Operation conditions

Use this air conditioner under the following temperature range.

DBT : Dry bulb temperature

WBT : Wet bulb temperature

CU-E9PD3EA, CU-E12PD3EA, CU-E12QD3EA Indoor Outdoor

DBT WBT DBT WBT

COOL Max. 32 (89.6) 23 (73.4) 43 (109.4) 26 (78.8)

Min. 16 (60.8) 11 (51.8) -10 (14.0) -

HEAT Max. 30 (86.0) - 24 (75.2) 18 (64.4)

Min. 16 (60.8) - -10 (14.0) -

°C (°F) (temperature)

Multi split outdoor unit

CU-2E15PBE, CU-2E18PBE, CU-3E18PBE, CU-4E23PBE,

CU-4E27PBE, CU-5E34PBE, CU-2E12SBE, CU-2E15SBE,

CU-2E18SBE, CU-3E23SBE, CU-2Z35TBE, CU-2Z41TBE,

CU-2Z50TBE, CU-3Z52TBE, CU-3Z68TBE, CU-4Z68TBE,

CU-4Z80TBE, CU-5Z90TBE

Indoor Outdoor

DBT WBT DBT WBT

COOL Max. 32 (89.6) 23 (73.4) 46 (114.8) 26 (78.8)

Min. 16 (60.8) 11 (51.8) -10 (14.0) -

HEAT Max. 30 (86.0) - 24 (75.2) 18 (64.4)

Min. 16 (60.8) - -15 (5.0) -16 (3.2)

°C (°F) (temperature)

Thank you for purchasing Panasonic Air Conditioner.

Installation instructions attached.

Before operating the unit, read these operating instructions thoroughly and keep them for future

reference.

The illustrations in this manual are for explanation purposes only and may differ from the actual unit.

They are subject to change without notice for future improvement.

Multi air conditioner system

Multi air conditioner systems save space by

letting you connect multiple indoor units to a

single outdoor unit.

• For complete product features, please refer

catalogue.

Indoor units

Outdoor unit

Indoor units

• It is possible to operate the indoor units

individually or simultaneously. The priority

of operation is placed on the ﬁrst unit that

turned on.

• During operation, HEAT and COOL modes

cannot activate at the same time for different

indoor units.

• The power indicator blinks to indicate the

indoor unit is standing by for a different

operation mode.

English

Quick guide

Remote control preparation

OFF /ON

TIMER/CLOCK

MODE

OFF/ON

CANCELCLOCK

SET

SELECTUP

DOWN

31 2

Open the cover to use the buttons

1Press

CLOCK

Press

TIMER

DOWN

select current day

3Press

SET

to conﬁrm

4Repeat steps 2 and 3 to set

the current time

Basic operation

OFF /ON

TEMP

TIMER/CLOCK

MODE

QUIET/

POWERFUL

FAN SPEED

MODE

CHECK RESET

AIR SWING

OFF/ON

CANCELCLOCK

SET

SELECTUP

DOWN

AC RC

Start/stop the operation

• Please note that the OFF indication is

as follows:

To start:

To stop:

2Select the desired mode

DRY

AUTO HEAT

COOL

3Select the desired temperature

• Selection range: 16 °C ~ 30 °C / 60 °F ~ 86 °F.

Table of contents

Safety precautions...................4-7

How to use...............................8-9

Information...............................8-9

To set the timer......................9-10

Troubleshooting........................ 11

Safety precautions

To prevent personal injury, injury to

others or property damage, please

comply with the following:

Incorrect operation due to failure to

follow instructions below may cause

harm or damage, the seriousness of

which is classiﬁed as below:

This appliance is not intended for

accessibility by the general public.

For appliance ﬁlled with R32

(mild ﬂammable refrigerant).

If the refrigerant is leaked and

exposed to an external ignition

source, there is a risk of ﬁre.

WARNING

This sign

warns of

death or

serious

injury.

CAUTION

This sign

warns of

injury or

damage to

property.

The instructions to be followed are

classiﬁed by the following symbols:

This symbol denotes an

action that is PROHIBITED.

These symbols denote

actions COMPULSORY.

