oticon Dual User manual
INSTRUCTIONS FOR USE
CONNECT/MINI
Thank you
Thank you for choosing our product as your means to better hearing.
To support your efforts, we have put great care and attention into making sure that your
new hearing instruments are of the highest quality and that they are easy to use and
maintain.
We recommend that you read this manual carefully to achieve the maximum benefit of
your new hearing instruments.
Congratulations on your decision to actively improve your hearing with today’s most
advanced hearing technology.
Contents
Instrument View 5
Turning your instruments ON and OFF 6
Putting on the hearing instrument 8
Changing batteries 10
AutoPhone 12
Caring for your hearing instrument 14
Daily maintenance Micro Mould 16
Daily maintenance with domes 20
Using your hearing instrument 24
Common problems and their solutions 30
International Warranty 32
Warnings Yellow Pages
4
IMPORTANT NOTICE
Please familiarise yourself with the entire contents of this booklet before using your
hearing instruments. It contains instructions and important information about the use
and handling of your instruments and batterie.
5
Instrument View
Ear grip
Battery door
Microphone
openings
Sound outlet
Speaker unit
Micro mould
Plus dome
Your ear piece:
6mm
8mm
10mm
8mm
10mm
12mm
Battery size: 10
Battery size: 312
Open dome: Power dome:
6
Turning your instruments ON and OFF
Turn ON your hearing instrument by closing the battery door completely with the battery
in place. When the battery door is closed the instrument will start up by playing a jingle.
This indicates that the battery is working and the instrument is operating.
Turn OFF your hearing instrument by opening the battery door.
With Dual Connect (312 size battery) the hearing instrument will turn off when the battery
door is half way open - you are able to feel a soft click. With Dual Mini (10 size battery)
the battery door must be fully opened to turn off the instrument.
To preserve the battery, make sure your hearing instrument is switched off when you are
not wearing it.
IMPORTANT NOTICE
Open the battery compartment fully to allow air to circulate whenever you are not
using your hearing instrument, especially at night!
7
ON
OFF
8
Putting on the hearing instrument
Turn the instrument on. Place the speaker, with the ear piece attached, into your ear first
and then place the amplifier behind your ear. If the instrument comes with a Micro
Mould, make sure that the coloured dot (blue or red) on the mould is facing towards the
amplifier unit (upwards) to ensure a correct position in the ear canal.
Make sure that the ear piece is placed so that the tube follows the contour of the skin.
If the instrument has an ear grip, place it in the concha as indicated in drawing 4.
Alternatively place the amplifier behind your ear. Put the speaker into your ear canal.
Left/right indication for hearing instrument
Blue colour indicates left instrument.
Red colour indicates right instrument.
9
Concha
Left/right
indicator
10
Changing batteries
Your Dual hearing device uses either a size 10 or 312 battery.
A worn out battery should be removed immediately and disposed of according to local
regulations.
When the battery power is low, you will hear 2 beeps. This pre-warning starts when the
battery has only a few hours of operation left. The pre-warning will be repeated in
moderate intervals to indicate it is time to change the battery.
If the battery runs out the instrument turns
off. When that happens, 4 beeps are played
to indicate that the instrument is no longer
operating.
This is not an indication of a malfunction.
