PREMIER P5-a

ELECTRIC ENGINE

OPERATING INSTRUCTIONS

This Premier P5-a Electric engine has a Die Cast body and operates on any O-42 track

system. This Premier Diesel Engine contains state-of-the-art electronics with many

built-in automatic features for incredibly realistic operation. Despite these advanced

features, the locomotive is easy to operate with any compatible standard AC transformer

that is equipped with whistle and bell buttons (see the compatibility chart on page 18),

and is compatible with most other 3-rail locomotives, rolling stock, and accessories.

This locomotive is equipped with Proto-Sound 2.0 with Digital Command System

(DCS). This new system will allow you to operate your locomotive in Command mode

(when used with the DCS Remote Control System, sold separately) or Conventional

mode. Conventional operating features are described in the following pages, while the

DCS operating features are covered in the set of operating instructions that

accompanies the DCS equipment. Conventional Mode operation of this locomotive is

much simpler than operation of original Proto-Sound engines. For your own safety and

that of your equipment, please read the instructions before you operate this engine.

Premier P5-a Electric Engine

Table of Contents

Set Up 3

Basic Operation 4

Transformer Controls 4

Throttle 4

Volume Control 4

Proto-Sound 2.0 Operation 5

Activating Proto-Sound 2.0 Conventional Mode Features 5

Passenger Station Announcements (PSA) 6

Tips on Using PSA 7

Proto-Coupler®Operation 8

Speed Control 8

Lock into a Direction State 9

Reset to Factory Defaults 9

Automatic Sounds 9

Maintenance 10

Lubrication and Greasing Instructions 10

Locomotive Traction Tire Replacement 12

Locomotive Light Bulb Replacement 13

Self-Charging Battery Back-Up 14

Troubleshooting 15

Compatibility 17

Transformer Compatibility Chart 18

Additional Features with DCS Remote Control System 19

Safety Precautions 21

Service and Warranty Information 24

Premier P5-a Electric Engine

Set Up

Although the engine was lubricated at the factory, it is important that you

lubricate the chassis before operation. Lightly grease the outside idler and

drive gears (marked “G” in Fig. 6 on page 11) to prevent them from squeaking.

Use light household oil and follow the lubrication points marked “L” in Fig. 5

on pg. 10. Do not over-oil. Use only a drop or two on each pivot point.

At this point, you are ready to put your engine on the track and begin running

it.

Premier P5-a Electric Engine

Throttle – Throttle up the power to your track. Give about 10-14 volts or

enough power so that the engine’s headlight shines brightly. Then put the

engine into motion by either firmly pressing the Direction button on your

transformer or remote once or dropping and advancing the throttle to put the

engine in forward.

Operation Buttons

Use the operation buttons on your transformer or remote as described below.

Horn/Whistle - To sound the horn, firmly press the Horn/Whistle button. The

horn will sound for as long as you continue to depress the button. It will stop

when you release the button. The horn has four different endings, depending on

whether you hold the button for less than three seconds, three seconds, four

seconds, or five seconds or longer.

Bell - To sound the bell, firmly press and release the Bell button. To turn the

bell off, press and release the Bell button again. The bell will continue to ring

from the time you turn it on until you press and release the button again to turn

it off.

Direction – Your train is programmed to start in neutral. The first direction

after neutral upon start-up is forward. Firmly press and release the Direction

button to allow the engine to move forward. Just as you must stop your

automobile between forward and reverse, this engine will not go directly from

forward to reverse; it goes into neutral between directions. If the train has been

moving forward, the first press of the Direction button will put the train from

forward into neutral, the second press into reverse, the third press back into

neutral, and the fourth back into forward. To prevent accidental high-speed

start-ups, this engine is programmed to restart in neutral each time the track

voltage is turned off for 25 seconds or more.

Volume Control –To adjust the volume of all sounds made by this engine,

turn the master volume control knob located under the engine clockwise to

increase the volume and counter-clockwise to decrease the volume (see Fig. 1).

