Nauticam NA-D7200 User manual
0
1
Thank you for your purchase of a NAUTICAM digital camera housing.
At NAUTICAM, we pride ourselves in the a ility to recognise the requirements of
professional as well as amateur underwater photographers and fulfill them
through the innovative designs of our products. We strive to achieve a high level
of user-friendliness y allowing stress-free installation and easy operation of all
important functions of the camera.
Each housing is individually inspected and water pressure tested to ensure
optimum quality.
Please read this manual carefully efore using the housing, this will maximise its
performance as well as its lifetime.
2
1.
All NAUTICAM Products are warranted against any material and
manufacturing defects for two years from the date of purchase for consumer
use. Please fill in the warranty cards shipped with our housings and
viewfinders at the time of sale and return them to your point of purchase
within a month. If we do not receive the completed warranty card for a
particular product, the warranty period would e assumed to egin from the
day that the product is shipped from our facility. This warranty only applies to
products purchased from authorised NAUTICAM dealers and does not extend
eyond the original retail purchaser.
2.
To return your product for service, please contact your regional authorized
service centre(s). Please note that this warranty only applies when the
product is purchased in the territory where the service centre is located.
3.
NAUTICAM accepts no lia ility for any damage to and defects in the housing
caused y improper use and/or poor maintenance; it is the responsi ility of
the owner to carefully follow the instructions in our manuals.
4.
NAUTICAM does not hold responsi ility for damage, of any nature, to any
equipment used with and/or placed within our products.
5.
NAUTICAM accepts no lia ility for any loss of captured images or the ina ility
to capture images even if it is due to the malfunctioning of our products.
6.
Unauthorised modifications and/or repairs of our products will automatically
invalidate the warranty.
3
1. NA-D7200 housing
2. Instruction manual
3. Spare silicone ru er main o-ring
4. O-ring remover
5. CR2032 attery (for moisture alarm)
6. Lu ricant
7. Set of Allen keys
8. M10 plastic plug removal tool (for removal of M10 plastic insert)
Spare silicone ru er o-ring
Lu ricant M10 plastic plug removal
tool
CR2032 attery
O-ring remover
4
1. A water-tight test without the camera inside the housing is highly
recommended when using the system for the first time and after the changing
of port and O-ring(s).
2. Do not use lu ricants from other rands with the silicone ru er O-ring on this
housing, only use the lu ricant provided y NAUTICAM.
3. Discontinue use immediately should you notice any leakage.
4. Store the housing in a ro ust, shock-proof container during transportation;
avoid transporting with any equipment, such as a camera, inside the housing.
5. When travelling y air, do not close the housing if the port is installed, as this
may lead to a pressure difference etween the atmosphere and inside the
housing.
6. Care must e taken when opening the housing, as pressure may uild up inside
the housing which increases the opening force.
7. Do not open the product in a wet or sandy environment. Protect the interior
from moisture and de ris in order to prevent malfunction or leakage.
8. Do not store the product in an environment of high humidity.
9. Do not leave the housing and the camera in direct sunlight for prolonged
periods.
10. Keep out of reach of children, failure to do so could result in injury.
11. Defective products should e shipped to our distri utors for service,
unauthorized disassem ling and/or modifications could result in malfunction
or leakage.
5
Specifications 6
Identification of Parts 7
Opening and Closing the Housing 11
Preparation of the Housing 12
Installing the Camera 17
Mounting the Port 19
Changing the Vie finder 21
Care and Maintenance 22
6
Construction
Housing ody: Aluminium alloy
Surface treatment: Hard anodised
Display window: A rasion resistant polycar onate
Grip handles: Polycar onate and ru er
Dimensions
(with handles)
Width: 343 mm
Height: 186 mm
Depth: 132 mm
Weight 2.74kg (without all mounts)
Buoyancy Slightly negative
Depth rating 100 metres
Features
Moisture alarm: Blinking LED and audi le alarm
Viewfinder: 0.66X viewfinder
TTL capa ility:
Nikonos 5-pin ulkheads (optional)
2 optical ulkheads utilising on camera
pop-up flash as commmander
Port mount: Patented port locking lever for easy port
installation.
Multi selector: Allows diagonal movement in addition to
the up/ down/ left/ right functions.
ISO sensitivity
lever:
Allows easy ISO adjustments from the left
handle.
Fn key lever: Allows easy access from the right handle.
7
1 On/Off control kno 4 Optical ulkhead for stro e
connections x 2
2 Grip handle x 2 5 Port alignment index
3 Port lock/release lever
1
3
2
5
4
2
8
6 M16 accessory port 12 Mode utton
7 Main command dial 13 M14 accessory port
8 Movie record lever 14 M10 plastic plug (M5 on top, M10
on housing)
9 AF-ON lever 15 Shutter release lever
10 Exposure compensation lever 16 Su -command dial
11 Info lever 17 Fn lever
6
13
7
8
9
11
10
14
15
16
17
12
9
19 Delete utton 28 Housing lock (R)
20 Menu utton 29 Housing lock safety utton (R)
21 Help/ Protect/ White alance
utton 30 Live view selector lever
22 Housing lock (L) 31 Multi selector
23 Housing lock safety utton (L) 32 Up selection utton
24 Play ack zoom in/ Image quality
utton 33 Left selection utton
25 i utton 34 OK utton
26 Moisture alarm window 35 Right selection utton
27 LV utton 36 Down selection utton
27
28
29
30
32
33
34
35
36
31
20
24
22
23
25
19
26
21