WARNING

Indoor unit and outdoor unit

This appliance can be used by

children aged from 8 years and

above and persons with reduced

physical, sensory or mental

capabilities or lack of experience

and knowledge if they have been

given supervision or instruction

concerning use of the appliance

in a safe way and understand the

hazards involved.

Children shall not play with the

appliance. Cleaning and user

maintenance shall not be made

by children without supervision.

Please consult authorised dealer

or specialist to clean the internal

parts, repair, install, remove

and reinstall the unit. Improper

installation and handling will

cause leakage, electric shock or

ﬁre.

Conﬁrm with authorised dealer

or specialist on usage of any

speciﬁed refrigerant type.

Using refrigerant type other than

the speciﬁed may cause product

damage, burst and injury etc.

Air inlet

Air outlet

Remote control

Outdoor unit

Power supply

Indoor unit

Air inlet vent

Air outlet

vent

EnglishSafety precautions

Do not install the unit in

a potentially explosive or

ﬂammable atmosphere.

Failure to do so could result in

ﬁre.

Do not insert your ﬁngers

or other objects into the

air conditioner indoor or

outdoor unit, rotating parts

may cause injury.

Do not touch the outdoor unit

during lightning, it may cause

electric shock.

Do not expose yourself directly

to cold air for a long period to

avoid excess cooling.

Do not sit or step on the

unit, you may fall down

accidentally.

Remote control

Do not allow infants and small

children to play with the remote

control to prevent them from

accidentally swallowing the

batteries.

Power supply

Do not use a

modiﬁed cord, joint

cord, extension cord

or unspeciﬁed cord to

prevent overheating

and ﬁre.

To prevent overheating, ﬁre or

electric shock:

•Do not share the same power

outlet with other equipment.

•Do not operate with wet hands.

•Do not over bend the power

supply cord.

•Do not operate or stop the unit

by inserting or pulling out the

power plug.

If the supply cord is damaged,

it must be replaced by the

manufacturer, service agent or

similarly qualiﬁed persons in

order to avoid a hazard.

It is strongly recommended to

be installed with Earth Leakage

Circuit Breaker (ELCB) or

Residual Current Device (RCD)

to prevent electric shock or ﬁre.

To prevent overheating, ﬁre or

electric shock:

•Insert the power plug properly.

•Dust on the power plug should

be periodically wiped with a dry

cloth.

Stop using the product if any

abnormality/failure occurs and

disconnect the power plug or turn

off the power switch and breaker.

(Risk of smoke/ﬁre/electric

shock)

Examples of abnormality/failure

•

The ELCB trips frequently.

•

Burning smell is observed.

•

Abnormal noise or vibration of

the unit is observed.

•

Water leaks from the indoor unit.

•

Power cord or plug becomes

abnormally hot.

•

Fan speed cannot be controlled.

•

The unit stops running

immediately even if it is

switched on for operation.

•

The fan does not stop even if

the operation is stopped.

Contact your local dealer

immediately for maintenance/

repair.

This equipment must be earthed

to prevent electrical shock or ﬁre.

Prevent electric shock by

switching off the power supply

and unplug:

-Before cleaning or servicing,

-When extended non-use, or

-During abnormally strong

lightning activity.

Safety precautions

WARNING

Precaution for appliance ﬁlled

with R32

Pay careful attention to the following

points when operating the appliances

and dealing with different refrigerants.

The appliance shall be installed,

and/or operated in a room with

ﬂoor area larger than Amin (m²)

and keep away from ignition

sources, such as heat/sparks/

open ﬂame or hazardous areas

such as gas appliances, gas

cooking, reticulated gas supply

systems or electric cooking

appliances, etc. (Refer to Table

A of Installation instructions table

for Amin (m²))

Be aware that refrigerant may

not contain an odour, highly

recommended to ensure suitable

ﬂammable refrigerant gas

detectors are present, operating

and able to warn of a leak.

Since the working pressure is

higher than that of refrigerant

R22 models, some of the piping

and installation and service tools

are special.

Especially, when replacing a

refrigerant R22 model with a new

refrigerant R32 model, always

replace the conventional piping

and ﬂare nuts with the R32 and

R410A piping and ﬂare nuts on

the outdoor unit side.