Proto-Sound 2.0

Volume Adjustment Knob

Figure 1. Proto-Sound 2.0 Volume Adjustment Knob

Premier P5-a Electric Engine

Proto-Sound 2.0 Operating Instructions

This manual contains the operating instructions for Proto-Sound 2.0 in

conventional mode only. Instructions for accessing DCS command mode

features accompany the DCS Remote Control System equipment.

Because Proto-Sound 2.0 is an all-new system developed by M.T.H.’s own

research and development team, it operates differently from original

Proto-Sound. Most Proto-Sound 2.0 features are automatically enabled, and

the reset state has been eliminated, so there is no need to program features as

with original Proto-Sound. Although the new system is easier to operate than

original Proto-Sound, you should read these instructions thoroughly before

using Proto-Sound 2.0 features in order to prevent harm to yourself or your

equipment.

Activating Proto-Sound 2.0 Conventional Mode Features:

Proto-Sound 2.0 features are activated by sequences of Bell and Whistle

button pushes described below. Please read the full descriptions of each

feature before using it. To use these buttons to activate features rather than to

blow the whistle or ring the bell, you should press the buttons for a shorter

time (1/2 second); you may need to practice your timing to make this work

smoothly.

Feature to Be Activated:

PassengerStationAnnouncements

Fire the Rear Coupler

Fire the Front Coupler

Speed Control On/Off

Lock into a Direction/Unlock

Reset to Factory Defaults

Button Code:

1 Bell, 2 Whistles

1 Bell, 3 Whistles

1 Bell, 4 Whistles

1 Whistle, 2 Bells (from Neutral only)

1 Whistle, 3 Bells

1 Whistle, 5 Bells (from Neutral only)

Premier P5-a Electric Engine

Passenger Station Announcements (PSA):

Your engine is equipped with a sound package of passenger station

announcements that you can play when you pull into a passenger station.

Each sequence described below will play as long as it is left on, randomly

generating sounds, but be sure to allow approximately 30 seconds between

the button pushes described below to allow the PSA sufficient time to run

through each sequence.

1. To cue the sound system to play the PSA, quickly but firmly press the Bell

button once followed by 2 quick but firm presses of the Whistle button while

the engine is moving. As soon as you have keyed in this code, you will hear

the announcement for the upcoming stop and the bell will begin to ring.

2. Press the Direction button or drop and advance the throttle once to stop the

engine. This will trigger the first sequence of PSA. The reverse unit is

temporarily disabled so that the train will not move as you use the Direction

button to trigger the sounds, and Proto-Sound 2.0 has disabled operator control

over the Whistle and Bell buttons until the full PSA sequence is complete.

3. After waiting about 30 seconds for that sequence to run, press the Direction

button again to trigger the second sequence of PSA.

4. After about 30 seconds, press the Direction button again to trigger the third

PSA sequence.

5. Again, after allowing about 30 seconds for that sequence to run, press the

Direction button one more time to trigger the fourth and final PSA sequence.

You will know it is the final sequence when you hear the “All Aboard!” call.

The bell will begin to chime and within a few seconds, the engine will start and

move out on its own at the current throttle setting, in the same direction it was

traveling when you began the sequence. Once the bell turns off, the operator

regains control of the transformer’s bell and whistle buttons and can ring the

bell or blow the whistle as usual.

Premier P5-a Electric Engine

Tips on Using PSA

• You can terminate PSA at anytime by turning off power to the

track for 15 seconds.

• You do not have to be in Forward to use PSA. At the conclusion

of the full sequence, the train will pull away from the station in

whatever direction you were going when you activated the feature.

