OPTICOM VDC10X - DATA User manual

November 8, 2010

Extreme/Specialty Camera

VDC10X

10x Zoom Day/Night PTZ Camera

VDC10X

Sensor

Resolution

Lens

Zoom

Illumination

Sync System

S/N RatioS/N Ratio

Video Output

White Balance

Auto Gain Control

Auto Level Control

Electronic Shutter

Back Light

CompensationCompensation

On Screen Display

Gamma Correction

External Control

Pan

Tilt

Auto Cruise

Power SourcePower Source

Operating Temp

1/4” Sony Super HAD

480 TV Lines

F 1.6~1.9 / f=3.7~37.8mm

10x Optical, 10x Digital

0.03 Lux

Internal/External (AC Lock)

More than 46dBMore than 46dB

1.0 Vp-p/ 75Ω

ATW / ATB / FIX

+24dB (max)

Auto / Fix (OSD Control)

1/60 ~ 1/120,000 sec

48 Zone BLC (OSD Control)

Zoom, Focus, Iris, AWB, AGC, Zoom, Focus, Iris, AWB, AGC,

Position, C Gain, AGC Gain

0.45/1

RS485

Speed: 0.5 - 360°

Speed: 0.5 - 180°

6 Auto Cruising Tracks (max)

DC 12V, 6W (max)DC 12V, 6W (max)

14° ~ 122° F (-10° ~ 50° C)

-Features-

■ 10x Optical, 10x Digital

■ Day & Night

■ Presets up to 32 positions

■ 6 Auto Cruise Programs

■ ICR Mechanical Cut Filter

■ On Screen Display■ On Screen Display

Page 1 of 1

-Specifications-
