Niles StageFront IW2650LCR User manual

IW2650LCR

Professional Quality, In-Wall,

Left/Center/Right Channel Loudspeaker

D a t a S h e e t

Features

■ Dual 6.5" Injection-molded TCC™ (Talc, Carbon, and Ceramic-filled) cone woofers are

extremely rigid to reduce breakup, lower distortion and provide enhanced bass response

■ 1" fluid-cooled Teteron® dome tweeter delivers ultra-wide dispersion and silky-smooth high-

frequency response

■ Cross-braced ported cabinet with integrated frame design fits standard 2X4 construction

and is easily retrofitted

■ Gold plated input terminals accept 12 gauge wire and ensure positive connections

■ Epoxy-coated MicroPerf™ grille provides an elegant yet unobtrusive appearance

Specifications

■ Frequency Response: 70Hz to 20kHz +/-3dB

■ Sensitivity: 89dB (2.83V@1 meter)

■ Hole Cutout Dimensions: 19 7/8 inches X 9 3/8 inches

■ Depth from Front of wall: 3 7/8 inches

■ Recommended Amplifier Power: 15 to 125 Watts

■ Impedance: 6 ohm nominal; 3.2 ohm minimum

Warranty: Five-year limited

In-wall Left/Center/Right

Channel Loudspeaker

IW2650LCR

Stock Number

FG01329

Loudspeaker Dimensions

IW2650LCR









































NILES AUDIO CORPORATION 12331 SW 130 Street, Miami, FL 33186 1-800-BUY-HIFI – www.nilesaudio.com

©2006 Niles Audio Corporation. All Rights Reserved. Niles and the Niles logo are registered trademarks of Niles Audio Corporation.

Stagefront Home Theater Solutions is a trademark of Niles Audio Corporation. All other trademarks are the properties of their respective owners. CS0035A

FRONT SIDE

BOTTOM
