motorola

H700

Bluetooth®

Wireless Headset

H700

CFJN2244C – 07/2006

Figure 1

Figure 3

Figure 2

English

General and safety information

European Union Directives Conformance Statement

Hereby, Motorola declares that this product (“H700”) is in compliance with:

• The essential requirements of European Union Directive

1999/5/EC

• All other relevant EU Directives

You can view your product's Declaration of Conformity (DoC) to Directive

1999/5/EC (the R&TTE Directive) at www.motorola.com/rtte.

Caring for the Environment by Recycling

When you see this symbol on a Motorola product, do not dispose the

product with household waste.

Recycling Mobile Phones and Accessories

Do not dispose of mobile phones or electrical accessories, such as

chargers or headsets, with your household waste. In some countries or

regions, collection systems are set up to handle electrical and electronic

waste items. Contact your regional authorities for more details. If collection

systems aren’t available, return unwanted mobile phones or electrical

accessories to any Motorola Approved Service Centre in your region.

FCC Notice to Users

Users are not permitted to make changes or modify the device in any way.

Changes or modifications not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

See-47-CFR-Sec.-15.21.

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference,

and (2) this device must accept any interference received, including

interference that may cause undesired operation. See-47-CFR-Sec.-15.19(3).

English

Initial set up

Welcome to the world of Motorola digital wireless communications! We are

pleased that you have chosen the Motorola H700 Bluetooth®Hands-free

Headset.

Before you begin

Take a moment to familiarize yourself with your H700 headset.

See figure 1 on page 1.

1 Earhook

2 Volume buttons

3 Call button

4 Multicolor indicator light

5 Microphone

6 Headset boom

Charging your headset

See figure 2 on page 2.

First time use: Charge your headset for 2 hours.

Recharging: When you hear 5 rapid high tones through the headset speaker

repeated at 60-second intervals, the headset battery needs to be recharged.

Note: the headset is not functional while charging.

The rechargeable battery that powers this product must be disposed

of properly and may need to be recycled. Contact your local

recycling center for proper disposal methods. Never dispose of

batteries in fire because they may explode.

Wearing the headset

You can wear your H700 headset on your left of right ear. The headset

comes ready for the right ear.

Placing the headset on your ear: refer to figure 3 on page 2.

Placing the headset on the left ear

• Open the earhook 90°

• Detach the earhook from the hinge pin.

English

Changing volume button orientation

If you change your headset to wear it on the other ear, you can also change

the orientation of the volume buttons.

With the headset off (boom closed), press the Call button until the light

turns on. Then, press the Volume button that you would like to assign as

“volume up” button. The headset flashes twice and goes back in sleep

mode. Turn the headset on (boom opened).

Pairing your headset and phone

Your phone’s Bluetooth feature is off by default. Make sure the Bluetooth

feature is permanently turned on in your phone. Please check your phone’s

user’s guide.

Before you can use your headset, you must pair (link) it with your phone.

1. With the headset turned off (boom closed), press and hold the Call

button for 5 seconds until the indicator light turns on and remain steadily

lit in purple.

2. Release the Call button and immediately open the headset boom. The

indicator light remains lit in purple.

3. Perform a device discovery (or scan) from the phone. For details about

device discovery, consult your phone’s user’s guide. The phone lists

Bluetooth devices it finds.

4. Select Motorola H700 in the list of discovered devices and confirm by

following the on-screen prompts.

5. When prompted by the phone, enter the passkey 0000 and confirm.

When your headset successfully pairs with your phone, the indicator light

changes from steadily to flashing blue.

After you have successfully paired your phone and headset, you do not

need to repeat these steps each time you use the headset.

English

SmartFind feature

The headset goes automatically in discoverable mode when powered

on the first time or in case it can not connect to the device it has been

previously paired with. In these instances, the pairing can be done directly

on the phone without manually placing the headset in pairing mode.

Test and use

Your phone and headset are now paired and ready to make and receive

calls. To confirm they are successfully paired and operating properly, make

a call from you phone. You will hear ringing from the headset.

Paired link to additional devices

Your headset can store pairing information for up to 8 different devices

in chronological order. When an attempt to pair to more than 8 devices is

made, the oldest paired device is removed from the list.

The headset will automatically initiate a connection with the last device it

was connected to either by powering up the headset or by pressing the Call

button. If you want to connect the headset to another device in the paired

device list, you must initiate the connection from that device. Whichever of

the 8 devices initiates a connection to the headset afterwards, that device

then becomes the “last connected” device.

English

Using your headset

Turning your headset on & off

To turn your headset on, open the headset boom. The indicator flashes

blue.

To turn your headset off, close the headset boom. The indicator turns off.

Making & receiving calls

Function Action

Receive a call Open the headset boom and tap the Call button

End a call Tap the Call button

Reject a call Press and hold the Call button until you hear a

beep

Redial last call Press and hold the Call button until you hear a

beep

Make a voice dial call Tap the Call button and speak the name after

the tone

Transfer a call from the phone to the Open the headset boom

headset

Answer a second incoming call Press and hold the Call button until you hear a

Put active call on hold beep (The 1st call is placed on hold).

Toggle between two active calls Press and hold the Call button until you hear a

beep

Join a 3 way call (note: feature is Press and hold both volume buttons

phone/network dependent)

Disable the indicator light Press and hold both volume button for 5 to 6

seconds

Mute or un-mute a call Tap both Volume buttons

Your headset supports both hands-free and headset profiles. Accessing

call functions depend upon which profile your phone supports. See your

phone’s user’s guide for more information.

English

Indicator lights

The indicator light provides information about your headset status.

With the charger plugged in:

Headset indicator Headset status

Red (steady) Charging (less than 80% charged)

Yellow (steady) Charging (more than 80% charged)

Green (steady) Charging complete

With no charger plugged in:

Headset indicator Headset status

Off Power off

Purple (steady) Pairing mode

Red (steady) Battery low

Blue (10 rapid flashes) Pairing successful

Blue (Quick flash) Standby (not on a call)

Blue (Slow pulse) Connected (on a call)

Note: after 5 minutes of inactivity, the light stop flashing to conserve power,

but the headset is in standby mode. Any button press on the headset will

re-awaken the headset and the flashing resumes.

English

Audio tones

The audio tones provide information about your headset status.

Audio tone Headset status

Single high tone when pressing Volume at minimum or maximum

volume button

5 rapid high tones repeated Low battery

every 60 seconds

No audio indications: deteriorating quality Out of range

Ring tone Incoming call

Single high tone Pairing confirmation

Single low tone Voice activation

Dual high/low tone Voice tag not recognized

Single high tone End call

Low to high tone Phone network not available

2 ascending tones Mute enabled

2 descending tones Mute disabled

Troubleshooting

My phone does not find my headset: make sure the blue light on your

headset is steadily lit when you phone is searching for devices

My headset worked before but now it is not working: Make sure the

Bluetooth feature is turned on in your phone. If the Bluetooth feature has

been turned off or was turned on temporarily, you may need to restart the

Bluetooth feature and pair your phone and headset again.

If you have any additional questions, please call your hotline number

(0870-9010-555) or visit us at www.hellomoto.com.
