Oki C110 User manual
C110
User’s Guide
x-1
Preface
Every effort has been made to ensure that the information in this document is com-
plete, accurate, and up-to-date. The manufacturer assumes no responsibility for the
results of errors beyond its control. The manufacturer also cannot guarantee that
changes in software and equipment made by other manufacturers and referred to in
this guide will not affect the applicability of the information in it. Mention of software
products manufactured by other companies does not necessarily constitute endorse-
ment by the manufacturer.
While all reasonable efforts have been made to make this document as accurate and
helpful as possible, we make no warranty of any kind, expressed or implied, as to the
accuracy or completeness of the information contained herein.
The most up-to-date drivers and manuals are available from:
http://www.okiprintingsolutions.com
Copyright © 2009 Oki Europe Ltd. All rights reserved.
Oki is a registered trademark of Oki Electric IndustryCompany Ltd.
Oki Printing Solutions is a trademark of Oki Data Corporation.
Energy Star is a trademark of the United States Environmental Protection Agency.
Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corpora-
tion.
Apple, Macintosh, Mac and Mac OS are registered trademarks of Apple Computer.
Other product names and brand names are registered trademarks or trademarks of
their proprietors.
As an Energy Star Program Participant, the manufacturer has deter-
mined that this product meets the Energy Star guidelines for energy
efficiency.
This product complies with the requirements of the Council Direc-
tives 2004/108/EC (EMC), 2006/95/EC (LVD) and 1999/5/EC
(R&TTE), as amended where applicable, on the approximation of the
laws of the member states relating to electromagnetic compatibility,
low voltage and radio & telecommunications terminal equipment.
x-2
Emergency first aid
Take care with toner powder:
If swallowed, give small amounts of cold water and seek medical
attention. DO NOT attempt to induce vomiting.
If inhaled, move the person to an open area for fresh air. Seek medi-
cal attention.
If it gets into the eyes, flush with large amounts of water for at least
15 minutes keeping eyelids open. Seek medical attention.
Spillages should be treated with cold water and soap to help reduce
risk of staining skin or clothing.
Importer to the EU/authorised representative
Oki Europe Limited (trading as Oki Printing Solutions)
Blays House
Wick Road
Egham
Surrey, TW20 0HJ
United Kingdom
For all sales, support and general enquiries contact your local distributor.
Environmental information
Contents
Contents x-3
Preface........................................................................................................ x-1
Emergency first aid ..................................................................................... x-2
Importer to the EU/authorised representative ............................................. x-2
Environmental information .......................................................................... x-2
1Introduction .................................................................................................... 1-1
Getting Acquainted with Your Printer .......................................................... 1-2
Space Requirements................................................................................... 1-2
Printer Parts ................................................................................................ 1-3
Front View............................................................................................. 1-3
Rear View ............................................................................................. 1-4
About the Control Panel ................................................................................ 1-5
About the Indicators .................................................................................... 1-5
About the Rotate Toner KEY....................................................................... 1-6
When replacing a toner cartridge.......................................................... 1-6
When cleaning the print head window .................................................. 1-7
When replacing all toner cartridges at the same time........................... 1-7
About the Cancel KEY ................................................................................ 1-7
Continuing a Print Job after an Error Message..................................... 1-7
Cancelling a Print Job ........................................................................... 1-8
Contentsx-4
About the Printer Driver and Utility CD/DVD ............................................... 1-9
System Requirements ................................................................................. 1-10
2Using the Printer Driver ................................................................................ 2-1
Selecting Printer Driver Defaults .................................................................. 2-2
Uninstalling the Printer Driver ...................................................................... 2-3
Windows Vista/XP/Server 2003/2000 ................................................... 2-3
Displaying Printer Driver Settings ............................................................... 2-3
Windows Vista ...................................................................................... 2-3
Windows XP/Server 2003 ..................................................................... 2-3
Windows 2000 ...................................................................................... 2-4
Printer Driver Settings ................................................................................... 2-5
Common Buttons ........................................................................................ 2-5
Basic Tab .................................................................................................... 2-6
Layout Tab .................................................................................................. 2-6
Overlay Tab................................................................................................. 2-7
Watermark Tab ........................................................................................... 2-7
Quality Tab.................................................................................................. 2-7
Version Tab................................................................................................. 2-7
3Remote Panel Utility ...................................................................................... 3-1
Working with the Remote Panel Utility ........................................................ 3-2
Introduction ................................................................................................. 3-2
Opening the Remote Panel Utility ............................................................... 3-2
Using the Remote Panel Utility ................................................................... 3-2
Panel Tab.............................................................................................. 3-2
