Operating Instructions

Air Conditioner

Model No.

Indoor Unit Outdoor Unit

CS-S9KKQ CU-S9KKQ

CS-S12KKQ CU-S12KKQ

CS-S18KKQ CU-S18KKQ

CS-S24KKQ CU-S24KKQ

CS-S28KKQ CU-S28KKQ

QUICK GUIDE

GUÍA RÁPIDA

F567176

ENGLISH 2 ~ 7

Before operating the unit, read these operating

instructions thoroughly and keep them for future

reference.

ESPAÑOL 8 ~ 13

Antes de utilizar la unidad, sírvase leer

atentamente estas instrucciones de

funcionamiento y conservarlas como futuro

elemento de consulta.

SAFETY PRECAUTIONS

To prevent personal injury, injury to others, or property damage, please

comply with the following.

Incorrect operation due to failure to follow instructions below may cause

harm or damage, the seriousness of which is classiﬁed as below:

WARNING

This sign warns of death or serious injury.

CAUTION

This sign warns of injury or damage to

property.

The instructions to be followed are classiﬁed by the following symbols:

This symbol denotes an action that is

PROHIBITED.

These symbols denote an actions that

is COMPULSORY.

WARNING

INDOOR UNITAND OUTDOOR UNIT

This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not

play with the appliance.

Please consult authorized dealer or specialist to repair,

install, remove and reinstall the unit. Improper installation

and handling will cause leakage, electric shock or ﬁre.

Do not install the unit in a potentially explosive or ﬂammable

atmosphere. Failure to do so could result in ﬁre.

Do not insert your ﬁngers or other objects into the

air conditioner indoor or outdoor unit, rotating parts

may cause injury.

Do not touch the outdoor unit during lightning, it may cause

electric shock.

REMOTE CONTROL

Do not allow infants and small children to play with the

remote control to prevent them from accidentally swallowing

the batteries.

Thank you for purchasing

Panasonic Air Conditioner

TABLE OF CONTENTS

SAFETY PRECAUTIONS2~3

REMOTE CONTROL 4~5

INDOOR UNIT 6

TROUBLESHOOTING 7

INFORMATION 14~15

QUICK GUIDE

BACK COVER

NOTE

The illustrations in this manual are for

explanation purposes only and may

differ from the actual unit. It is subjected

to change without notice for future

improvement.

OPERATION CONDITION

Use this air conditioner under the following

temperature range

Temperature (°C) Indoor

*DBT *WBT

COOLING Max. 32 23

Min. 16 11

Temperature (°C) Outdoor

*DBT *WBT

COOLING Max. 43 26

Min. 16 11

* DBT: Dry bulb temperature

* WBT: Wet bulb temperature

ENGLISH

CAUTION

INDOOR UNITAND OUTDOOR UNIT

Do not wash the indoor unit with water, benzene,

thinner or scouring powder.

Do not use for other purpose such as

preservation of food.

Do not use any combustible equipment in front of

the airﬂow outlet to avoid propagation ﬁre.

Do not expose yourself directly to cold air for a

long period.

Do not sit or step on the unit, you may

fall down accidentally.

Do not touch the sharp aluminium ﬁn,

sharp parts may cause injury.

Do not switch ON the indoor unit when waxing

the ﬂoor. After waxing, aerate the room properly

before operating the unit.

Do not install the unit in oily and smoky areas.

Ensure drainage pipe is connected properly.

Otherwise, leakage may occur.

Aerate the room regularly.

After long period of use, make sure the

installation rack is not deteriorate to prevent the

unit from falling down.

REMOTE CONTROL

Do not use rechargeable (Ni-Cd) batteries.

It may damage the remote control.

Remove the batteries if the unit is not going to be

used for a long period of time.

New batteries of the same type must be inserted

following the polarity stated to prevent

malfunction of the remote control.

WARNING

POWER SUPPLY

Do not use modiﬁed cord,

joint cord, extension cord or

unspeciﬁed cord to prevent

overheating and ﬁre.

