Ocean Digital WR-210CB User manual

Internet radio with bluetooth

User Manual

WR-210CB

Please read this user manual carefully before using the receiver.

Location of Controls

1. Standby button

2. Right button

3. Left / Back button

4. Preset button

5. Local button

6. Home

7. Infrared remote sensor

8. Speaker

9. TFT display 2.4”

10. Rotary control knob for

Volume/Dial/Select – Rotate

to adjust the volume/browsing

menu, press the knob to select

for conﬁrmation

11. Aux-in jack

12. Earphone jack

13. Line out jack

14. DC IN jack

DCIN9V

Aux-in

11 12 13 14

‒ 1 ‒

Remoter control

‒ 2 ‒

1. : Mute

2. : Standby button

3. 0-9: Favorite station key / input letters and

numbers for WiFi Encryption code

4. : Preset the current playing station to

Favorite

5. : Recall the favorite list

6. ▲: Cursor up

7. t: Cursor left / back to previous menu

8. u: Cursor right

9. ▼: Cursor down

10. OK: confirm button

11. : Alarm button

12. : Sleep Timer

13. Vol+: Volume up

14. Vol-: Volume down

15. : Main Menu

16. Mode: Switch between the modes of

radio

17. EQ: Equalizer

18. : Previous station on the list/previous

track on UPnP

19. : Play/pause for internet radio

20. : Next station on the list/next track on

UPnP

21. Local: Access the local station list (Local

area set up in Configuration)

22. Info: View the detailed info of the radio

channel or the music info under

UPnP.

23. Dimmer: Dim down the backlight of

display

Remote control character list

Key“0”―― 0,‘DEL’

Key“1”―― ‘1’->‘@’->‘ ’（space）->‘！’-> “ (double quotes)

->‘#’->‘$’->‘%’->‘&’-> ’（single quotes）->‘（’

->‘）’->‘*’->‘+’->‘，’->‘-’->‘.’->‘/’->‘:’->‘;’->‘<’->‘=’->‘>’->‘?’-

>‘[’->‘\’->‘]’->‘^’->‘_’->‘`’->‘{’->‘|’->‘}’->‘~’

Key “2”―― 2,A,B,C,a,b,c

Key“3”―― 3,D,E,F,d,e,f

Key“4”―― 4,G,H,I,g,h,i

Key“5”―― 5,J,K,L,j,k,l

Key“6”―― 6,M,N,O,m,n,o

Key“7”―― 7,P,Q,R,S,p,q,r,s

Key“8”―― 8,T,U,V,t,u,v

Key“9”―― 9,W,X,Y,Z,w,x,y,z

Remark: press ’→’ to move to next character and press ’OK’ button to

conﬁrm.

You can also press ↑ ↓ to change the character /number, then press the

right key to conﬁrm the entry.

After you ﬁnish the entry, press the select button to conﬁrm.

Switching on the radio

Connect the mains adaptor to the radio unit, one end to the DC IN on the

radio and the other end to the AC mains wall socket.

Caution: Use only the mains adaptor supplied with the radio.

Connecting a power supply with a different rating will cause

permanent damage to the radio and may be hazardous.

The display on the front of the radio will light up and show:

Then you can select your prefer language on the radio.

Welcome

• English

Deutsch

Français

< 2/7 8

01:44

‒ 3 ‒

It will ask you if you want to Enable the <Check Network when Power

on>, it is suggested to choose <Yes>. Then the radio will always check

the available WiFi network automatically.

Connecting to your WiFi Network

The screen below will appear. You can choose <Yes> to proceed to

search for the available WiFi network. If your router has the WPS

function, you can select <Yes(WPS)> to proceed.

It will then start scanning the network. After the search is done, it will

display a list of the available router.

Choose your router from the list, enter the WEP (Wired Equivalent

Privacy) or WPA(Wi-Fi Protected Access) code. If your network is not

encrypted with the WEP or a WPA code, the unit will connect to the router

automatically.

Note: The encryption code would have been set up by the person

who set up and conﬁgured your network.

Please follow the steps below to enter the encryption code of your router.

- Rotate the rotary knob to browse the character

- Press the Úright button to skip to the next entry

- After you ﬁnish with the entries, press the Rotary knob to conﬁrm.

The radio will start connecting to the network.