• You can use PSA even if you are double-heading with another

engine. If the second engine is not equipped with PSA at all, you

must remember not to leave the throttle at a high voltage level once

you have stopped the engine to run the PSA. Otherwise, the engine

without PSA will begin vibrating on the track as its motors strain to

move the train, since they cannot be automatically disabled during

the PSA cycle. If the second engine is an original Proto-Sound

engine equipped with PSA, you may choose to disable it when

used in double-heading operations, so you will not experience

competing PSA sounds. To disable PSA in an original

Proto-Sound engine, see the operating instructions for that engine.

• PSA can be triggered from Neutral. It will operate the same as if

triggered while in motion except that, at the conclusion of the PSA,

the engine will depart in the next direction of travel, as opposed to

the direction it was traveling before entering Neutral.

Premier P5-a Electric Engine

Proto-Coupler®Operation

This locomotive is equipped with two coil-wound Proto-Couplers for remote

uncoupling action. Because the Proto-Coupler is controlled through the

Proto-Sound 2.0 microprocessor, it does not require an uncoupling track

section or modification to your layout to function. You can fire the coupler(s)

from neutral or while in motion. Use the codes shown below (and in the chart

on pg. 5) to fire the coupler(s).

Rear Coupler:

To fire the rear coupler, press the Bell button once followed immediately by

three pushes of the Whistle button. The sound of the liftbar and air line

depletion will play, and the knuckle will be released.

Front Coupler:

To fire the front coupler, press the Bell button once followed immediately by

four pushes of the Whistle button. The sound of the liftbar and air line

depletion will play, and the knuckle will be released.

Speed Control:

M.T.H. engines equipped with Proto-Sound 2.0 have speed control capabilities

that allow the engine to maintain a constant speed up and down grades and

around curves, much like an automobile cruise control. You can add or drop

cars on the run, and the engine will maintain the speed you set.

While the engine is programmed to start with the speed control feature

activated, you can opt to turn it off. This means the engine’s speed will fall as

it labors up a hill and increase as it travels downward. It is also affected by the

addition or releasing of cars while on the run. To maintain a constant speed

when speed control is turned off, you need to adjust track voltage yourself.

When speed control is off, the volume will drop to allow for better low voltage

operation. Full volume is restored upon reactivation of speed control.

To turn speed control on and off, put the engine in neutral, then press the

transformer’s Whistle button one time then immediately press the Bell button

two times. Two horn blasts will indicate that the engine has made the change.

Repeat the 1 whistle, 2 bells code to return it to the other state. You will want

to do this during the initial neutral upon start-up if you ever couple this

engine to another engine that is not equipped with speed control to avoid

damaging the motors in either engine. Each time you shut down the engine

completely, it will automatically turn speed control on.

Premier P5-a Electric Engine

Lock into a Directional State:

You can lock your engine into a directional state (forward, neutral, or reverse)

so that it will not change directions. To do this, put the engine into the

direction you want or into neutral, to lock it into neutral, run it at a very slow

crawl (as slowly as it will move without halting), and quickly but firmly press

your remote’s Horn button once followed immediately by three presses of the

Bell button. Two horn blasts will indicate that the engine has made the change.

The engine will not change direction (including going into neutral) until you

repeat the 1 horn, 3 bells code to return the engine to its normal state, even if

the engine is kept without power for extended periods of time.

Reset to Factory Defaults:

To override the settings you currently have assigned to the engine and reset it

to its factory defaults, while in Neutral press the Whistle button once, followed

immediately by five quick pushes of the Bell button. Two horn blasts will

indicate that the engine has made the change.

Automatic Sounds:

Certain Proto-Sound 2.0 sound effects automatically play in programmed

conventional mode conditions:

Squealing Brakes play any time the engine’s speed decreases rapidly.

Cab Chatter plays at random intervals when the engine idles in neutral.

Engine Start-up and Shut-down sounds play when the engine is initially

powered on or is powered off for five seconds or more.

Premier P5-a Electric Engine

Lubrication and Greasing Instructions

The engine should be well oiled and greased in order to run properly.

You should regularly lubricate the engine to prevent it from squeaking. Use

light household oil and follow the lubrication points marked “L” in Fig. 5. Do

not over-oil. Use only a drop or two on each pivot point.

