Oticon CIC P User manual

INSTRUCTIONS FOR USE CIC / MIC / ITC / ITE

Thank you

Thank you for choosing our product as your means to better hearing.

To support your efforts, we have put great care and attention into making sure that your

new hearing instruments are of the highest quality and that they are easy to use and

maintain.

We recommend that you read this manual carefully to achieve the maximum benefit of

your new hearing instruments.

Congratulations on your decision to actively improve your hearing with today’s most

advanced hearing technology in the market.

Contents

Instrument View CIC/MIC 5a

Instrument View ITC 5b

Instrument View ITC Power 5c

Instrument View ITE 5d

Changing batteries 7

Turning your instruments ON and OFF 9

Left/Right ear marking 10

Inserting your hearing instruments 11

Programs (Optional) 12

Standby (Optional) 15

Volume Control by Push Button (Optional for Ino Pro ITC* only) 16

Volume Control by Wheel (Optional for ITE and ITC Power) 18

Telecoil (Optional) 21

Auto Phone (Optional) 22

Caring for your hearing instruments 24

Using your hearing instrument 30

IMPORTANT NOTICE

Please familiarise yourself with the entire contents of this booklet before using your

hearing instru ments. It contains instructions and important informa tion about the use

and handling of your hearing instru ments and batteries.

Instrument View CIC/MIC

Microphone opening Battery door

Ventilation opening

Sound outlet +

wax protection system

Ventilation opening

Battery size: 10

Pull-out string

Common problems and their solutions 36

Warranty Certificate 40

Warnings Yellow Pages

Instrument View ITC

Battery size: 312

One or two microphone

openings

Battery door Ventilation opening

Ventilation opening

Sound outlet +

wax protection system

Push-button (Optional)

IMPORTANT NOTICE

Open the battery compartment fully to allow air to circulate whenever you are not

using your hearing instrument, especially at night!

Instrument View ITC Power

Ventilation opening

Sound outlet +

wax protection system

One or two microphone

openings

Push-button (Optional)

Volume Control Wheel

(Optional)

Battery door

Ventilation opening

IMPORTANT NOTICE

Open the battery compartment fully to allow air to circulate whenever you are not

using your hearing instrument, especially at night!

Battery size: 312

IMPORTANT NOTICE

Open the battery compartment fully to allow air to circulate whenever you are not

using your hearing instrument, especially at night!

Battery size: 312

Instrument View ITE

Microphone openings Push-button (Optional)

Volume Control Wheel

(Optional)

Battery door

Ventilation opening

Sound outlet +

wax protection system

Changing batteries

The correct battery size appears in the instrument overview in the first section of

this document. Batteries perform differently. Ask your hearing care professional for help

choosing a high quality battery for your hearing instrument.

A worn out battery should be removed immediately.

When the battery power is low, you will hear a series of short beeps. This indicates

that it is time to change the battery.

To replace the battery, follow these instructions:

• Open the battery door with your fingernail and remove the

old battery.

• Remove the sticky label from the + side of the new battery.

IMPORTANT NOTICE

Open the battery compartment fully to allow air to circulate whenever you are not

using your hearing instrument, especially at night!

8 9

Turning your instruments ON and OFF

Turn ON your hearing instrument by closing the battery

door completely with the battery in place.

When the battery door is closed the instrument will start up

by playing a jingle. This indicates that the battery is working

and the instrument is operating.

Turn OFF your hearing instrument by opening the battery

door with your finger nail.

To preserve the battery, make sure your hearing instrument

is switched off when you are not wearing it.

• Insert the new battery so that its + marking faces the + sign printed on the

battery door.

• Close the battery door. If you feel any resistance, you may have inserted the battery

incorrectly. Reinsert the battery and try again.

It will take a few seconds before the battery works to full capacity.

To assist the handling of the batteries, the magnet placed

at the end of the tool can be used.

OFF

MultiTool

10 11

Left/Right ear marking

Hearing instruments are fitted to the uniqueness of each ear, which means if you have

two instruments then your left hearing instrument is shaped and programmed differently

from your right. That is why it is important to distinguish between the left hearing

instrument and the right.

In order to easily identify whether it is the left ear or right ear instrument, colour markings

may be applied.

Blue text or a blue dot marks the LEFT instrument.

Red text or a red dot marks the RIGHT instrument.

Inserting your hearing instruments

Place the tip of the hearing instrument in your ear canal.

Gently pull your ear and push the hearing instrument into

the ear canal, twisting slightly if necessary, following the

natural contour of the ear canal.

DO NOT use the battery door as a handle to insert or remove

your instruments. It is not designed for this purpose.

12 13

Programs (Optional)

Your hearing instruments may have a push-button for switching between

different programs.

Push briefly on the button to switch to the next program.

A push will go forwards in the program cycle e.g from P1->P2.

When the highest numbered program is reached, the cycle

starts from program one again.

Your hearing instrument can have up to 4 different programs.

When switching between the different programs, your hearing instrument will beep.

The number of beeps will indicate which program you are using.

One beep, when you switch to program 1

 Two beeps, when you switch to program 2

 Three beeps, when you switch to program 3

 Four beeps, when you switch to program 4