Do not share the same power outlet with other

equipment to prevent overheating and ﬁre.

Do not operate with wet hands to prevent electric

shock.

If the supply cord is damage, it must be replaced

by the manufacturer, its service agent or similarly

qualiﬁed persons in order to avoid a hazard.

It is strongly recommended to be installed

with Earth Leakage Circuit Breaker (ELCB)

or Residual Current Device (RCD) to prevent

electric shock or ﬁre.

This equipment must be earthed to prevent

electrical shock or ﬁre.

In case of emergency or abnormal conditions

(burnt smell, etc), turn off the power supply, and

please consult authorized dealer.

Prevent electric shock by switching off the power

supply when:

- Before cleaning or servicing.

- Extended non-use.

- Abnormally strong lightning activity.

Air Inlet

Air Outlet

Air Inlet

Indoor

Unit

Power

Supply

Remote

Control

Outdoor

Unit

REMOTE CONTROL

5TOADJUST VERTICALAIRFLOW DIRECTION

(5 OPTIONS)

AIR SWING

• Keeps the room ventilated.

• In COOL/DRY mode, if AUTO is set, the louver swing

up/down automatically.

6TOADJUST AIRFLOW DIRECTION (5 OPTIONS)

(PAGE 5)

AIR SWING

• Keeps the room ventilated.

• In COOL/DRY mode, if AUTO is set, the louver swing

left/right and up/down automatically.

7TO MONITOR HUMAN PRESENCE

& ACTIVITY FOR ENERGY SAVING

ECO

PATROL

ECO 1 ECO 2 ECO OFF

+3°C

Heat Source & Movement Low High

+2°C

Set Temperature

None

-1°C

Set Fan Speed

≤Medium

Fan

+1 tap

• — ECO 1 - To optimize comfort and energy saving.

• --- ECO 2 - To maximize energy saving.

MILD

DRY

FAN

SPEED

AIR

SWING

QUIET

POWERFUL

FAN SPEED

AIR SWING

ECO

PATROL PATROL/

MILD DRY

COOLING

MODE

TEMP

OFF/ON

TIMER

SET

CANCEL

OFF

123

SET CHECK CLOCK RESET

AC RC

AUTO

COOL

DRY

Press the remote control’s button

1TO TURN ON OR OFF THE UNIT

• Please be aware of the OFF indication on the remote

control display to prevent the unit from starting/stopping

improperly.

2TO SET TEMPERATURE

• Selection range: 16˚C ~ 30˚C.

• Operating the unit within the recommended temperature

could induce energy saving.

COOL mode : 26˚C ~ 28˚C.

DRY mode : 1˚C ~ 2˚C lower than room temperature.

3TO SELECT OPERATION MODE

AUTO mode - For your convenience

• During operation mode selection the power indicator

blinks.

• Unit selects operation mode during startup according to

temperature setting and room temperature.

COOL mode - To enjoy cool air

• Use curtains to screen off sunlight and outdoor heat to

reduce power consumption during cool mode.

DRY mode - To dehumidify the environment

• Unit operates at low fan speed to give a gentle cooling

operation.

4TO SELECT FAN SPEED (5 OPTIONS)

FAN

PEED

• For AUTO, the indoor fan speed is automatically adjusted

according to the operation mode.

Maximum

distances: 8m

INDICATOR

PATROL SENSOR (Red/Orange/Blue)

POWER

(Green)

TIMER

(Orange)

QUIET

(Orange)

POWERFUL

(Orange)

(Blue)

ECO PATROL

(Green)

S9KKQ, S12KKQ

Remote

Control display

ENGLISH

NOTES

PATR

UIET

WERFUL

ECO

PATROL

• Can be activated in all modes and can be cancelled

by pressing the respective button again.

UIET

WERFUL

ECO

PATROL

• Cannot be selected at the same time.

• Cannot be activated during “MIILD DRY COOLING”

operation is activated.

TO SET THE TIMER

• 2 sets of ON and OFF timers are available to turn ON

or OFF the unit at different preset time.

