long installation piping up to 15 meters.

•

• •

• Quality Improvement

−

− −

− Random auto restart after power failure for safety restart

operation.

−

− −

− Gas leakage detection.

•

• •

• Serviceability

−

− −

− Removable and washable front panel.

−

− −

− Breakdown self diagnosis function.

•

• •

• Environmental Protection

−

− −

− Non-ozone depletion substances refrigerant (R410A).

12.4. INSTALLATION, TRANSFERRING, SERVICING 57

13 Servicing Information 61

13.1. About Lead Solder (PbF) 61

13.2. TROUBLESHOOTING 62

13.3. BREAKDOWN SELF DIAGNOSIS FUNCTION 64

13.4. DISASSEMBLY OF PARTS 66

14 Technical Data 74

14.1. Operation Characteristics 74

14.2. Sensible Capacity Chart 76

15 Exploded View and Replacement Parts List 77

15.1. Exploded View (Indoor Unit) 77

15.2. Replacement Parts List (Indoor Unit) 78

15.3. Exploded View (Outdoor Unit) 79

15.4. Replacement Parts List (Outdoor Unit) 80

1 Features

CS-TE9DKE CU-TE9DKE / CS-TE12DKE CU-TE12DKE

2 Functions

2.1. Remote Control

CS-TE9DKE CU-TE9DKE / CS-TE12DKE CU-TE12DKE

2.2. Indoor Unit

CS-TE9DKE CU-TE9DKE / CS-TE12DKE CU-TE12DKE

2.3. Outdoor unit

CS-TE9DKE CU-TE9DKE / CS-TE12DKE CU-TE12DKE

3 Product Specifications

Unit CS-TE9DKE CU-TE9DKE

Cooling Capacity kW

kcal/h

BTU/h

2.60 (0.60 - 3.00)

2,240 (520 - 2,580)

8,870 (2,050 - 10,200)

Heating Capacity kW

kcal/h

BTU/h

3.60 (0.60 - 5.30)

3,100 (520 - 4,560)

12,300 (2,050 - 18,100)

Moisture Removal l/h

Pint/h

1.5

(3.2)

Power Source Phase

Cycle

Single

230/240

Airflow Method OUTLET

INTAKE

SIDE VIEW TOP VIEW

Air Volume Indoor Air (Lo) m3/min (cfm) Cooling; 5.3 (190) —

Heating; 6.2 (220)

Indoor Air (Me) m3/min (cfm) Cooling; 7.2 (250) —

Heating; 8.4 (290)

Indoor Air (Hi) m3/min (cfm) Cooling; 9.2 (320) —

Heating; 10.5 (370)

dB (A) Cooling; High 39, Low 26 Cooling; 46

Heating; High 40, Low 27 Heating; 47

Noise Level

Power level dB Cooling; High 50 Cooling; High 59

Heating; High 51 Heating; High 60

Electrical Data Input W Cooling; 580 (120 - 720)

Heating; 845 (115 - 1,360)

Running Current ACooling; 2.7

Heating; 3.9

EER W/W (kcal/hw), BTU/hw Cooling; 4.48(3.86), 15.3

COP W/W (kcal/hw), BTU/hw Heating; 4.26 (3.67), 14.5

Starting Current A 3.9

Piping Connection Port

(Flare piping)

inch

G ; Half Union 3/8”

L ; Half Union 1/4”

G ; 3-way valve 3/8”

L ; 2-way valve 1/4”

Pipe Size

(Flare piping)

inch

G (gas side) ; 3/8”

L (liquid side) ; 1/4”

G (gas side) ; 3/8”

L (liquid side) ; 1/4”

CS-TE9DKE CU-TE9DKE / CS-TE12DKE CU-TE12DKE

Unit CS-TE9DKE CU-TE9DKE

Drain

Hose

Inner diameter mm 16 —

Length m 0.65 —

Power Cord Length

Number of core-wire

2.0 m

3-core wires × 1.0 mm2

—

Dimensions Height inch (mm) 11 - 23/32 (298) 21 - 1/4 (540)

Width inch (mm) 31 - 15/32 (799) 30 - 23/32 (780)

Depth inch (mm) 5 - 15/32 (139) 11 - 3/8 (289)

Net Weight lb (kg) 18 (8) 73 (33)

Compressor Type — Involute scroll

Motor Type —Brushless (4-poles)

Rated Output W — 750

Air Circulation Type Cross-flow Fan Propeller Fan

Material AS + Glass Fiber 30% P.P

Motor Type Transistor (8-poles) Transistor (8-poles)

Input W — —

Rate Output W 30 40

Fan Speed Lo (Cool/Heat) rpm 800 / 840 —

Me (Cool/Heat) rpm 1,000 / 1,040 —

Hi (Cool/Heat) rpm 1,200 / 1,270 790

Heat Exchanger Description Evaporator Condenser

Tube material Copper Copper

Fin material Aluminium (Pre Coat) Aluminium (Pre Coat)

Fin Type Slit Fin Corrugated Fin

Row / Stage (Plate fin configuration, forced draft)

2 rows / 11 stages,

1 row / 4 stages

2 rows / 24 stages

FPI 23 16.5

Size (W × H × L) mm 640 × 304 × 25.4 + 12.7 725.8

694.6

× 504 × 36.4

Refrigerant Control Device — Expansion valve

Refrigeration Oil (c.c) — RB68A (400)

Refrigerant (R410A) g (oz) — 960 (33.9)

Thermostat Electronic Control Electronic Control

Protection Device Electronic Control Electronic Control

Length mm — —

Capillary Tube Flow Rate l/min — —

Inner Diameter mm — —

Air Filter Material

Style

P.P.