User Service Tab .................................................................................. 3-4
Closing the Remote Panel Utility ................................................................. 3-4
4Media Handling .............................................................................................. 4-1
Print Media ..................................................................................................... 4-2
Specifications .............................................................................................. 4-2
Types .............................................................................................................. 4-3
Plain Paper (Recycled Paper)..................................................................... 4-3
Thick Stock.................................................................................................. 4-4
Envelope ..................................................................................................... 4-5
Label ........................................................................................................... 4-6
Letterhead................................................................................................... 4-7
Postcard...................................................................................................... 4-7
Printable Area ................................................................................................ 4-8
Envelopes ................................................................................................... 4-9
Page Margins .............................................................................................. 4-9
Loading Media .............................................................................................. 4-10
Tray 1 (Multipurpose Tray)........................................................................ 4-10
Loading Plain Paper............................................................................ 4-10
Other Media ........................................................................................ 4-12
Contents x-5
Loading Envelopes ............................................................................. 4-12
Loading Label Sheets/Letterheads/Postcards/Thick Stock................. 4-14
Output Tray .................................................................................................. 4-16
Media Storage .............................................................................................. 4-16
5Replacing Consumables ............................................................................... 5-1
Replacing Consumables ............................................................................... 5-2
About Toner Cartridges............................................................................... 5-2
Replacing a Toner Cartridge................................................................. 5-4
Replacing All Toner Cartridges at the Same Time...................................... 5-9
Replacing the Imaging Cartridge............................................................... 5-10
Replacing the Fuser Unit........................................................................... 5-13
6Maintenance ................................................................................................... 6-1
Maintaining the Printer .................................................................................. 6-2
Cleaning the Printer ....................................................................................... 6-4
Exterior........................................................................................................ 6-4
Interior ......................................................................................................... 6-5
Cleaning the Media Feed Roller ........................................................... 6-5
Cleaning the Print Head Window .......................................................... 6-8
7Troubleshooting ............................................................................................ 7-1
Introduction .................................................................................................... 7-2
Preventing Media Misfeeds ........................................................................... 7-3
Understanding the Media Path ..................................................................... 7-4
Indicator Messages ....................................................................................... 7-5
Status Messages......................................................................................... 7-5
Warning Messages ..................................................................................... 7-5
Error Messages........................................................................................... 7-7
Service Message......................................................................................... 7-9
Clearing Media Misfeeds ............................................................................ 7-10
Clearing Procedures ................................................................................. 7-11
Solving Problems with Media Misfeeds ..................................................... 7-18
Solving Other Problems .............................................................................. 7-20
Solving Problems with Printing Quality .................................................... 7-22
AAppendix ........................................................................................................A-1
Technical Specifications ...............................................................................A-2
Printer..........................................................................................................A-2
Consumable Life Expectancy Chart............................................................A-3
User-Replaceable .................................................................................A-3
Service-Replaceable ..................................................................................A-4
Index ....................................................................................................................... I-1
Oki contact details .......................................................................................... I-3
Contentsx-6
Introduction
Getting Acquainted with Your Printer1-2
Getting Acquainted with Your Printer
Space Requirements
To ensure easy operation, consumable replacement and maintenance,
adhere to the recommended space requirements detailed below.
Side View
Front View
496 mm (19.5")
100 mm
(3.9")
396 mm (15.6")
707 mm (27.8")
100 mm
(3.9")
380 mm (14.9")
520 mm (20.5")
127 mm
(5.0")
245 mm
(9.6")
275 mm (10.8")
100 mm
(3.9")
Getting Acquainted with Your Printer 1-3
Printer Parts
The following drawings illustrate the parts of your printer referred to through-
out this guide, so please take some time to become familiar with them.
Front View
1—Output tray
2—Control panel
3—Front cover
4—Tray 1 (Multipurpose tray)
5—Top cover
6—Fuser unit
7—Fuser separator levers
8—Fuser cover lever
9—Imaging cartridge
10—Toner cartridge
1
2
3
4
5
7
7
6
9
10
8
6
10
9
