Motorola FX855P User manual
FX855P
Dual Band GSM Fixed Wireless Phone
USER’S GUIDE
(Back cover)
Motorola, the Stylized M Logo, and other Motorola trademarks and trade dress are owned
by Motorola, Inc. and are used under license from Motorola, Inc. MOTOROLA and the
Stylized M Logo are registered in the U.S. Patent & Trademark Office. All other
products or service names are the property of their respective owners. © Motorola, Inc.
2007. All rights reserved.
The information contained in the FX855P user guide is believed to be correct at the time
of printing. We reserve the right to change or modify any information, product
specifications, features or functionality without notice. The contents of the FX855P user
guide are provided “as is.” Certain features may not be activated by your service provider,
and/or their network settings may limit the feature’s functionality. Additionally, certain
features may require a subscription. Contact your service provider for details.
FX855P User Guide version 1.0 08/14/2007
© Copyright 2007, Motorola Inc., All rights reserved
This page is intentionally left blank
WELCOME
Congratulations on the purchase of your Motorola FX855P product!
Please retain your original dated sales receipt for your records.
For warranty service of your Motorola FX855P product, you will need to provide a copy
of your dated sales receipt to confirm warranty status.
Thank you for choosing a Motorola product.
Please read important safety instructions before use.
Read and understand all instructions before use.
Please retain this guide for future reference.
1
1. PREPARING YOUR PHONE FOR USE
Before using your phone, the phone must be setup according to the following
instructions.
1.1. Installing the coiled cord
xConnect the coiled cord to both the handset and the base.
1.2. Plugging the AC/DC adaptor
zConnect the adaptor to the AC Wall outlet.
2
1.3. Backup Battery
x
Remove the battery door.
x
Insert the rechargeable battery pack into the battery compartment.
x
Replace the battery door.
Note: The battery pack is a backup for emergencies in case of a power failure. Do
not operate the phone without having the AC/DC adaptor connected.
Be sure to carefully match the positive and negative terminals as shown on the
battery.
Caution:
x
It is prohibited to use the SIM card for this Fixed Wireless Phone in other
GSM mobile phones. Once the SIM pin number is entered, the SIM pin is
automatically changed so the initial PIN is no longer valid. Therefore, it is
highly recommended NOT to take out the SIM card once it is installed in this
product.
x
DO NOT bend or scratch your SIM card, and avoid exposing it to static
electricity, water, or dirt.
3
2. FEATURE HIGHLIGHTS
zVoice mail
zShort Message Service
zEmergency call
zCall logs
zCall restriction
zCaller ID
zClock with alarm
zCalculator
zCordless function
zBlue back light
zMultiple ring tones
zAdjustable ring tone
zProfile setting
zGraphic display
zMulti language
z100 phone book memories and 250 phone book memory additionally suppo
rted by SIM card.
zKeypad lock
zDial tone generation
zLong Message Service up to 450 characters
zAntenna bar
zBattery bar
zEar phone / microphone jack
4
3. ABOUT THE PHONE
This phone can operate in different bands (depending on the service provider). It
supports dual band (850MHz / 1900MHz or 900MHz / 1800MHz).
3.1. Part of the Phone
5
3.2. Identifiers
On your phone, you have two types of identifiers: indicators and icons. Icons are
graphic representations of a specific item or situation. For example, an icon appears
when you have a voice message waiting.
Indicators show the status of something. The phone uses three types of indicators:
zSignal strength indicator: This indicator shows the signal strength of the
wireless network at your current location. The higher the bar, the stronger
the signal.
zRinger volume indicator: When you press , the upper key once during
standby, you are able to enter the ringer volume adjustment. Scrolling up
and down using the key adjusts the ringer volume higher or lower.
The list below shows what each icon means.
Tells you the strength of the network signal.
Battery indicator
You have one or more unread text messages waiting.
The alarm has been set and is on.
6
4. BASIC OPERATIONS
4.1. Switching the phone ON and OFF
Case 1:
zTo turn the phone ON, plug the power cable into the phone.
zTo reset the phone, press and hold the key.
4.2. Making a call
Case 1:
x
Deactivate the Key guard, if it is ON.
x
Pick up the handset, and dial tone is generated.
x
Enter the phone number, including the area code, and press .( if you don't p
ress , the phone will call the number which you had input after 6 s
econd.)
.
x
Press to end the call or to cancel the call attempt. If handset is placed in
its base, call is automatically terminated.
Case 2:
xEnter the phone number with the handset on the base.
xPress . The phone enters speaker mode.