Honeycomb

—

•

• •

• Specifications are subject to change without notice for further improvement.

CS-TE9DKE CU-TE9DKE / CS-TE12DKE CU-TE12DKE

Unit CS-TE12DKE CU-TE12DKE

Cooling Capacity kW

kcal/h

BTU/h

3.50 (0.60 - 4.00)

3,010 (520 - 3,440)

11,950 (2,050 - 13,600)

Heating Capacity kW

kcal/h

BTU/h

4.80 (0.60 - 6.50)

4,130 (520 - 5,590)

16,400 (2,050 - 22,200)

Moisture Removal l/h

Pint/h

2.0

(4.2)

Power Source Phase

Cycle

Single

230/240

Airflow Method OUTLET

INTAKE

SIDE VIEW TOP VIEW

Air Volume Indoor Air (Lo) m3/min (cfm) Cooling; 6.1 (210) —

Heating; 8.2 (290)

Indoor Air (Me) m3/min (cfm) Cooling; 7.9 (280) —

Heating; 9.5 (330)

Indoor Air (Hi) m3/min (cfm) Cooling; 9.9 (350) —

Heating; 10.9 (380)

dB (A) Cooling; High 42, Low 29 Cooling; 48

Heating; High 42, Low 33 Heating; 50

Noise Level

Power level dB Cooling; High 53 Cooling; High 61

Heating; High 53 Heating; High 63

Electrical Data Input W Cooling; 900 (120 - 1,160)

Heating; 1,320 (115 - 1,880)

Running Current ACooling; 4.2

Heating; 6.2

EER W/W (kcal/hw), BTU/hw Cooling; 3.89 (3.34), 13.3

COP W/W (kcal/hw), BTU/hw Heating; 3.64 (3.13), 12.4

Starting Current A 6.2

Piping Connection Port

(Flare piping)

inch

G ; Half Union 1/2”

L ; Half Union 1/4”

G ; 3-way valve 1/2”

L ; 2-way valve 1/4”

Pipe Size

(Flare piping)

inch

G (gas side) ; 1/2”

L (liquid side) ; 1/4”

G (gas side) ; 1/2”

L (liquid side) ; 1/4”

Drain

Hose

Inner diameter mm 16 —

Length m 0.65 —

Power Cord Length

Number of core-wire

2.0 m

3-core wires × 1.0 mm2

—

CS-TE9DKE CU-TE9DKE / CS-TE12DKE CU-TE12DKE

Unit CS-TE12DKE CU-TE12DKE

Dimensions Height inch (mm) 11 - 23/32 (298) 21 - 1/4 (540)

Width inch (mm) 31 - 15/32 (799) 30 - 23/32 (780)

Depth inch (mm) 5 - 15/32 (139) 11 - 3/8 (289)

Net Weight lb (kg) 18 (8) 75 (34)

Compressor Type — Involute scroll

Motor Type —Brushless (4-poles)

Rated Output W — 1100

Air Circulation Type Cross-flow Fan Propeller Fan

Material AS + Glass Fiber 30% P.P

Motor Type Transistor (8-poles) Transistor (8-poles)

Input W — 65.9

Rate Output W 30 40

Fan Speed Lo (Cool/Heat) rpm 880 / 1,100 —

Me (Cool/Heat) rpm 1,100 / 1,230 —

Hi (Cool/Heat) rpm 1,310 / 1,410 790

Heat Exchanger Description Evaporator Condenser

Tube material Copper Copper

Fin material Aluminium (Pre Coat) Aluminium (Pre Coat)

Fin Type Slit Fin Corrugated Fin

Row / Stage (Plate fin configuration, forced draft)

2 rows / 11 stages,

1 row / 4 stages

2 rows / 24 stages

FPI 21 16.5

Size (W × H × L) mm 640 × 304 × 25.4 + 12.7 725.8

694.6

× 504 × 36.4

Refrigerant Control Device — Expansion valve

Refrigeration Oil (c.c) — RB68A (400)

Refrigerant (R410A) g (oz) — 1,030 (36.3)

Thermostat Electronic Control Electronic Control

Protection Device Electronic Control Electronic Control

Length mm — —

Capillary Tube Flow Rate l/min — —

Inner Diameter mm — —

Air Filter Material

Style

P.P.

Honeycomb

—

•

• •

• Specifications are subject to change without notice for further improvement.

CS-TE9DKE CU-TE9DKE / CS-TE12DKE CU-TE12DKE

4 Dimensions

4.1. Indoor Unit

CS-TE9DKE CU-TE9DKE / CS-TE12DKE CU-TE12DKE
