Motorola H375 - Headset - Over-the-ear User manual

Universal Bluetooth®

Headset H375

H375 MOTOMANUAL

Figure 2

Charging

Port

Figure 1

Figure 3

Figure 5

Figure 4

European Union Directives Conformance Statement

Hereby, Motorola Inc., declares that this H375 is in compliance

with the essential requirements and other relevant provisions of

Directive 1999/5/EC.

You can view your product’s Declaration of Conformity (DoC) to Directive

1999/5/EC (the R&TTE Directive) at www.motorola.com/rtte.

Caring for the Environment by Recycling

When you see this symbol on a Motorola product, do not dispose

the product with household waste.

Recycling Mobile Phones and Accessories

Do not dispose of mobile phones or electrical accessories, such as chargers

or headsets, with your household waste. In some countries or regions,

collection systems are set up to handle electrical and electronic waste items.

Contact your regional authorities for more details. If collection systems aren’t

available, return unwanted mobile phones or electrical accessories to any

Motorola Approved Service Centre in your region.

FCC Notice to Users

Users are not permitted to make changes or modify the device in any way.

Changes or modiﬁcations not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment. See-

47-CFR-Sec.-15.21.

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference,

and (2) this device must accept any interference received, including

interference that may cause undesired operation. See-47-CFR-Sec.-15.19(3).

English

Before you begin

See ﬁgure 1 on page 1.

Take a moment before you get started to familiarize yourself with your new

H375 Bluetooth Hands-free Headset.

1. Power button

2. Microphone

3. Call button

4. Indicator light

5. Volume buttons

6. Speaker

Charging your headset

See ﬁgure 2 on page 1.

The indicator light turns on when the battery is charging. It may take up to 30

seconds for the indicator light to turn on. When the headset’s battery is fully

charged (about 3 hours), the indicator light is steadily lit in blue

Note: Headset is NOT functional while charging.

English

Wearing your headset

See ﬁgure 3 on page 2.

Your H375 headset is supplied with both round-and-oval shaped earbuds

to provide personal choice for maximum comfort. The ear bud is ﬁtted onto

the end of your headset’s earpiece speaker, and placed onto your ear when

using your headset.

Your headset’s performance is greatly dependent upon achieving a good ﬁt

on your ear. Therefore, we recommend trying all the supplied ear buds with

your headset.

You can wear your H375 headset on your left of right ear. The headset comes

ready for the right ear.

Placing the headset on your ear: see ﬁgure 4 on page 2.

Placing the headset on the left ear: see ﬁgure 5 on page 2.

Changing volume orientation button

You can change the orientation of the volume buttons on your headset.

1. Turn the headset power off

2. Press and hold the Volume button you want to assign as the “Volume up”

button and the Power button to power on the headset. The indicator light

ﬂashes 3 times in blue.

English

Turning headset on and off

To turn your headset on, press and hold the Power button until the indicator

light ﬂashes.

To turn your headset off, press and hold the Power button until the indicator

light ﬂashes rapidly and then turns off.

Pairing your headset

Your phone’s Bluetooth feature is off by default. To use your headset, you

must turn on the Bluetooth feature in your phone. Please check your phone’s

user’s guide.

Note: The Bluetooth feature remains on until you turn the feature off.

Before you can use your headset, you must pair it with your phone.

1. Ensure headset is in pairing mode

• Power the headset on.

• After a few moments, the indicator light will be steadily lit in blue to

indicate headset is in pairing mode.

If the headset does not enter into pairing mode, see “Troubleshooting”

section.

2. Set your phone to look for your headset

• Perform a device discovery from the phone. For details about device

discovery, consult your phone’s user’s guide. The phone lists Bluetooth

devices it ﬁnds.

• Select Motorola H375 in the list of discovered devices and conﬁrm by

following the on-screen prompts.

• When prompted by the phone, enter the passkey 0000 and conﬁrm.

Pairing is successful when the headset indicator ﬂashes purple and blue.

English

Test and use

Your phone and headset are now paired and ready to make and receive calls.

To conﬁrm they are successfully paired and operating properly, place the

headset over your ear and make a call from your phone. You will hear ringing

from the headset.

After you have successfully paired your phone and headset, you do not need

to repeat these steps each time you use the headset.

Using your headset: Making & receiving calls

Your headset supports both hands-free and headset proﬁles.

Accessing call functions depend upon which proﬁle your phone supports.

See your phone’s user’s guide for more information.

Note: Some features are phone/network dependent.

Function Action

Receive a call Tap the Call button

End a call Tap the Call button

Reject a call Press and hold either volume button until

incoming call stops ringing

Redial last call Press and hold the Call button for at least

2 seconds until you hear a beep

Make a voice dial call Tap the Call button and speak the name

after the tone

Mute or un-mute a call Tap both Volume buttons

English

Audio tones

Audio tone Headset status

Ascending tone Powering on

Descending tone Powering off

2 ascending tones Pairing successful

Ring tone Incoming call

2 short tones Volume at maximum or minimum

when pressing volume button

High/low tones repeated Low battery

every 30 seconds

No audio indications: Out of range

deteriorating quality

3 ascending tones Connected call

3 descending tones Ended call

2 rapid ascending tones Mute enabled

2 rapid descending tones Mute disabled

Indicator lights

Checking battery level

To check battery level while headset is powered on, press and hold both

Volume buttons for 5 seconds until you hear a beep. The indicator light

displays the following charge status for a few seconds.

Headset indicator Charge level

Red Below 10% charge

Purple Between 10% and 80% charge

Blue Above 80% charge

English

Charging status

With charger plugged in

Headset indicator Charge status

Red Charging (below 10% charge)

Purple Charging (above 10% charge)

Blue Charging complete

Operating status

With no charger plugged in

Headset indicator Headset status

Off Power off

3 blue ﬂashes Powering on/off

Steady blue Pairing mode

Rapid blue/purple ﬂashes Pairing/Connection successful

Quick blue ﬂash Incoming/outcoming call

Slow blue ﬂash Connected (on a call)

Standby (not on a call)

Slow red ﬂash Idle (not connected)

Slow purple ﬂash Connected (on a muted call)

Quick red ﬂash Low battery

Note: After 30 minutes on a call or of inactivity, the light stops ﬂashing to

conserve battery power, but the headset remains in standby mode.
