Oregon Scientific RM602 User manual

BIORHYTHM RF CLOCK

MODEL NO.: RM602

USER’S MANUAL

SECTION 1 INTRODUCTION

Congratulations on your purchasing the RM602 Biorhythm RF

Clock. Now you can forecast the physical, emotional, intellectual

and intuitive conditions of yourself and three people you care

most by pressing a few buttons.

An easy-to-operate device, the RM602 is also designed to

automatically synchronize its current time and date when brought

within an approximate 1500km radius of the radio signal

DCF77generated from Frankfurt, Germany.

Other functions of the RM602 include dual daily alarms with

snooze function and backlight.

CONTROL BUTTONS

A ANTENNA / STAND

Receives RF signal for RF clock and rotate to the desired angle

for viewing.

B MODE BUTTON

Changes among physical, emotional, intellectual and intuitive

scans of individual users

C UP[ ] BUTTONS

Scans the biorhythm of a user for a particular day or change the

value of a setting

D DOWN [ ] BUTTONS

Scans the biorhythm of a user for a particular day

E USER BUTTON

Changes the user to be scanned for biorhythm or enters the

birthdays of individual users

F CLOCK / ALARM BUTTON

Changes among clock, calendar and alarm modes

G SNOOZE / LIGHT BUTTON

Activates the snooze function or turns on the backlight

H ALARM ON / OFF BUTTON

Changes the operating status of the daily alarms

I RESET BUTTON

Returns all settings to default values

BATTERY INSTALLATION

1. Remove the battery compartment door.

2. Insert two AA-sized (UM-3) batteries.

3. Replace the battery compartment door.

Replace the batteries when the low-battery indicator appears.

BEFORE YOU BEGIN

• Place the RM602 on a flat, sturdy surface.

• Adjust the antenna to the best angle for viewing. The antenna

can be rotated through 0, 30, 60 and 90 degrees.

THE BACKLIGHT

Press [SNOOZE/LIGHT] to turn on the backlight for five

seconds.

SECTION 2 THE CALENDAR CLOCK

DISPLAY MODES

In normal display, the current time, including seconds, will be

displayed. Press [CLOCK/ALARM] repeatedly to display the

following in sequence:

• Current time and day-of-the-week

• Date

• TimeforALARM1

• Timefor ALARM 2

• Current time and seconds

ABOUT RADIO RECEPTION

The RM602 is designed to automatically synchronize its current

time and date when brought within range of the DCF77 RF signal.

When the unit is within range, its radio-control mechanism will

override all manual settings.

When the unit is receiving radio signal, the reception icon will start

to blink. The reception icon will show either strong, weak or no

signal depending on the strength of the radio signal. A complete

reception generally takes about two to 10 minutes.

When the reception is completed the reception icon will stop

blinking. The reception icon will show [ ] for no reception or

[ ] for successful reception.

30°

60° 90°

Receiving

radio

signal No signal Weak signal Strong signal

For better reception of radio signals, place the clock away from

metal objects and electrical appliances to minimize interference.

HOW TO ENABLE OR DISABLE

AUTO-RECEPTION

If you wish to disable the auto-reception feature while the unit

is within range, hold down the [CLOCK] and [ ] buttons

simultaneously for two seconds. The [ ] signal will disappear.

The unit will NOT respond to radio signals.

To enable the feature again, hold down the buttons again. The

[ ] signal will start blinking to initiate reception

automatically.

HOW TO SET THE CALENDAR

CLOCK MANUALLY

When the current time is displayed,

1. Press [CLOCK/ALARM] for two seconds.

2. Enter the hours using [ ]. Hold down [ ] to rapidly i n -

crease the value.

3. Press[CLOCK/ALARM].

4. Enter the minutes using [ ].

5. Press[CLOCK/ALARM].

6. Follow the same pattern to set year, month, day and date format

(day-month or month-day).

Press [CLOCK/ALARM] to save the changes and exit. If changes

are made for the minute, the seconds will reset and start from

zero.

The unit will also save all changes and return to normal display

automatically after the unit has been left idle for a minute.