After the router is connected successfully, it will display the main menu as

follow:

01:01

Would you like to

configure Network now?

Yes(WPS) NOYes

01:44

Linksys

Homeaudio

Demo

MOVE INPUT:OK

Ent er

Password

1/1

16:23

‒ 4 ‒

08:58

Internet Radio

You can now start enjoying the internet radio.

Internet Radio

Choose <Internet Radio> from the menu, you can see several listed

options.

To start listening the radio stations worldwide, select <Radio

Station/Music>.

My Favorite

This is to show the list of your Favorite stations which have been

assigned to the presets.

To preset a station:

While you are playing the favorite station, long pressing the <Preset>

button and the <Add to My Favorite> menu will display. Press the rotary

knob to conﬁrm. The playing station will be added to the preset list

automatically.

The presets will be stored in ascending order. You can store up to 250

presets.

Note: Preset 1 to 5 are reserved for your own choice of the dedicated

radio channels. The preset will be intended to store from no. 6

onwards, you can scroll to choose no. 1-5 at your preference.

You can edit your favorite list anytime. Go to <My Favourite> on the

menu or press the <Preset> button when it displays the list of favorite

stations, then press the -> right button. The following options will

display:

Delete – To delete the selected station

Press rotary knob to conﬁrm The symbol on the top row means

station is added to preset list

‒ 5 ‒

Shift up- To shift the selected station by one level up on the ranking

Shift down – To shift the selected station by one level down on the ranking

Rename – To rename the selected station

Play – press and play the selected station

Choose the radio station that you want to make with the above changes.

Then press the Right key, it will enter into the list with the options listed

above. Then choose your desire action.

To recall a preset station:

Press the <Preset> button brieﬂy and choose your desire station.

Radio Station / Music

Select this option, then you can select your desired radio station by

Genre, Location., etc.

Local Radio

If you want to access quickly the radio station located in your area, select

this function and it will display the list of the stations available in your

area.

History

The radio will memorize the last 10 listened stations.

Service

Search Stations

You can ﬁnd your desire radio station by entering the name of the radio.

Add New Radio Station

If you cannot ﬁnd your desire station from the Radio station list and you

have the streaming URL address, you can input the link here and add to

your favorite list.

When the radio station is playing, the display will show a color image

transmitted from the radio station.

iRadio

.977 The 80s Channel

977

Music

Internet Radio

Delete

Shift Up

Shift Down

< 1/5 >

iRadio

‒ 6 ‒

Aux In

You can enjoy the music from other audio devices by connecting the

audio cable to the AUX IN connector at the rear of the unit, such as smart

phone, MP3 player, etc.

DLNA

The Internet radio can play music stream from DLNA compatible device,

provided that the Internet radio and other DLNA devices are under the

same Wi-Fi network.

The radio will be discovered as “AirMusic” when you try to search it on

other devices. If you want to change other name from AirMusic, go to

Conﬁguration and DLNA setup to make the change.

Bluetooth

1. The radio can receive and play music streamed by other Bluetooth

device.

Choose Bluetooth mode on the radio, it will be discoverable on other

Bluetooth devices.

2. Turn on Bluetooth on your device and look up the device named “WR-

210” from the list. Select it to start pairing.

3. If the connection is successful, it will show “Connected” on your

Bluetooth device list.

4. You can start playing music from your Bluetooth device now.

Media Center

UPnP (Universal Plug and Play)

You can stream music from the Networked device which supports UPnP

function to the radio to play.

For instance, most of the latest computer laptop supports UPnP, and you

can stream music from Windows Media Player application on the

computer and listen on your radio.

Please make sure your computer laptop is on the same Wi-Fi

network as the Radio before you start using this function

1. If your PC is running Microsoft Windows XP, then you can use Windows

Media Player 11(WMP11) to act as your UPnP (Universal Plug and Play)

media server. (For Windows 7 or above, please download the correspond

version of Windows Media Player). The latest Windows Media Player may

be downloaded from Microsoft’s website and install by following the

instructions detailed in its installation wizard.

‒ 7 ‒

2. Once installed, Windows Media Player will create a library from all the

media ﬁles available to it on your PC.

2.1 Windows XP / Windows Media 11

2.1.1 To add new media ﬁles to the library, select’ File > Add to

Library…> Advanced Options’, Click ‘Add’ and choose the ﬁles

you wish to add and click’ OK’.

