oticon Opn Series User manual
Instructions for use miniRITE
miniRITE T
Oticon Opn™
Oticon Opn S™
Oticon Opn Play™
Oticon Siya
Oticon Ruby
Model overview
This booklet is valid for Oticon Opn™, Oticon Opn S™,
Oticon Opn Play™, Oticon Siya and Oticon Ruby families,
in the following hearing aid models:
miniRITE
miniRITE T
Oticon Opn FW 6
Oticon Opn 1 GTIN: (01) 05707131340795
Oticon Opn 2 GTIN: (01) 05707131340818
Oticon Opn 3 GTIN: (01) 05707131340801
Oticon Opn S FW 8
Oticon Opn S 1 GTIN: (01) 05707131374967
Oticon Opn S 2 GTIN: (01) 05707131374974
Oticon Opn S 3 GTIN: (01) 05707131374981
Oticon Opn Play FW 8
Oticon Opn Play 1 GTIN: (01) 05707131374998
Oticon Opn Play 2 GTIN: (01) 05707131375001
Oticon Siya FW 1
Oticon Siya 1 GTIN: (01) 05707131340887
Oticon Siya 2 GTIN: (01) 05707131340894
Oticon Ruby FW 1
Oticon Ruby 1 GTIN: (01) 05707131378491
Oticon Ruby 2 GTIN: (01) 05707131378507
Introduction to this booklet
This booklet gives you guidance on how to use and maintain your
new hearing aid. Please read the booklet carefully, including the
Warnings section. This will help you to get the most out of your new
hearing aid.
Your hearing care professional has adjusted the hearing aid to meet
your needs. If you have further questions, please contact your
hearing care professional.
About Start-up Handling Options Tinnitus Warnings More info
For your convenience, this booklet contains a navigation bar to help
you easily navigate through the different sections.
Model overview
LED light (Oticon Opn Play) for visual indication
The LED light helps caregivers, parents, and teachers to operate
the hearing aid and to give instructions on relevant functions and
modes (see relevant information throughout the booklet).
The following speakers are available for the above models:
Speaker 60
Speaker 85
Speaker 100 (Power Instrument)
Power flex mould speaker 100 (Power Instrument)
Power flex mould speaker 105 (Power Instrument)
Table of contents
About
Your hearing aid, speaker, and earpiece 10
miniRITE 12
miniRITE T 13
Identify left and right hearing aid 14
MultiTool for handling batteries and cleaning 15
Start-up
Turn hearing aid ON and OFF 16
When to replace the battery 17
How to replace the battery (size 312) 18
Put on the hearing aid 20
Continues on next page
Intended use
Intended use The hearing aid is intended to amplify and transmit
sound to the ear.
Indications for use Impaired hearing within mild to severe-to-profound
hearing loss.
Intended user Adults and children older than 36 months.
User environment Indoor and outdoor.
Contraindications Users of active implants must pay special attention
when using the hearing aid. For more information read
the Warnings section.
Clinical benefits The hearing aid is designed to provide better speech
understanding to help ease communication with the
aim of improving quality of life.
IMPORTANT NOTICE
The hearing aid amplification is uniquely adjusted and optimised
to your personal hearing capabilities during the hearing aid fitting
performed by your hearing care professional.
Handling
Caring for the hearing aid 21
Replace standard earpieces 22
Replace ProWax miniFit filter 25
Clean customised earpieces 26
Replace ProWax filter 27
Flight mode 28
Options
Optional features and accessories 29
Change volume miniRITE 30
Change volume miniRITE T 31
Change program 32
Mute 34
Use hearing aid with iPhone and iPad 35
Wireless accessories 36
Other options 38
Table of contents
Tinnitus
Tinnitus SoundSupport™ (optional) 40
Guidelines for tinnitus sound generator users 41
Sound and volume adjustment 42
Limitation on use time 46
Tinnitus SoundSupport warnings 49
Warnings
General warnings 50
More info
Troubleshooting 56
Water & dust resistant (IP68) 58
Conditions of use 59
Technical information 60
Warranty 67
Your individual hearing aid settings 68
Sound and LED indicators 70
10 11
About Start-up Handling Options Tinnitus Warnings More info
About
Your hearing aid, speaker, and earpiece The speaker uses one of the following earpieces:
Standard earpieces Customised earpieces
LiteTip
VarioTherm® LiteTip
Open dome Micro mould
VarioTherm® micro mould
60 85
Please see details for replacing the dome in
chapter “Replace standard earpieces”.
