Ocean Digital WR-26F User manual

WR-26F

Portable Internet Radio

Please read this user manual carefully before using the receiver.

User Manual

- 3 -

Contents

1. Introduction to the WR-26F Internet Radio .................4

2. Location of controls .................................................5

3. Choosing options and functions ................................7

4. Network Setup ........................................................8

5. Overview of Radio modes and functions ..................10

6. My Favorite ...........................................................12

7. Internet Radio .......................................................13

8. Media Center ........................................................15

9. FM Radio ..............................................................16

10. Bluetooth Speaker ...............................................17

11. Sleep Timer .........................................................18

12. Conﬁguration ......................................................19

13. Skytune Web Application for Internet Radio

www.skytune.net ................................................21

14. Problems and Solutions .......................................23

15. Technical Speciﬁcations .......................................25

- 4 -

1Introduction to the WR-26F

Internet Radio

The WR-26F Internet Radio is a compact and light weight

portable radio with an internal 2000 mAh Li-Ion

rechargeable battery for many hours of audio

entertainment and a gateway into the world of digital

audio.

There are seven different operating modes requiring

different wireless connections as listed below:

1) My Favorite (No Wi-Fi or Internet)

• List of previously Preset favorite listening choices

2) Wireless Wi-Fi (Internet connected)

• Internet Radio with more than 30 thousand radio

stations worldwide

3) Media Center (Wi-Fi - no Internet)

• Play music streamed over the Wi-Fi network by a

UPnP or DLNA server e.g. smart phone, laptop.

4) Wireless (direct broadcast – no Internet or Wi-Fi)

• FM Radio

5) Wireless (Bluetooth – no Internet or Wi-Fi)

• Play audio transmitted from a Bluetooth source e.g.

smart phone, Laptop.

6) Timer (no Wi-Fi or Internet)

• Adjustable timer to delay putting the Radio into

Standby mode

7) Conﬁguration (no Wi-Fi or Internet)

• Set up, options and information center

Precautions

Charge the battery with a USB charger – do not apply any

other power source or permanent damage to the radio will

occur and may be hazardous.

To clean use only a damp cloth and dry with a clean towel -

keep away from all liquids.

To avoid loss of warranty do not attempt to repair or

remove the cover for any reason.

- 5 -

2Location of controls

234

5 6 789

10 11

12 14

- 6 -

Location of controls

1) Press and Hold – turn On/Standby (On/Off without

USB power)

2) Press and Hold – add to Favorite list

Press and Release – display the Favorite list

3) Main menu – go to My Favorite

4) Conﬁrm selection

Internet Radio – Stop playing / Resume Playing

FM and Bluetooth – Mute

5) Move Back – previous menu

Bluetooth – replay previous song

6) Move Forward – next display or next in list

Playing – Display Clock, Battery level and Radio

station information

Favorite list – go to Edit list mode

Bluetooth – skip to the next song

7) Decrease volume (Hold for continuous decrease)

Move down list

8) Increase volume (Hold for continuous increase)

Move up list

9) Color Display

10) Loud speaker

11) Telescopic FM radio antenna

12) Micro USB connector for battery charging

13) LED – Red battery charging / Green charging

complete

14) Headphone 3.5 mm connector

- 7 -

3Choosing options and functions

All user input is information that the Radio uses to provide

the desired audio entertainment with select (OK button) a

conﬁrmation and go to command.

Navigate to a function (i.e. My Favorite, Internet Radio,

Media Center, FM Radio, Bluetooth, Sleep Timer and

Conﬁguration) or a position in a list by using the Move

Forward (►), Move Back (◄), Move Up (▲) and Move

Down (▼) controls.

Once a desired selection is displayed or highlighted the

selection is conﬁrmed by pressing and releasing the [OK]

button.

Throughout this manual “Select” will mean navigating

through option lists or display screens until the desired

selection is displayed or highlighted and conﬁrming it by

pressing and releasing the [OK] button.

- 8 -

4Network Setup

The Internet Radio must have a high bandwidth internet

connection and a wireless (Wi-Fi) home network

connected to it to be fully functional.

To conﬁgure the Wi-Fi network connection turn on the

radio by pressing and holding [ ] button until the display

illuminates - this normally takes 3 - 5 seconds.

The ﬁrst time the Radio is turned on after leaving the

factory a Conﬁgure Network wizard is automatically

started:

1) Highlight and Select Yes to connect to the Wi-Fi

network

2) The display will change and display a list of options –

Select Add AP (Scan)

3) The display will show a list of available networks –

Select your network

4) The display will ask for your passcode/password –

using the [ ▲ ] and [ ▼ ] buttons highlight the ﬁrst

digit and press [ ► ] button to conﬁrm and input the

next character. highlight the next digit and press [ ► ]

button to move forward. Repeat until the last digit is

highlighted. While the last digit is highlighted Select

by pressing and releasing the [ OK ] button. If the

wrong character be input, press [ ◄ ] button to delete

it.

5) If the connection is successful “Association

Complete” will be displayed brieﬂy.

- 9 -

To repeat the above procedure, or if the Conﬁgure

Network wizard does not automatically start, the network

can be connected by using the Conﬁguration mode.

1) Press the [ ] button to go to the mode selection

options

2) Select Conﬁguration

3) Select Network

There are two different options to connect to the network

from the Conﬁguration mode:

1) Repeat steps 1) through 5) above page 8.

2) Select Add AP (WPS button) – Press WPS button on

your router within 2 minutes to complete the

connection.

Connection status is displayed on the bottom left hand

corner of the LCD with the Wi-Fi symbol and signal

strength bars ( ).

For best Wi-Fi performance, limit “drop outs”

(interruptions) the Wi-Fi Channels must be set according

to the location of the Radio e.g. China, USA, Europe. The

factory default is China.

To set the correct location, select

Conﬁguration>Network>Wi-Fi Channels and select the

correct option.

Network Setup

- 10 -

5Overview of Radio modes

and functions

To Select any mode use the Menu button [ ] on top of

the radio to display the My Favorite screen:

Navigate through the modes to ﬁnd and Select any of

these functions:

1) My Favorite – A maximum of 99 previously saved

(Preset) favorite listening sources are listed for

Selection.

2) Internet Radio – Select online radio station from the

thousands available on Skytune or by using the History

list of previously selected radio stations or use search

to ﬁnd a preferred radio station.

3) Media Center – Browse and Select music streaming on

your home Wi-Fi network by any UPnP or DLNA

compatible server e.g. Smart phone, Tablet, PC,

Laptop.

4) FM Radio – Play your favorite local radio station using

the telescopic antenna.

5) Bluetooth – When “Paired” (connected) to another

Bluetooth device use the Radio as a powered speaker.

Maximum range of the Bluetooth wireless signal is 10

meters (32 feet) but may be reduced by the presence of

walls or other obstructions.

Internet Radio

My Favourite

1/7 >

Media Center

FM Radio

Bluetooth

Sleep Timer

Conﬁguration