• Complete below procedures to set each timer:

OFF

Cancel

Cancel 2

Select ON or OFF timer Set the

time Conﬁrm

• Example of application at living room:

Morning: ON at 07:00 (Wake up)

OFF at 08:00 (Out for work)

Evening: ON at 17:00 (Back home)

OFF at 22:00 (Sleep)

• To cancel ON or OFF timer, press

Nor OFF to

select respective or then press CANCEL.

• If timer is cancelled manually or due to power failure,

you can restore the timer again by pressing

Nor

OFF to select respective or then press SET .

• Upcoming timer will be displayed and will be activated

in sequence.

• When ON Timer is set, the unit may start earlier (up

to 15 minutes) before the actual set time in order to

achieve the desired temperature on time.

• Timer operation is based on the clock set in the

remote control and repeats daily once set. For clock

setting, please refer to Remote Control Preparation at

back cover.

FAN SPEED

ECO

PATROL PATROL/

MILD DRY

COOLING

MODE

QUIET

TEMP

OFF/ON

AIR SWING

POWERFUL

TIMER

SET

CANCEL

OFF

123

SET CHECK CLOCKRESE

AC RC

8TO ENJOY CLEAN & FRESH AIR

PATROL/ PATROL

NORMAL

PATROL - To monitor air quality

• Detects air quality; e-ion operation

activates when air quality is at dirty

level.

• Regardless of air quality, to

maintain air freshness e-ion

activates automatically (PATROL

SENSOR indicator turns red) when:

- 2 minutes after the unit is on, or

- exceeds 4 hours at clean level.

Indicator Air Quality

Blue Clean

Orange Moderate

Red Dirty

• Can be activated even when the unit is turned off.

• Patrol starts automatically with the unit switched on with

OFF/ON

- To freshen and purify the air

• Generates negative ions to produce fresh air effect and

attract dust which will then be captured at the positively

charged e-ion ﬁlters.

• Can be activated even when the unit is turned off. In this

condition, fan speed and air swing can not be adjusted.

9TO IMPROVE HUMIDITYAND MOISTURE LEVEL

• This operation reduces air dryness and provides you with

a comfortable living environment during COOL mode only.

• When vertical airﬂow direction is set to AUTO, it stops at

lower position to avoid cold air contact. However, you can

adjust the louver direction manually.

10 TO ENJOY QUIET OPERATION

• This operation reduces airﬂow noise.

11 TO REACH TEMPERATURE

QUICKLY

• This operation will stop automatically after 4 hours.

12 Press and hold for 5 seconds to dim or restore the

unit’s indicator brightness.

13 Press and hold for approximately 10 seconds to

show temperature setting in °C or °F.

14 Press to restore the remote control’s default setting.

15 Not used in normal operations.

S18KKQ, S24KKQ, S28KKQ

1INDOOR UNIT

• Wipe the unit gently with a soft, dry cloth.

2FRONT PANEL

Remove Front Panel

• Raise and pull to remove the front panel.

• Wash gently and dry.

Close Front Panel

• Press down both ends of the front panel to close it

securely.

3REMOTE CONTROL RECEIVER

4ALUMINIUM FIN

5ECO PATROL SENSOR

6HORIZONTALAIRFLOW DIRECTION LOUVER

S9KKQ, S12KKQ

• Manually adjustable.

S18KKQ, S24KKQ, S28KKQ

• Do not adjust by hand.

7VERTICALAIRFLOW DIRECTION LOUVER

• Do not adjust by hand.

8AUTO OFF/ON BUTTON

• Use when remote control is misplaced or a malfunction

occurs.

Action Mode

Press once. Auto

Press and hold until 1 beep is

heard, then release. Cooling

Press the button to turn off.

9e-ion CHARGING WIRE

10 e-ion FILTERS

• Clean the ﬁlters regularly.

• Wash/rinse the ﬁlters gently with water to avoid damage

to the ﬁlter surface.

• Dry the ﬁlters thoroughly under the shade, away from

ﬁre or direct sunlight.

