Nauticam NA-GH4 User manual

Thank you for your purchase of a NAUTICAM camera housing.

At NAUTICAM, we pride ourselves on the a ility to recognise the

requirements of professional as well as amateur underwater

photographers and fulfill them through the innovative designs of our

products. We strive to achieve a high level of user-friendliness y

allowing stress-free installation and easy operation of all important

functions of the camera.

Each housing is individually inspected and water pressure tested to

ensure optimum quality.

Please read this manual carefully efore using the housing, this will

maximise its performance as well as its lifetime.

1. All NAUTICAM Products are warranted against any material and

manufacturing defects for one year from the date of purchase for

consumer use.

2. NAUTICAM accepts no lia ility for any damage to and defects in the

housing caused y improper use and/or poor maintenance; it is the

responsi ility of the owner to carefully follow the instructions in

this manual.

3. NAUTICAM does not hold responsi ility for damage, of any nature,

to any equipment used with and/or placed within the housing.

4. NAUTICAM accepts no lia ility for any loss of captured images or

the ina ility to capture images even if it is due to the

malfunctioning or leakage of the housing.

5. This warranty only applies to products purchased from authorised

NAUTICAM dealers and does not extend eyond the original retail

purchaser.

6. Unauthorised modifications and/or repairs of the housing will

automatically invalidate this warranty.

7. To return products for service, please contact our regional

distri utor, normally you would need to notify them y email first

and ship them the product y registered mail, along with your

contact details and a rief description of the defect.

1. NA-GH4 housing

2. Instruction manual

3. Spare silicone ru er housing o-ring

4. O-ring remover

5. CR2450 attery (for moisture alarm)

6. Lu ricant

7. Set of Allen keys

Spare silicone ru er o-ring

Lu ricant Set of Allen keys

CR2450 attery

O-ring remover

1. A water-tight test without the camera inside the housing is highly

recommended when using the system for the first time and after

the changing of port and O-ring(s).

2. Do not use lu ricants from other rands with the silicone ru er O-

ring on this housing, only use the lu ricant provided y NAUTICAM.

3. Discontinue use immediately should you notice any leakage.

4. Store the housing in a ro ust, shock-proof container during

transportation; avoid transporting with any equipment, such as a

camera, inside the housing.

5. When travelling y air, do not close the housing if the port is

installed, as this may lead to a pressure difference etween the

atmosphere and inside the housing.

6. Care must e taken when opening the housing, as pressure may

uild up inside the housing which increases the opening force.

7. Do not open the product in a wet or sandy environment. Protect

the interior from moisture and de ris in order to prevent

malfunction or leakage.

8. Do not store the product in an environment of high humidity.

9. Do not leave the housing and the camera in direct sunlight for

prolonged periods.

10. Keep out of reach of children, failure to do so could result in injury.

11. Defective products should e shipped to our distri utors for service,

unauthorized disassem ling and/or modifications could result in

malfunction or leakage.

Specifications 6

Identification of Parts 7

Preparation of the Housing 11

Opening and Locking the Housing 14

Installing the Camera 15

ounting the Port 17

Care and aintenance 19

Optional Accessories 20

Construction

Housing ody: Aluminium alloy

Surface treatment: Hard anodised

Display window: A rasion resistant polycar onate

Dimensions

(with handles)

Width: 318mm

Height: 171mm

Depth: 121mm

Weight Approx. 2.08kg (without camera)

Buoyancy Slightly negative

Depth rating 100 metres

Features

Moisture alarm: Blinking LED and audi le alarm

TTL capa ility:

Optical fi re mount included for

external stro es connection,

utilising the camera’s pop-up flash

as trigger.

Port mount: Patented easy port installation

system.

Front dial:

Ergonomically placed elow the

shutter lever, it can e comforta ly

controlled y the middle or ring

finger.

AEL/AFL lever: Easily reached e right thum .

Handles: Tilted for etter ergonomics.

1/4"-20UNC

top & ottom of

housing:

Maximum versatility for tripod and

shoulder support mounting

options.

1 Ball joint x2 5 Lens release utton

2 Adjusta le handle x2 6 1/4”–20UNC tripod socket x 3*

3 Optical fi re mount 7 M5 threaded hole x2

4 Port alignment index

* The maximum length of screws that can e

used with the tripod sockets is 4mm

8 1/4”–20UNC threaded hole x2 13 Port release safety utton

9 Accessory coldshoe 14 Port lock/release lever

10 Flash up/off lever 15 Drive mode dial

11 M16 accessory port 16 Flash open utton

12 Zoom/Focus kno 17 M5 threaded hole

18 Mode dial lock utton 26 Fn1 utton

19 On/off lever 27 Exposure compensation utton

20 M14 accessory port 28 M10 stro e mounting ase

21 Rear dial 29 M5 threaded hole

22 AEL/AFL lever 30 Shutter release lever

23 Housing lock safety utton 31 Front dial

24 Housing lock 32 WB lever

25 Mode dial
