Morel BREEZ AW600 User manual

User Manual

6.5”- 8”

Outdoor loudspeaker

BREEZ AW600

BREEZ AW800

WATERPROOF

IP66

Please note:

These weather-resistant speakers

are manufactured to resist a

variety of weather conditions with

UV paint protection, aluminum

grilles, and aluminum brace.

They are not waterproof

and cannot be submerged under

water.

1 3

Package content Installation Requires

Bracket mounting

Connecting Logo on grille

6.5”

6.5” 8”Specications

Connect the speakers to the brackets, lightly

screw the bracket knobs into the cabinet and

point the speaker towards the listening area.

Once the speaker direction is set, tighten the

bracket knobs securely.

(NOT INCLUDED)

According to the speaker

placement conguration

(horizontal/vertical), you can

rotate the logo on the grille.

Input Power

Dimension (H*W*D)

Net Weight

10-100W

285*200*195mm

3.45Kg

20-120W

381*250*250mm

5.02Kg

LF Unit

HF Driver

Impedance (AC)

Output SPL

Power handling

Freq. Range

6.5 inch *1

1 inch *1

8Ω

87dB

120W

45Hz~20Kz±3dB

8 inch *1

1 inch *1

8Ω

88dB

150W

40Hz~20Kz±3dB

8”

Using the supplied bracket, choose your location

and placement conguration and then mount the

bracket. For safety reasons, DO NOT mount the

speaker on a wall constructed of reinforced drywall

or plasterboard. If you are not sure of your wall

type, consult a professional installer.