• Replace any damaged ﬁlters.

11 ACTIVE e-ion GENERATOR

Clean with dry cotton bud.

• Active e-ion generator cleaning is

recommended every 6 months.

CAUTION

•Switch off the power supply before cleaning.

•Do not touch the aluminium ﬁn, sharp parts may cause injury.

INDOOR UNIT

5ECO PATROL SENSOR

• Do not hit or violently press the

sensor or poke it with a sharp

object. This can lead to damage

and malfunction.

• Do not place large objects near

the sensor and keep heating units

or humidiﬁers off the sensor’s

detection area. This may lead to

sensor malfunction.

9, 10 , 11 e-ionAIR PURIFYING

SYSTEM

• Do not touch during operation

CLEANING INSTRUCTIONS

HINT

• Do not use benzene, thinner or scouring powder.

• Use only soap ( pH7) or neutral household detergent.

• Do not use water hotter than 40°C.

• To ensure optimal performance of the unit, cleaning

maintenance has to be carried out at regular intervals.

Dirty unit may cause malfunction and you may see error

code “H99”. Please consult authorized dealer.

ENGLISH

TROUBLESHOOTING

The following symptoms do not indicate malfunction.

SYMPTOM

CAUSE

Mist emerges from indoor unit. ►• Condensation effect due to cooling process.

Water ﬂowing sound during operation. ►• Refrigerant ﬂow inside the unit.

The room has a peculiar odour. ►• This may be due to damp smell emitted by the wall,

carpet, furniture or clothing.

Indoor fan stops occasionally during automatic fan speed

setting.

►• This helps to remove the surrounding odours.

Operation is delayed a few minutes after restart. ►• The delay is a protection to the unit’s compressor.

Outdoor unit emits water/steam. ►• Condensation or evaporation occurs on pipes.

Timer indicator is always on. ►• The timer setting repeats daily once set.

Power indicator blinks before the unit is switched on. ►• This is a preliminary step in preparation for the operation

when the ON timer has been set.

Cracking sound during operation. ►• Changes of temperature cause the expansion/contraction

of the unit.

Inconsistent airﬂow during PATROL operation. ►• Fan speed is adjusted automatically during patrol

operation.

Select QUIET operation to maintain the airﬂow

consistency.

Check the following before calling for servicing.

SYMPTOM

CHECK

Cooling operation is not working efﬁciently. ►• Set the temperature correctly.

• Close all doors and windows.

• Clean or replace the ﬁlters.

• Clear any obstruction at the air inlet and air outlet vents.

Noisy during operation. ►• Check if the unit has been installed at an incline.

• Close the front panel properly.

Remote control does not work.

(Display is dim or transmission signal is weak.)

►• Insert the batteries correctly.

• Replace weak batteries.

The unit does not work. ►• Check if the circuit breaker is tripped.

• Check if timers have been set.

The unit does not receive the signal from the remote

control.

►• Make sure the receiver not obstructed.

• Certain ﬂuorescent lights may interfere with signal

transmitter. Please consult authorized dealer.

Patrol sensor or e-ion indicator on the indoor unit is

blinking.

►• Stop Patrol or e-ion operation then restart. If the patrol

sensor or e-ion indicator still blinking, please consult

authorized dealer.

Notes on “ECO PATROL SENSOR”

• Sensor may not detect moving objects further than 7m away or beyond detection angle.

• Sensor sensitivity is inﬂuenced by indoor unit location, movement speed, temperature range, etc.

• The sensor may mistakenly detects pets, sunlight, certain lighting, ﬂuttering curtains and light reﬂection as human being.

The unit stops and the timer indicator blinks.

Use remote control to retrieve error code.

TIMER

SET

CANCEL

OFF

123

SET CHECK CLOCK RESET

AC RC

1Press for 5

seconds.

3Press for 5

seconds to

quit checking.

2Press until you hear

beep sound, then

write down the error

code.

Note:

• For certain errors, you

may restart the unit for

limited operation with 4

beeps during operation

starts.