The R32 ﬂare nut and pipe on

the outdoor unit side can also be

used for a R410A model.

Models that use refrigerant R32

and R410A have a different

charging port thread diameter to

prevent erroneous charging with

refrigerant R22 and for safety.

Therefore, check beforehand.

[The charging port thread

diameter for R32 and R410A is

12.7 mm (1/2 inch).]

Be extra careful so that foreign

matter (oil, water, etc.) does not

enter the piping.

Also, when storing the piping,

securely seal the opening by

pinching, taping, etc. (Handling

of R32 is similar to R410A.)

This appliance shall be stored in

a well ventilated area.

This appliance shall be stored

in a room without continuously

operating open ﬂames and

ignition sources.

This appliance shall be stored

so as to prevent mechanical

damage from occurring.

Do not use means to accelerate

the defrosting process or

to clean, other than those

recommended by manufacturer.

Any unﬁt method or using

incompatible material may cause

product damage, burst and

serious injury.

Do not pierce or burn as the

appliance is pressurized. Do not

expose the appliance to heat,

ﬂame, sparks, or other sources

of ignition. Else it may explode

and cause injury or death.

English

CAUTION

Indoor unit and outdoor unit

Do not wash the indoor unit

with water, benzine, thinner

or scouring powder to avoid

damage or corrosion at the unit.

Do not use for preservation

of precise equipment, food,

animals, plants, artwork or other

objects. This may cause quality

deterioration, etc.

Do not use any combustible

equipment in front of the airﬂow

outlet to avoid ﬁre propagation.

Do not expose plants or pet

directly to airﬂow to avoid injury,

etc.

Do not touch the sharp

aluminium ﬁn, sharp parts

may cause injury.

Do not switch ON the indoor

unit when waxing the ﬂoor. After

waxing, aerate the room properly

before operating the unit.

Do not install the unit in oily and

smoky areas to prevent damage

to the unit.

Do not dismantle the unit for

cleaning purpose to avoid injury.

Do not step onto an unstable

bench when cleaning the unit to

avoid injury.

Do not place a vase or water

container on the unit. Water may

enter the unit and degrade the

insulation. This may cause an

electric shock.

Do not open window or door

for long time during operation,

it may lead to inefﬁcient power

usage and uncomfortable

temperature changes.

Prevent water leakage by

ensuring drainage pipe is:

-Connected properly,

-Kept clear of gutters and

containers, or

-Not immersed in water

After a long period of use or use

with any combustible equipment,

aerate the room regularly.

After a long period of use, make

sure the installation rack does

not deteriorate to prevent the unit

from falling down.

Remote control

Do not use rechargeable (Ni-Cd)

batteries. It may damage the

remote control.

To prevent malfunction or

damage of the remote control:

•Remove the batteries if the unit

is not going to be used for a

long period of time.

•New batteries of the same type

must be inserted following the

polarity stated.

Power supply

Do not disconnect the plug

by pulling the cord to prevent

electric shock.

Safety precautions

FAN SPEED

To select fan speed

(Remote control display)

• For AUTO, the indoor fan speed is automatically

adjusted according to the operation mode.

How to use

MODE

To select operation mode

AUTO - For your convenience

• Unit selects operation mode every 10 minutes

according to setting temperature and room

temperature.

HEAT - To enjoy warm air

• Unit takes a while to warm up.

COOL- To enjoy cool air

• Use curtains to screen off sunlight and outdoor

heat to reduce power consumption during COOL

mode.

DRY - To dehumidify the environment

• Unit operates at low fan speed to give a gentle

cooling operation.

QUIET/

POWERFU

To switch between

quiet & powerful

QUIET POWERFUL NORMAL

QUIET: To enjoy quiet operation

• This operation reduces airﬂow noise.

POWERFUL: To reach temperature quickly

Single • This operation stops automatically after

20 minutes.

• To eliminates the POWERFUL indicator

after 20 minutes operation, press

QUIET/

POWERFU

button again.

Multi • Press the button again or turn OFF the

unit to stop this operation.

Can be activated in all modes and can be

cancelled by pressing the respective button again.

