LIMITED ONE YEAR WARRANTY

This item is warranted for one year from the date of purchase

against defects in material or workmanship. We will repair or

replace (at our option) the defective part without charge for parts

or labor, if the item is returned to the address below within one

year of the original date of purchase. This warranty does not

cover items that have been abused or damaged by careless

handling. Transportation costs incurred by the customer are not

covered under this warranty.

This warranty gives you specific legal rights and you may have

other rights which vary from state to state.

M.T.H. Electric Trains, Inc. • 7020 Columbia Gateway Drive • Columbia, MD 21046-1532

The Premier N-8 Caboose offers a new level of

excitement and realism for your O Gauge

model railroad. Constructed from sturdy ABS

plastic, the N-8 Caboose was created from

quality components and has been designed for

years of operation.

The Premier N-8 Caboose comes fully

assembled, decorated and ready for use right

out of the box. The N-8 Caboose features an

illuminated interior and exterior marker lights,

controlled from track power. Use and operation

is made easy by following the instructions on

the following pages.

ELECTRIC TRAINS, INC.

Caboose

N-8

Turn the caboose

upside down and

unplug the red LED's

from underneath the

interior.

There will be two

spots of hot glue

holding the LEDs in

place. Use a screw

driver to loosen the

wires from the spots

of glue. Pull the LEDs

back towards the

inside of the shell to

remove them.

Replace the LEDs

with a new set and

use hot glue to put the

wires back in place.

Plug the wires back

into the connector

under the interior.

Reassemble.

STEP

INSTRUCTIONS To replace the interior light bulbs, follow these steps. 1) To remove the shell from the chassis, remove the four mounting

screws located underneath the trucks. 2) With the four screws removed, lower the chassis from the shell, take care not to

pull the wires out. 3) To be able to separate the interior from the shell you need to remove the step platform from both ends.

In order to do this you need to loosen the end frames from the step platform. You must do this carefully so that you don't

break them. First remove the handrail from the end frame by pulling the handrail outward. Next grasp the end frame by the bottom and pivot slowly and

carefully outwards 5 With the step platforms removed you can then lower the interior from the shell (to

completely remove the body from the interior, go to Step 6 which is found on the back page). 5) You can now replace the bulbs by pushing the socket up from

the bulb holder and pull the bulb from its socket. Replace with a new one, and reverse the steps to reassemble the caboose. To replace the two red LED

lights at the end of the caboose follow steps 1- 4 and 6-7 on the back page.

°. You can then remove the step platforms. 4)

STEP

Remove these

four screws