4Turn the unit off and reveal the error code to authorized dealer.

PRECAUCIONES DE SEGURIDAD

Muchas gracias por elegir una

unidad de aire acondicionado

Panasonic

CONTENIDO

PRECAUCIONES DE

SEGURIDAD 8~9

MANDO A DISTANCIA10~11

UNIDAD INTERIOR 12

LOCALIZACIÓN DE

AVERÍAS 13

INFORMACIÓN 14~15

GUÍA RÁPIDA

CUBIERTA TRASERA

NOTA

Las ilustraciones de este manual

sirven únicamente para describir las

explicaciones y pueden no coincidir

exactamente con las del aparato

suministrado. Están sujetas a cambios

sin previo aviso con el ﬁn de mejorar el

producto.

CONDICIONES DE

FUNCIONAMIENTO

Utilice este aparato de aire acondicionado

dentro del siguiente intervalo de

temperaturas

Temperatura (°C) Interior

*DBT *WBT

ENFRIAMIENTO

Máx. 32 23

Mín. 16 11

Temperatura (°C) Exterior

*DBT *WBT

ENFRIAMIENTO

Máx. 43 26

Mín. 16 11

* DBT: Temperatura de bulbo seco

* WBT: Temperatura de bulbo húmedo

Para evitar lesiones personales, lesiones a terceros, o daños materiales,

cumpla lo siguiente.

El uso incorrecto por no seguir las instrucciones puede causar daños o

averías; su gravedad se clasiﬁca con las indicaciones siguientes:

ADVERTENCIA

Esta indicación advierte del posible peligro

de muerte o de daños graves.

PRECAUCIÓN

Esta indicación advierte de los posibles

daños o desperfectos materiales.

Las instrucciones que deben seguirse están clasiﬁcadas mediante los

siguientes símbolos:

Este símbolo denota una acción

que está PROHIBIDA.

Estos símbolos denotan acciones

que son OBLIGATORIAS.

ADVERTENCIA

UNIDAD INTERIOR Y UNIDAD EXTERIOR

Este aparato no debe ser utilizado por personas (incluyendo

niños) con discapacidades mentales, sensoriales o físicas,

o falta de experiencia y conocimiento, a menos que hayan

recibido formación o supervisión en relación al uso del

aparato por una persona responsable por su seguridad. Los

niños deberían estar supervisados para asegurar que no

juegan con el aparato.

Consulte a un distribuidor autorizado o especialista para

reparar, instalar, retirar y reinstalar la unidad. Una instalación

y uso incorrectos provocarán fugas, descargas eléctricas o

incendios.

No instale la unidad en ambientes potencialmente

explosivos o inﬂamables. En caso contrario, podría

provocar accidentes de incendios.

No introduzca los dedos u otros objetos en la

unidad exterior o interior del aire acondicionado,

ya que las partes rotatorias podrían provocarle

lesiones.

No toque la unidad exterior durante un relámpago, ya que

podría causar una descarga eléctrica.

MANDOA DISTANCIA

No permita que bebés y niños pequeños jueguen con el

mando a distancia para evitar que ingieran accidentalmente

las pilas.

ESPAÑOL

PRECAUCIÓN

UNIDAD INTERIOR YUNIDAD EXTERIOR

UNIDAD INTERIOR Y UNIDAD EXTERIOR

No limpie la unidad interior con agua, benceno,

disolvente o limpiador en polvo.

No utilice la unidad para otros ﬁnes, como la

conservación de alimentos.

No utilice ningún equipo combustible delante de

la salida de aire pare evitar que se propague un

incendio.

No se exponga directamente al aire frío durante un

periodo prolongado de tiempo.

No se siente o pare sobre la unidad, se

podría caer accidentalmente.

No toque la ﬁlosa aleta de aluminio, las

piezas ﬁlosas pueden causar lesiones.

No encienda la unidad cuando encere el suelo.

Después de encerar, airee la habitación correctamente

antes de usar la unidad.