2.1.2 Now you need to connect your Internet radio to Windows Media

Player 11 and conﬁgure it to allow the radio to access your

media library. In order to this, you will need to do the following:

a. On the radio, go to the main menu and select <Media Centre>

<UPnP>.

b. It will scan for all available UPnP servers. Note, this may take a

few seconds for the radio to complete its scan and before the scan

has completed, the radio will display ‘[Empty]’. The radio will

continue to display ‘[Empty]’ if no UPnP servers and found.

c. After a successful scan. Select your UPnP server, by rotating the

dial if there is more than one UPnP server, and then press

SELECT.

2.1.3 Your PC will now prompt you that a device has attempted to

connect to your UPnP server. In order to allow the radio to have

access to the media ﬁles, you will need to click the ‘Library’ tab

from Windows Media Player 11 and select the <Media

Sharing> item to open the ‘Media Sharing’ window.

Selecting ‘Media Sharing…’ for Windows Media Player11:

2.1.4 From the ‘Media Sharing’ windows, the radio will be listed as an

unknown device. Click on the unknown device listed, then click

the ‘Allow’ button and then click ‘OK’. Allowing the Radio to

Connect:

‒ 8 ‒

2.2 Windows 7 / Windows Media Player 12

2.2.1 If you are using WMP 12, simply go to <File> and choose

<Open> to retrieve the music ﬁles you would like to add to

library.

2.2.2 Windows 7 or above requires the PC to be set as Home

network and also with the Homegroup enabled to allow

devices to access/ play the media ﬁles on your Windows Media

Player. Please ﬁnd the steps below:

I) Go to <Control Panel>, select <Network and Internet>

ii) Choose <HomeGroup>

‒ 9 ‒

Other manuals for WR-210CB

Table of contents

Other Ocean Digital Radio manuals

Ocean Digital

Ocean Digital DK-336 User manual

Ocean Digital

Ocean Digital WR-210CB User manual

Ocean Digital

Ocean Digital WR-03 User manual

Ocean Digital

Ocean Digital WR-230 User manual

Ocean Digital

Ocean Digital DB-220B User manual

Ocean Digital

Ocean Digital WR-330D User manual

Ocean Digital

Ocean Digital WR-280 User manual

Ocean Digital

Ocean Digital WR-390 User manual

Ocean Digital

Ocean Digital WR-800F User manual

Ocean Digital

Ocean Digital WR-336N User manual

Ocean Digital

Ocean Digital WR-238 User manual

Ocean Digital

Ocean Digital WR-336F User manual

Ocean Digital

Ocean Digital WR-230 User manual

Ocean Digital

Ocean Digital WR-23F User manual

Ocean Digital

Ocean Digital WR-210N User manual

Ocean Digital

Ocean Digital WR-238CD User manual

Ocean Digital

Ocean Digital WR-100F User manual

Ocean Digital

Ocean Digital wr-282cd User manual

Ocean Digital

Ocean Digital WR-202 User manual

Ocean Digital

Ocean Digital DBA-01C8 User manual

Ocean Digital

Ocean Digital WR-828F User manual

Ocean Digital

Ocean Digital WR-282 User manual

Ocean Digital

Ocean Digital WR-60 User manual

Ocean Digital

Ocean Digital DB-230B User manual

Popular Radio manuals by other brands

EisSound

EisSound KBSound iSelect user manual

Midland

Midland 1001LWX owner's manual

Konig

Konig HAV-SR41 manual

Roberts

Roberts exprssion manual

VDigi

VDigi DD3.0 Operation manual

Radio Shack

Radio Shack 21-1863 owner's manual

Roberts

Roberts Stream 207 instruction manual

Sony

Sony Walkman SRF-M97 Service manual

Stanley

Stanley FatMax FMC770 manual

auna

auna DAB-Radio 10026947 manual

SOUNDMASTER

SOUNDMASTER UR190 instruction manual

HYT

HYT TC-320 user manual

auna multimedia

auna multimedia Yellowstone 10026851 instructions

B-Tech

B-Tech GMRS-V2 manual

Weierwei

Weierwei VEV-V8 user manual

SOUNDMASTER

SOUNDMASTER DAB750 instruction manual

Telefunken

Telefunken TF-1505 instruction manual

Makita

Makita LXRM03 instruction manual