HOW TO SET THE ALARMS

1. Select ALARM1 or ALARM2 using [CLOCK/ALARM].

2. Press and hold [CLOCK/ALARM] for two seconds.

3. Use [ ] to enter the hours.

4. Press[CLOCK/ALARM].

5. Use [ ] to enter the minutes.

6. Press [CLOCK/ALARM] to exit.

HOW TO USE THE ALARMS

To activate or deactivate an alarm, press [CLOCK/ALARM] to

select the alarm and press [ALARM ON/OFF]. The alarm time

will be displayed when the chosen alarm is activated. Otherwise,

blanks will be displayed.

Reception

complete No reception, or

manually adjusted Successful reception

You can have both alarms enabled or disabled at the same time.

When an alarm goes on, press [ALARM ON/OFF] to mute the

alarm. Or press [SNOOZE/LIGHT] to activate the snooze function.

SNOOZE FUNCTION

When the snooze function is activated, the alarm will be muted

temporarily and set on again after eight minutes. To disable the

snooze function, press [ALARM ON/OFF].

SECTION 3 THE BIORHYTHM FUNCTION

HOW TO ENTER USER BIRTHDAYS

To have a biorhythm scan, you have to enter the user’s birthday

first. The RM602 can support up to three users.

To enter a birthday,

1. Select USER 1, 2 or 3 by pressing [USER].

2. Press and hold [USER] for two seconds.

3. Use [ ] to enter the year of birth.

4. Press[USER].

5. Use [ ] to enter the month of birth.

6. Press[USER].

7. User [ ] to enter the day of birth.

8. Press [USER] to exit.

Note: The birthday is constraint to the current day. If the

birthday entered is after the current day, no biorhythm chart

will be shown.

ABOUT BIORHYTHM

The unit can forecast the biorhythm of a user according to the

entered birthday. The forecast includes conditions for physical,

emotional, intellectual and intuitive element.

The conditions for the four elements fluctuate, since birth, over

a fixed but individual cycle. The cycle for the physical, emotional,

intellectual and intuitive elements are, approximately, 23 days,

28 days, 33 days and 38 days, respectively.

For each element, there are active (above zero level) and passive

(below zero level) days. When crossing from active to passive,

one is having a critical day; and a zero day if it is the contrary.

So, do a scan on your biorhythm and make the most of your day.

HOW TO BIO-SCAN THE CURRENT DAY

1. Select the user by pressing [USER].

2. Select the bio element by pressing [MODE].

A kinetic display of the biorhythm will appear with the current

day status flashing on the chart. An indicator will light up to

show if your active or passive condition is increasing, decreasing

or reaching the peak or trough.

And, to alert you to your critical days, a warning indicator will

appear. Each cycle contains one zero day at the beginning and

one critical day in the middle.

HOW TO BIO-SCAN A PARTICULAR DAY

1. Select the user by pressing [USER].

2. Select the bio element by pressing [MODE].

3. Press [ ] for the previous day or [ ] for the next.

The unit is capable of scanning any day between user's birthday

and 2099.

SECTION 4 ADDITIONAL INFORMATION

THE RESET BUTTON

The [RESET] button is used to enhance synchronization of

signals after battery replacement or when the unit is operating in

an unfavourable way or malfunctioning. Use a blunt stylus to

hold down the button. All settings will return to their default

values.

Critical Days Zero Day

Passive Increasing Passive Decreasing

Peak Trough

Active Increasing Active Decreasing

PRECAUTIONS

This unit is engineered to give you years of satisfactory service

if handled carefully.

1. Do not immerse the unit in water.

2. Do not clean the unit with abrasive or corrosive materials.

3. Do not subject the unit to snow or excessive force, shock,

dust, temperature or humidity.

4. Do not tamper with the unit’s internal components.

5. Do not mix new and old batteries or batteries of different

specifications.

SPECIFICATIONS

24-h display : hh : mm : ss

Day-of-the-week : Day / Month / Year or

Month / Day / Year

date-of-week in English

Daul alarm : Two (2) minutes crescendo

Power : Two (2) UM-3 or “AA”1.5V

battery

Size : 71 x 147 x 29 mm (H x W x D)

Weight : 124g (not including batteries)

CAUTION

— The content of this manual is subject to change without

further notice.

— Due to printing limitation, the displays shown in this

manual may differ from the actual display.

— The manufacturer and its suppliers held no

responsibility to you or any other person for any damage

expenses, lost profits, or any other claim arise by using

this product.

— The contents of this manual may not be reproduced

without the permission of the manufacturer.
