Mircom TX3 Series User manual
Version 1.1 Mircom 1 (42)
LT-968 Copyright 2012
TX3 Series
TELEPHONE ACCESS SYSTEM
User Guide - Keypad Configuration
2 (42) Telephone Access System User Guide Version 1.1
LT-968 Copyright 2012
Copyright 2012 Mircom Inc.
All rights reserved.
Telephone Access System User Guide v.1.1 for Windows 2000/NT/XP®.
This manual, as well as the software described in it, is provided under licence or other agreements
and may be used or copied only in accordance with the terms of such license. The content of this
manual is furnished for informational use only. It is subject to change without notice, and should not
beconstruedasacommitmentbyMircom. Mircomassumesnoresponsibilityorliabilityforanyerrors
or inaccuracies that appear in this book.
Except as permitted by such license, no part of this publication may be reproduced, stored in a
retrieval system, transmitted in any form by means electronic, mechanical, using any recorded
media, or any other format without the prior written permission of Mircom.
Microsoft, MS-DOS, Windows, and Windows 2000/NT/XP are either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or other countries.
Mircom
25 Interchange Way
Vaughan, Ontario
L4K 5W3
905.660.4655
Fax:905.660.4113
3 (42) Telephone Access System User Guide Version 1.1
LT-968 Copyright 2012
Contents
1Introduction7
1.1 Introducing the TX3 Telephone Access System 8
1.2 Warranty and Special Notices 8
1.3 About This Manual 8
2 Configuration 11
2.1 Using the TX3 Telephone Access System 12
2.2 Frequently Used Functions 12
2.3 Viewing Configuration Information 13
2.4 Entering Configuration Mode 13
2.5 Keypad Navigation 14
2.6 Exiting Configuration Mode 14
2.7 Main Door DTMF Setup 15
2.8 Auxiliary Door DTMF setup 16
2.9 Sensitivity DTMF setup 17
2.10 Setting the Talk and Door Timers 18
2.11 Talk Timer setup 18
2.12 Main Door Timer Setup 19
2.13 Auxiliary Door Timer Setup 20
2.14 Changing Your Passcode 20
2.15 Configuration Menu using the Entry Panel Keypad 21
2.16 Glossary 30
2.17 TX3 ADC Frequently Asked Questions 31
2.18 Resident Directory Worksheet 35
Warranty & Warning Information 37
Special Notices 40
4 (42) Telephone Access System User Guide Version 1.1
LT-968 Copyright 2012
Version 1.1 Telephone Access System User Guide 5 (42)
LT-968 Copyright 2012
List of Figures
Figure 1. Viewing Configuration Information 13
Figure 2. Entering Configuration Mode 13
Figure 3. Keypad Navigation 14
Figure 4. Main Door DTMF Setup 15
Figure 5. Auxiliary Door DTMF Setup 16
Figure 6. DTMF Sensitivity 17
Figure 7. Talk Timer Setup 18
Figure 8. Main Door Timer setup 19
Figure 9. Auxiliary Door Timer Setup 20
Figure 10. Changing Your Passcode 21
Figure 11. Entering Resident’s Names 23
6 (42) Telephone Access System User Guide Version 1.1
LT-968 Copyright 2012
Version 1.1 Telephone Access System User Guide 7 (42)
LT-968 Copyright 2012
1 Introduction
This manual provides information on the most common features of the TX3
Telephone Access System and provides you with instructions to configurethe
TX3 Telephone Access System from the main entry panel keypad.
Note: MircomperiodicallyupdatespanelfirmwareandConfigurator
Softwaretoaddfeaturesandcorrectanyminorinconsistencies.
For information about the latest firmware or software visit the
Mircom website at www.mircom.com.
This manual explains how to
• Operate the TX3 Telephone Access Panel
• View Configuration Info
• Add, delete, and edit records
• Set the Main and Auxiliary doors’ DTMF (the touch tone key to press to
open the doors)
• Set the talk timer and door timers
• Change your password
8 (42) Telephone Access System User Guide Version 1.1
LT-968 Copyright 2012
Introduction
1.1 Introducing the TX3 Telephone Access System
The TX3 Telephone Access System is part of the Mircom suite of products that
provide building ready monitoring, control and integrated security solutions for
use in the high end multi-tenant residential market.
The TX3 Telephone Access System addresses the need within today’s high end
multi-tenant residential market for an easy-to-use tenant access system and an
easy-to-useconfiguration utility. TheTX3TelephoneAccess System creates an
aestheticallypleasing highquality entry system for residents and their visitors in
a multi-unit dwelling establishment.
This manual provides the technician with information about the keypad
configuration of the TX3 Telephone Access System and explains how to
configurevariouscomponentsforanewsystem,includingthemodificationofan
existing system.
1.2 Warranty and Special Notices
Mircom values your business and always attempts to provide you with the very
best service.
Please see the Warranty and Special Notices chapter onpage 37 for information
about the warranty and special notices about equipment use.
1.3 About This Manual
This manual provides comprehensive information on the installation and
configuration of the Touch Screen by the installation technician. Tasks are
described in the order that they are likely to be performed.
1.3.1 Version Control
The version number appears on the front cover and changes whenever there is a
major or minor update to any part of the system regarding operation or
configuration.
The following convention indicates major or minor changes:
Initial release. Version 1.00.0
Major change. Version 2.00.0
Minor change. Version 2.01.0
Pre-release changes. Version 2.01.1
Introduction
Version 1.1 Telephone Access System User Guide 9 (42)
LT-968 Copyright 2012
1.3.2 Additional Documentation
For additional documentation, see the following Mircom literature:
• TX3-CX Touch Screen Administrators Guide LT-995
• TX3 Telephone/Card Access System Installation and Operation Manual
LT-969
• TX3-CX Card Access System Installation and Operation Manual LT-980
• TX3 Two Door Card Access System Kit Catalogue Number 6531
• TX3 Series Elevator Restriction Accessories Catalogue Number 6532
1.3.3 Contact Us
You can contact us from Monday to Friday 8:00 A.M. to 5:00 P.M. E.S.T.
1.3.4 General Inquiries
Toll Free: 1-888-660-4655
Local: 905-660-4655
1.3.5 Customer Service
Toll Free: 1-888-MIRCOM5
Local: 905-695-3535
Local Fax: 905-660-4113
Toll-Free Fax: 1-888-660-4113
10 (42) Telephone Access System User Guide Version 1.1
LT-968 Copyright 2012
Introduction
1.3.6 Technical Support
Fortechnical supportcontactMircom’sTechnical Support Department between
8 A.M. and 5 P.M. (EST) Monday through Friday, excluding holidays.
Toll Free: 1-888-MIRCOM5
Local: 905-695-3535
Local Phone: 905-660-4655
Toll Free Phone: 1-888-660-4655
Email: [email protected]
1.3.7 Website
www.mircom.com
1.3.8 Email
