Maytag MVW18MN User manual

LEGENDARY MAYTAG DEPENDABILITY

Maximizing your equipment investment for over a half-century.

ENERGY-SAVING SOLUTIONS

Maytag built the first appliance ever to receive the ENERGY STAR®

label. Today, we offer energy-saving laundry solutions for all

commercial laundry needs—from highly efficient ENERGY STAR®-

qualified washers to the most energy-efficient dryers ever from

Maytag—to help you save money and build profits.

FOR YOUR CUSTOMERS:

• Proven Cleaning Performance

• Extra-Large Lid and Tub Opening

• User-Friendly Controls Allow for Customized Cleaning

FOR YOUR OPERATION:

• Our Most Energy-Efficient Top-Load Washer

• Sensor Fill Water Levels Reduce Water Usage

• Maytag Connect 360°™ Wireless Audit System—Option

• High-Speed Spin of 144 G-Force Reduces Dry Time

BUILT-TO-LAST™FEATURES:

• Premium Porcelain-Enamel Top

• Smooth Balance Suspension System

• Front Access for Easier-Self Service

• 5-Year Limited Warranty—All Parts Covered

MVW18MN

MAYTAG®COMMERCIAL

ENERGY ADVANTAGE™

TOP-LOAD WASHER

MY130066

visit maytagcommerciallaundry.com

or call 800-662-3587

MG13104_MVW18MNSpec.indd 1 5/20/13 1:52 PM

5-YEAR LIMITED WARRANTY

ALL PARTS COVERED

For a period from the date of original purchase through the time listed above,

the designated parts that fail in normal commercial use will be repaired or

replaced free of charge for the part itself, with the owner paying all other

costs, including labor, transportation and customs duty. Chemical damage is

excluded from all warranty coverage. See complete warranty for details.

WASHER SPECIFICATIONS

MODEL MVW18MN

MOTOR

Single-phase, reversible, thermoprotected, high torque



HP (kw)

.33 (.25)

APPROXIMATE WATER USAGE—GALLONS (LITERS)

Average hot water usage, hot water cycle 6.1 (22.9)*

Average hot water usage, warm water cycle —

Average total water usage per cycle 19.9 (75)*

ELECTRIC RATING

Domestic model—voltage/Hz 120/60

Export model—voltage/Hz 220–240/50

BREAKER/FUSE MINIMUM REQUIREMENTS

Domestic model—amps 15

Export model—amps 10

CAPACITY

Cylinder volume—cu. ft. (liters) 2.9 (82)

Cylinder diameter—in. (mm) 20.8 (528)

Cylinder depth—in. (mm) 23.8 (605)

EXTRACT SPEED

Maximum RPM 700

Maximum G-Force 144

OPERATING PRESSURE

Psi (bar) 20–100 (1–8)

INLET HOSE LENGTH

Ft. (m) 6 (1.8)

DRAIN HOSE LENGTH

Ft. (m) 4.2 (1.3)

ADJUSTABLE LEVELING LEGS



APPROXIMATE WEIGHT

Crated—lbs. (kg) 137 (63)

Uncrated—lbs. (kg) 122 (55)

DIMENSIONS

Height—in. (mm) 40.8 (1,036)**

Width—in. (mm) 27 (686)

Depth—in. (mm) 25.9 (658)

Lid opening—in. (mm) 17 (432)

WARRANTY 5-YEAR

*Average based on DOE J1 testing with factory preset cycles.

**Height at metercase top does not include pedestal.

Dimensions are for planning purposes only. See specific instructions for proper installation. Because of continuous product

improvement, Maytag reserves the right to change specifications without notice. Export model ships without coin-drop mechanism.

Maytag®Commercial Energy Advantage™

Top-Load Washer

MECHANICAL NON-COIN

At Maytag, we believe durable goods should remain just that.

That’s why every Maytag®product is constructed of the

highest-quality materials and with the utmost in precision

craftsmanship. It’s also why we stand behind our equipment

with solid service and support from our professional Maytag

laundry suppliers. Simply put, when you choose Maytag®

products, you ensure your peace of mind.

OUR COMMITMENT

TO DEPENDABLE QUALITY

5/13

MVW18MN

MAYTAG®COMMERCIAL

ENERGY ADVANTAGE

™

TOP-LOAD WASHER

Front View

Back View

MG13104_MVW18MNSpec.indd 2 5/20/13 1:52 PM