® VarioTherm is a registered trademark
of Dreve
100 100
105
miniRITE
miniRITE T
Power dome
Grip Tip
Available in small and large, left and
right, with or without vent.
Bass dome, single vent
Bass dome, double vent
* only as open dome for speaker 60
** not for open dome
6 mm5 mm* 8 mm 10 mm 12 mm**
Ear grip
(optional)
Standard
speakers
The hearing aid uses one of the following speakers:
Power flex
mould
speakers
Ear grip
(optional)
Dome sizes
12 13
About Start-up Handling Options Tinnitus Warnings More info
miniRITE
What it is and does
miniRITE T
What it is and does
Push button
Mute, change
volume, and
programs
Microphones
Sound in
Battery drawer
Contains the battery
and functions as an
on/off switch
Battery drawer
Contains the battery
and functions as an
on/off switch
Wax filter
Protects the
speaker from
wax
Wax filter
Protects the
speaker from
wax
Speaker
Sound out Speaker
Sound out
Ear grip
Holds the speaker
in place (optional)
Ear grip
Holds the speaker
in place (optional)
Microphones
Sound in
LED
Program, volume,
battery status
(optional)
Nail grip
Open the
battery drawer
Nail grip
Open the
battery drawer
Push button
Mute, change
volume, and
programs
14 15
About Start-up Handling Options Tinnitus Warnings More info
Identify left and right hearing aid
It is important to distinguish between the left and the right hearing
aid, as they may be programmed differently.
You can find left/right colour indicators in the battery drawer and
on 60 and 85 speakers. Indicators (either L or R) can also be found
on 100 speakers and some earpieces.
A RED indicator marks the
RIGHT hearing aid
A BLUE indicator marks
the LEFT hearing aid
MultiTool for handling batteries and cleaning
The MultiTool contains a magnet that makes it easier to replace the
battery in the hearing aid. It also contains a brush and wire loop for
cleaning and removing earwax. If you need a new MultiTool, please
contact your hearing care professional.
Brush
Wire loopMagnet
IMPORTANT NOTICE
The MultiTool has a built-in magnet. Keep the MultiTool at least 30 cm
away from credit cards and other magnetically sensitive devices.
16 17
About Start-up Handling Options Tinnitus Warnings More info
Turn hearing aid ON and OFF
The battery drawer is used to switch the hearing aid on and off.
To save battery life, make sure your hearing aid is switched off
when you are not wearing it. If you wish to return to the standard
settings of the hearing aid, simply open and close the battery
drawer (quick reset).
When to replace the battery
When it is time to replace the battery, you will hear three tones
repeated in moderate intervals until the battery runs out.
Three alternate tones*
= The battery is running low
Four descending tones
= The battery has run out
Battery tip
To make sure the hearing aid is always working, bring spare
batteries with you, or replace the battery before you leave home.
Optional LED
Continuous red flashes indicate low battery.
Turn ON
Close the
battery
drawer with
the battery
in place.
Turn OFF
Open the
battery drawer.
Start-up
Note: Batteries need to be replaced more often if you are streaming to your hearing aid.
* Bluetooth® will be turned off and it will not be possible to use wireless accessories.
18 19
About Start-up Handling Options Tinnitus Warnings More info
How to replace the battery (size 312)
2. Uncover 3. Insert
Fully open the
battery drawer.
Remove the battery.
Remove the sticky
label from the +side
of the new battery.
Tip:
Wait 2 minutes so that
the battery can draw
air, to ensure optimal
functioning.
Insert the new
battery into the
battery drawer with
the + side facing
upwards.
1. Remove
MultiTool
Close the battery drawer.
The hearing aid will play a
jingle through the earpiece.
Hold the earpiece close to
your ear to hear the jingle.
The MultiTool can be used to
change the battery. Use the
magnetic end to remove and
insert batteries.
The MultiTool is provided by
your hearing care professional.
4. Close Tip
