WWW.SZNEO.COM IPCAM User Manual
Page 5
●2.3 Wireless network settings
Tick in the " wireless LAN " behind . You want to connect to and select SSID , the input
selection SSID password , as shown below:
●2.4 DDNS settings
ipcam(DDNS built-in）no need settings
Select service providers: Please select a server of the service provider, such as：
dyndns.org、3322.org、9299.org
Application domain address: Fill in the user application domain address, as shown
below:(ooo01.3322.org)
User name and password: fill in the the DDNS account number and password, if you use
the ipcam domain name, you can find the username and password in the camera tab:
DDNS account and password.
Extranet landing camera simply in the browser address bar and transportation equipment
DDNS domain name address plus port number of the camera you can access the IP
camera !
3. Installation plug-and-play software
●Install the plug and play software DeviceClient ,After installed, the icon will display
on the screen, click to open it to view. Click ”Devices list” , Double-click search
camera ID Online to add LAN camera in the pop-up box click "Open search interface
Shenzhen NEO Electronics Co., Ltd
Tel: 86 755 29642263、29642252、29642256、29642259 Fax: 86 755 29667746
1.Click the Seanch button
2 . Selected list router
3.Enter the key