No instale la unidad en áreas aceitosas y ahumadas.

Asegúrese de que el tubo de drenaje esté conectado

correctamente. Si no es así, se podrían producir

fugas.

Ventile la habitación con regularidad.

Después de un largo periodo de uso, asegúrese

de que la ranura de instalación no se encuentre

deteriorada, para evitar que la unidad se caiga.

MANDOA DISTANCIA

No utilice pilas recargables (Ni-Cd).

Podría dañar el control remoto.

Extraiga las pilas si no va a utilizar la unidad durante

un periodo prolongado de tiempo.

Para que el mando a distancia funcione bien, es

necesario insertar las pilas según la polaridad

indicada.

Entrada

de aire

Salida

de aire

Salida

de aire

Entrada

de aire

Entrada

de aire

Unidad

Interior

Fuente

energía

Mando a

Distancia

Unidad

Exterior

ADVERTENCIA

FUENTE DE ENERGÍA

No utilice un cable modiﬁcado,

unido con otro, un cable

de extensión o un cable

no especiﬁcado para evitar

sobrecalentamiento e incendios.

No comparta la misma salida eléctrica con otros

equipos para evitar el calentamiento e incendios.

No lo use con las manos mojadas para evitar

descargas eléctricas.

Para evitar riesgos, si el cable de alimentación

está dañado y es necesario cambiarlo, deberá hacerlo

el fabricante, un representante del servicio técnico o

una persona caliﬁcada.

Se recomienda altamente instalarlo con un disyuntor

de fuga a tierra (ELCB) o un dispositivo residual actual

(RCD) para evitar descargas eléctricas o incendios.

Este equipo deberá conectarse a tierra para evitar

descargas eléctricas o incendios.

En caso de emergencia o condiciones anormales (olor

a quemado, etc.), corte la alimentación de energía y

consulte al distribuidor autorizado.

Evite descargas eléctricas desconectando la

alimentación eléctrica cuando:

- Antes de limpiarlo o repararlo.

- Largo periodo en desuso.

- Tormentas eléctricas especialmente violentas.

MANDO A DISTANCIA

PARAAJUSTAR LA DIRECCIÓN VERTICAL DE LA

CORRIENTE DEAIRE (5 OPCIONES)

AIR SWING

• Mantiene la habitación ventilada.

• En el modo FRÍO/SECAR, si AUTOMÁTICO está

conﬁgurado, la rejilla gira hacia arriba/abajo automáticamente.

6PARAREGULAR LA DIRECCIÓN DE LA

CORRIENTE DEAIRE (5 OPCIONES)

(PÁGINA 11)

AIR SWING

• Mantiene la habitación ventilada.

• En el modo FRÍO/SECAR, si AUTOMÁTICO está conﬁgurado,

la rejilla gira hacia la izquierda/derecha y arriba/abajo

automáticamente.

PARACONTROLAR LA PRESENCIA

HUMANAY LAACTIVIDAD PARA EL

AHORRO DE ENERGÍA

ECO

PATROL

ECO 1 ECO 2 ECO OFF

+3°C

Fuente de calor y movimiento

Baja Alta

+2°C

Temperatura configurada

Ninguna

-1°C

Definir la velocidad del ventilador

≤Ventilador

medio

+1 punto

• — ECO 1 - Para optimizar la comodidad y ahorro de energía.

• --- ECO 2 - Para el máximo ahorro de energía.

MILD

DRY

FAN

SPEED

AIR

SWING

QUIET

POWERFUL

FAN SPEED

AIR SWING

ECO

PATROL PATROL/

MILD DRY

COOLING

MODE

TEMP

OFF/ON

TIMER

SET

CANCEL

OFF

123

SET CHECK CLOCK RESET

AC RC

AUTO

COOL

DRY

Distancia

máxima: 8m

INDICADOR

PATROL SENSOR

(Rojo/Naranja/Azul)

POWER

(Verde)

TIMER

(Naranja)

QUIET

(Naranja)

POWERFUL

(Naranja)

(Azul)

ECO PATROL

(Verde)

S9KKQ, S12KKQ

Pantalla del

mando a

distancia

Pulse el botón del control remoto

ENCENDER OAPAGAR LA UNIDAD

• Por favor esté al tanto de la indicación OFF en la pantalla del

mando a distancia para impedir que la unidad arranqueo se

detenga incorrectamente.