The locomotive’s internal gearing was greased at the factory and should not

need additional grease until after 50 hours of operation or one year, whichever

comes first. Follow the greasing instructions below. Note that in some tightly

packed engines you may need to move internal components temporarily in

order to access the gears.

1. To access the gear box, remove the cab from the chassis by unscrewing the

chassis screws as seen in Figure 6 and lifting the cab from the chassis.

2. Once the cab is removed, remove the screws that hold the motor mounting

plates to the chassis. You will need a long, skinny screw driver to reach the

screws. There are 2 sets of screws on each motor (see figure 7 on pg. 11)

3. Once the motor mount screw has been removed, pull the motor away from

the truck block and lightly coat the motor worm gear and bronze drive gear (in

the truck block) with grease.

4. Reassemble the truck and motor, being careful not to pinch any wires

between the truck block and motor mount.

5. After repeating the procedure for the other motor, reassmble the chassis and

body, being careful that the wire harnesses are not caught between the chassis

and body and reinstall the chassis screws.

Lubricate Pick Up Rollers (L)

LubricateWheelAxle

Figure 5. Lubrication Points on the Locomotive

Table of contents

Other MTHTrains Toy manuals

MTHTrains

MTHTrains PCC Street Car User manual

MTHTrains

MTHTrains PREMIER GP-40 DIESEL ENGINE User manual

MTHTrains

MTHTrains Premier Alco RS-11 Road Switcher Diesel... User manual

MTHTrains

MTHTrains Premier SD40-2 Diesel Engine User manual

MTHTrains

MTHTrains HO 4-8-8-4 Big Boy Quick start guide

MTHTrains

MTHTrains Premier EF-3 Electric Engine User manual

MTHTrains

MTHTrains RAILKING ES44 User manual

MTHTrains

MTHTrains Premier BL-2 Diesel Engine User manual

MTHTrains

MTHTrains RailKing C628 Diesel Engine User manual

MTHTrains

MTHTrains PREMIER GP60M User manual

MTHTrains

MTHTrains PREMIER DC-3 User manual

MTHTrains

MTHTrains Rail King SW-1 Diesel Engine User manual

MTHTrains

MTHTrains Premier SD40-2 Diesel Engine User manual

MTHTrains

MTHTrains RAILKING McDonald's Restaurant User manual

MTHTrains

MTHTrains HO 4-6-4 Quick start guide

MTHTrains

MTHTrains RailKing SW-1500 User manual

MTHTrains

MTHTrains Tinplate 4696 User manual

MTHTrains

MTHTrains Proto-Sound 3.0 User manual

MTHTrains

MTHTrains Rail King RKS FP-45 Diesel Engine User manual

MTHTrains

MTHTrains Rail King RS-1 User manual

MTHTrains

MTHTrains Rail King 30-9054 User manual

MTHTrains

MTHTrains Premier SD35 Diesel Engine User manual

MTHTrains

MTHTrains RAILKING BLUE COMET User manual

MTHTrains

MTHTrains Center Copula Steel Caboose User manual

Popular Toy manuals by other brands

marklin

marklin 37321 instruction manual

Canon

Canon PAPER CRAFT Assembly instructions

GREAT PLANES

GREAT PLANES Pitts M-12S instruction manual

NOCH

NOCH 14261 manual

Hausler

Hausler 450 SE V2 quick start

Dynaflite

Dynaflite Daydream instruction manual

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Build instructions

Kenner

Kenner Batman 63651 instructions

LEGO

LEGO 8527 instructions

iKarus

iKarus ECO 8 Assembly instruction

Multiplex

Multiplex EasyStar II Building instructions

Walkera

Walkera 38 User handbook

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE manual

MD MXION SWD user manual

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway instructions

marklin

marklin 39671 user manual

Meccano

Meccano 15103 instructions

LEGO

LEGO TECHNIC 8735 instructions