OFF /ON

TEMP

TIMER/CLOCK

MODE

QUIET/

POWERFUL

FAN SPEED

MODE

CHECK RESET

AIR SWING

OFF/ON

CANCELCLOCK

SET

SELECTUP

DOWN

AC RC

Remote control display

Press and hold

for approximately

10 seconds to show

temperature setting

in °C or °F.

Press to restore the

remote control to

default setting.

Not used in normal

operations.

Not applicable

Information for Users on Collection and Disposal of Old Equipment

These symbols on the products, packaging, and/or accompanying documents mean that used electrical

and electronic products should not be mixed with general household waste.

For proper treatment, recovery and recycling of old products, please take them to applicable collection

points, in accordance with your national legislation.

By disposing of these products correctly, you will help to save valuable resources and prevent any

potential negative effects on human health and the environment which could otherwise arise from

inappropriate waste handling.

For more information about collection and recycling of old products, please contact your local

municipality, your waste disposal service or the point of sale where you purchased the items.

Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.

For business users in the European Union

If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for

further information.

[Information on Disposal in other Countries outside the European Union]

These symbols are only valid in the European Union. If you wish to discard these items, please contact

your local authorities or dealer and ask for the correct method of disposal.

Information

Single Single split system

Multi Multi split system

NON SERVICEABLE CRITERIAS

TURN OFF POWER SUPPLY then please consult

authorised dealer under the following conditions:

• Abnormal noise during operation.

• Water/foreign particles have entered the remote

control.

• Water leaks from Indoor unit.

• Circuit breaker switches off frequently.

• Power cord becomes unnaturally warm.

• Switches or buttons are not functioning properly.

English

To set the timer

Daily timer setting

To turn ON or OFF the unit at a preset time.

TIMER/CLOCK

CANCELCLOCK

SELECT

/ON

1Press TIMER

MODE

to enter timer mode

• Press once to change the display from

clock to timer or vice-versa.

• Press for 4 seconds to change the display

from daily timer to weekly timer or vice-

versa.

2Select ON or OFF

timer

Example:

OFF at 22:00

OFF/ON

3Set the time

DOWN

4Conﬁrm

SET

• To cancel, press

CANCEL

• When ON timer is set, the unit may start early

before the actual set time in order to achieve

the desired temperature on time.

• Timer operation is based on the clock set in

the remote control and repeats daily once set.

• The timer closest to the current time will be

activated ﬁrst.

• If timer is cancelled manually or due to power

failure, you can restore the previous setting

by pressing

SET

How to use / Information / To set the timer

To ensure optimal performance of the unit,

cleaning has to be carried out at regular

intervals. Please consult authorised dealer.

• Switch off the power supply before cleaning.

• Do not touch the aluminium ﬁn, sharp parts

may cause injury.

• Do not use benzine, thinner or scouring

powder.

• Use only soap ( pH 7) or neutral household

detergent.

• Do not use water hotter than 40 °C / 104 °F.

For seasonal inspection after extended

non-use

• No obstruction at air inlet and air outlet

vents.

• These units are mounted inside the ceiling.

It uses external air intake vent and air

outlet vent to operate. Please consult your

nearest dealer for seasonal inspection.

• After 15 minutes of operation, it is normal to

have the following temperature difference

between air inlet and air outlet vents:

COOL: ≥8 °C / 14.4 °F

HEAT: ≥14 °C / 25.2 °F

For extended non-use

• Activate HEAT mode for 2~3 hours to

remove moisture left in the internal parts

thoroughly to prevent mould growth.

• Turn off the power supply.

To set the timer

Weekly timer setting

Promotes energy saving by allowing you to set

up to 6 programmes in any given day.

TIMER/CLOCK

CANCELCLOCK

SELECT

/ON

Lights up if Timer operation is selected

Programme number in a

day (1 ~ 6)

Time to be selected

(10 minutes step)

ON Timer

OFF Timer

Day to be selected

Indicates the selected day

Indicates the next timer

operation day

1. Press TIMER

MODE

for 4 seconds to change

display to weekly timer.

2. Press TIMER

DOWN

to select your

desired day.