PARAAJUSTAR LATEMPERATURA

• Gama de selección: 16°C ~ 30°C.

• El funcionamiento de la unidad dentro de la temperatura

recomendada podría resultar en el ahorro de energía.

MODO FRÍO : 26°C ~ 28°C.

MODO DESHUMIDIFICACIÓN : 1°C ~ 2°C menos que la

temperatura ambiente.

SELECCIONAR MODO DE OPERACIÓN

MODOAUTOMÁTICO - Para su conveniencia

• Durante la selección del modo de funcionamiento el indicador de

encendido parpadea.

• La unidad selecciona el modo de operación durante el inicio de

acuerdo a la conﬁguración de la temperatura y a la temperatura

de la habitación.

MODO FRÍO - Para disfrutar de aire frío

• Use cortinas para proteger de luz solar y el calor exterior y así

reducir el consumo eléctrico durante el modo de frío.

MODO DESHUMIDIFICACIÓN - Para deshumidiﬁcar

el ambiente

• La unidad funciona en la velocidad de ventilador baja para

proporcionar una agradable refrigeración.

PARASELECCIONAR LA VELOCIDAD DEL

VENTILADOR (5 OPCIONES)

FAN

PEED

• Para AUTO (automático), la velocidad de ventilador de interior

es ajustada automáticamente según el modo de operación.

Other manuals for CS-S9KKQ

This manual suits for next models

Table of contents

Languages:

Other Panasonic Air Conditioner manuals

Panasonic

Panasonic CS-RE18PKR User manual

Panasonic

Panasonic CS-E24FKR User manual

Panasonic

Panasonic CS-A7DKD User manual

Panasonic

Panasonic S-24MF2U6 User manual

Panasonic

Panasonic PAPAMY1604017CE User manual

Panasonic

Panasonic CU-KS30NKUA User manual

Panasonic

Panasonic U-8MF3E8 User manual

Panasonic

Panasonic CS-W18DKR User manual

Panasonic

Panasonic S-15MY2E5A CZ-KPY3A Instruction manual

Panasonic

Panasonic CS-G95KE CU-G95KE User manual

Panasonic

Panasonic S-07MM2U6 User manual

Panasonic

Panasonic CU-C18CKV User manual

Panasonic

Panasonic CS-NU12VKYW Series User manual

Panasonic

Panasonic U-4LA1E5 User manual

Panasonic

Panasonic CS-RE9PKE User manual

Panasonic

Panasonic CS-A120TE User manual

Panasonic

Panasonic CS-RE18UKA User manual

Panasonic

Panasonic CU-CZ12SKE User manual

Panasonic

Panasonic CS-RE9UKA User manual

Panasonic

Panasonic CS-VE9NKE User manual

Panasonic

Panasonic CS-UC12QKD User manual

Panasonic

Panasonic CS-XE12SKUA-1 User manual

Panasonic

Panasonic CS-PS12UKV-6 User manual

Panasonic

Panasonic CS-LE9WKA User manual

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

nedis

nedis ACMB1WT7 quick start guide

Samsung

Samsung AR KV Series User & installation manual

Daikin

Daikin FCFV50A Operation manual

Fujitsu

Fujitsu Inverter ASBA30JFC operating manual

Toshiba

Toshiba RAS-M10SMUV-E installation manual

Daikin

Daikin FXLQ20MAVE Operation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Frigidaire

Frigidaire FFRE0533S1E0 Use & care guide

Samsung

Samsung AS09HM3N user manual

Frigidaire

Frigidaire CRA073PU11 use & care

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual

Webasto

Webasto Frigo Top 25 DS Instructions for use
