Nokia N95-4 Specification sheet

Get started

Nokia N95-4

9207276, Issue 1 EN

Keys and parts (front)

Model number: Nokia N95-4.

Hereinafter referred to as Nokia N95 8GB.

1Power key

2Selection keys to select commands and access Options

3Menu key to access the main menu

4Call key

5Edit key to open a list of commands when you

edit text

6Scroll key to move around the menus and to

select items

7Numeric keypad

8Clear key

9End key

10 Multimedia key to access the multimedia menu and

open the music player

11 Light sensor

12 Secondary camera with lower resolution

Keys and parts (landscape)

1Media keys under the 2-way slide

•Next key

•Play/pause key

•Stop key

•Previous key

2Zoom/volume key

3Review key to view the last stored image or

video clip

42-stage capture key for auto-focus, still image

capture, and video recording

When you open the media keys under the 2-way slide,

the media mode is activated and the display is shown in

landscape orientation.

Use the media keys to control music and video players.

To activate the main camera, press and hold the capture

key. To lock the focus on an object, press the capture key

halfway down. To take a picture, press the capture key down.

To activate the video mode, select in the active

toolbar. To shoot video, press the capture key down.

Keys and parts (back)

1Charger connector

2Mini-USB connector to connect to a compatible PC

3Stereo speakers with 3D sound effect

4Main camera for high resolution image capture and

video recording (up to 5 megapixel)

5Camera flash

6Nokia AV Connector (3.5 mm) for compatible headsets,

headphones, and TV-out cables, for example, the Nokia

Video Connectivity Cable

7Infrared (IR) window

Insert the (U)SIM card and battery

A USIM card is an enhanced version of the SIM card and is

supported by UMTS mobile phones.

Always switch the device off and disconnect the charger before

removing the battery.

For availability and information on using SIM card services, contact

your SIM card vendor. This may be the service provider or other vendor.

1With the back of the

device facing you, press

and hold the release

button, slide the cover,

and lift it up.

2To release the (U)SIM

card holder, lift the

holder up from the handle.

3Insert the (U)SIM card. Make sure that the contact area

on the card is facing the connectors on the device and

the bevelled corner on the card is facing the base of

the device.

4Close the holder, and lock it into place.

5Insert the battery. To secure the battery into place,

press it gently.

6Replace the cover so that the locking catches are

directed towards their slots, and slide the cover

into place.

Switch the device on

1Press and hold the power key.

2If the device asks for a (U)PIN

code or lock code, enter it, and

press the left selection key.

The factory setting for the lock

code is 12345.

Your device has internal antennas.

Note: As with any radio

transmitting device, avoid

touching an antenna unnecessarily when the

antenna is in use. For example, avoid touching the

cellular antenna during a phone call. Contact with a

transmitting or receiving antenna affects the quality

of the radio communication, may cause the device to

operate at a higher power level than otherwise

needed, and may reduce the battery life.

1Cellular antenna

2Bluetooth

technology/wireless

LAN antenna

3GPS receiver

Charge the battery

1Connect a compatible

charger to a wall outlet.

2Connect the power cord

to the device. If the

battery is completely

discharged, it may take a

while before the charging

indicator starts scrolling.

3When the battery is fully

charged, the charging indicator stops scrolling.

Disconnect the charger from the device, then from

the wall outlet.

Tip: Disconnect the charger from the wall outlet

when the charger is not in use. A charger that is

connected to the outlet consumes power even

when it is not connected to the device.

Transfer content

Transfer personal content from

another Nokia device

With the Switch application, you can transfer content,

such as contacts, between two compatible Nokia devices

using Bluetooth connectivity or infrared. To transfer data

to your Nokia N95 8GB, press , and select Tools >

Utilities > Switch.

Transfer content from PC

You can use your device with a variety of compatible PC

connectivity and data communications applications. You

can, for example, transfer music, images, and videos

between your device and a compatible PC by using a

compatible USB data cable, Bluetooth connectivity, or

Nokia Nseries PC Suite installed on your compatible PC.

Always create the connection from the PC to synchronise

with your device.

Support

Help

The help function provides instructions when using the

applications in the device. To access it from an application,

select Options > Help.

User guide

Refer to the user guide for other important information

about your device.

Online

Check www.nseries.com/support or your local Nokia

website for the latest guides, additional information,

downloads, and services related to your Nokia product.

Tip: You can also access the support pages from the

web browser in your device.

Keypad lock (keyguard)

When the keys are locked, is displayed.

To lock the keys, press the left selection key, then the right

selection key.

To unlock the keys, open the 2-way slide, or press the left

selection key, then the right selection key.

To have the keypad lock activated automatically after a

time-out or when the 2-way slide is closed, press , and

select Tools > Settings > General > Security > Phone

and SIM card.

Tip: If you want to close the 2-way slide without

activating the keypad lock, press any key after you

close the slide.

When the keypad lock is on, calls may be possible to the

official emergency number programmed into your device.

Shortcuts

•To switch between open applications,

press and hold .

•To open Music player, press and hold the

multimedia key.

•In many applications, to view the most

used option items, press the scroll key.

•To open Gallery, press once.

•To call your voice mailbox (network service), press and

hold .

•To open the multimedia menu, press the multimedia key.

•To change the profile, press the power key, and select

a profile.

•To switch between Normal and Silent profiles, press

and hold . If you have two phone lines (network

service), this action switches between the two lines.

•To open the last dialed numbers list, press the call key.

•To use voice commands, press and hold the right

selection key.

•To start the Web browser (network service), press and

hold .

Personalization

In the personalization menu, you can change several settings

in your device. Press , and select Tools > Settings >

General > Personalization and from the following:

•Themes — to change the theme, wallpaper and power

saver settings

•Display > Light time-out — to adjust the

backlight timeout

•Display > Font size — to

adjust the size of the text

and icons on the display

•Standby mode > Active

standby — to switch the

active standby on or off.

The active standby

display shows application

shortcuts and events

from applications.

•Standby mode > Shortcuts — to assign a shortcut to

the selection keys in the standby mode

•Standby mode > Active standby apps. — to change

the default shortcut icons in the active standby mode.

Some shortcuts may be fixed, and you cannot

change them.

There are also other items you can modify:

•To modify a profile, press , and select Tools > Profiles >

Options > Customize. You can, for example, customise

the ringing tones and message alert tones.

•To change the clock shown in the standby mode, press

, and select Applications > Clock > Options >

Settings > Clock type.

Nokia Video Center

With Nokia Video Center (network service), you can

download and stream video clips over the air from

compatible internet video services.

Nokia Video Center supports files with extensions such as

.3gp, .mp4, or .rm.

To connect to the internet to browse available services that

you can add to Nokia Video Center, select Add new services.

To find and view videos, do the following:

1Press , and select

Video center.

2To connect to a service,

select the desired

video service.

3Some video clips can be

streamed over the air,

but others must be first

downloaded to your

device. To download

a video clip, select

Options > Download.

The downloaded videos are saved in Video center >

My Videos.

You can also transfer your own videos to Nokia Video

Center and view them in My Videos.

Tip: To convert video files into mobile format, use

Nokia Video Manager in Nokia Nseries PC Suite.

1To view your device on your compatible PC as a mass

memory device, make the connection with a

compatible USB cable.

2Select Data transfer as the connection mode.

3Select the videos you want to copy from your PC.

4Transfer the videos to E:\My Videos in the mass

memory of your device.

Video files in other folders of your device are not displayed

in My Videos.