3. Press

SELECT

to conﬁrm your selection.

4. “1” will be blinking, press

SELECT

to set

programme 1.

5. Press TIMER

OFF/ON

to select ON or OFF timer.

6. Press TIMER

DOWN

to select your

desired time.

If you want to set the timer together with

your desired temperature, press

TEMP

select the temperature.

7. Press

SET

to conﬁrm programme 1. The

selected day will be highlighted with .

• After 2 seconds, the display will move to the

next programme. Repeat steps 4 to 7 to set

programmes 2 to 6.

• During timer setup, if no button is pressed within

30 seconds, or if the

SET

button is pressed, the

setting at that moment is conﬁrmed and timer

setup is ended.

To check current timer programme

1.Press TIMER

MODE

to enter timer mode and

press

SELECT

to enter day setting.

2.Press TIMER

DOWN

until your desired day is

shown, press

SELECT

to conﬁrm your selection.

3.Press TIMER

DOWN

to check the set

programmes.

To modify current timer programme or

add new timer programme

1.Press TIMER

MODE

to enter timer mode and

press

SELECT

to enter day setting.

2.Press TIMER

DOWN

until your desired day is

shown.

3.Perform steps 4 to 7 of “Weekly timer setting”

to modify existing timer programme, or add any

timer programme.

To cancel current timer programme

1.Press

SELECT

to enter day.

2.Press TIMER

DOWN

until your desired day is

shown, press

SELECT

to enter programme setting.

3.Press TIMER

DOWN

until your desired day

is shown. Press

CANCE

to cancel the programme

and will disappear.

To disable/enable Weekly Timer

• To disable weekly timer setting, press TIMER

MODE

, then press

CANCEL

• To enable previous weekly timer setting, press

TIMER

MODE

, then press

SET

Note

• Daily timer and weekly timer could not be set

at the same time.

• Same timer programme cannot be set in the

same day.

This manual suits for next models

Table of contents

Languages:

Other Panasonic Air Conditioner manuals

Panasonic

Panasonic CW-A120FR User manual

Panasonic

Panasonic CS-E7MKR User manual

Panasonic

Panasonic CS-F14DD3E5 User manual

Panasonic

Panasonic CS-W24EKR User manual

Panasonic

Panasonic CS-RE9UKA User manual

Panasonic

Panasonic CS-MS9SD3H User manual

Panasonic

Panasonic 2005 User manual

Panasonic

Panasonic CW-C51GU User manual

Panasonic

Panasonic CU-4E27CBPG User manual

Panasonic

Panasonic CS-C9GKZW User manual

Panasonic

Panasonic CS-RE18MKR User manual

Panasonic

Panasonic CS-Z25TKEA User manual

Panasonic

Panasonic CS-PV18VKF User manual

Panasonic

Panasonic CS-XE12EKE User manual

Panasonic

Panasonic CS-PU9XKH-8M User manual

Panasonic

Panasonic CU-3E19RBU-5 User manual

Panasonic

Panasonic CS-C12KKF-2 User manual

Panasonic

Panasonic CS-CZ9SKE User manual

Panasonic

Panasonic CSC9CKPG - SPLIT A/C IN DOOR User manual

Panasonic

Panasonic CS-ME18NKE User manual

Panasonic

Panasonic CS-TE12HKE-5 User manual

Panasonic

Panasonic S-22MU1E5A Instruction manual

Panasonic

Panasonic CW-XC145HU User manual

Panasonic

Panasonic CS/CU-EU12AKY Series Product guide

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

nedis

nedis ACMB1WT7 quick start guide

Samsung

Samsung AR KV Series User & installation manual

Daikin

Daikin FCFV50A Operation manual

Fujitsu

Fujitsu Inverter ASBA30JFC operating manual

Toshiba

Toshiba RAS-M10SMUV-E installation manual

Daikin

Daikin FXLQ20MAVE Operation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Frigidaire

Frigidaire FFRE0533S1E0 Use & care guide

Samsung

Samsung AS09HM3N user manual

Frigidaire

Frigidaire CRA073PU11 use & care

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual

Webasto

Webasto Frigo Top 25 DS Instructions for use
